Sentinel V SC and RT Operation Manual
Correlation Magnitude, Echo Intensity, and Per-
cent-Good Data Format
BYTE 7/S
1
2
3
4
5
6
7
8
9
10
↓
511
512
513
514
See Table 40 through Table 42 for a description of the fields.
Figure 106.
The number of depth cells is set by ReadyV. The value will be calculated based on the Range
and Cell size.
Correlation magnitude data give the magnitude of the normalized echo autocorrelation at the lag used for
estimating the Doppler phase change. The Sentinel V ADCP represents this magnitude by a linear scale
between 0 and 255, where 255 is perfect correlation (i.e., a solid target). A value of zero indicates bad cor-
relation values.
Table 40: Correlation Magnitude Data Format
Binary Field
Byte
1,2 ID Code
3 Depth Cell 1,
Field 1
Depth Cell 1,
4
Field 2
BIT POSITIONS
6 5 4
ID CODE (see Table 40 to Table 42)
DEPTH CELL #1, FIELD #1
DEPTH CELL #1, FIELD #2
DEPTH CELL #1, FIELD #3
DEPTH CELL #1, FIELD #4
DEPTH CELL #2, FIELD #1
DEPTH CELL #2, FIELD #2
DEPTH CELL #2, FIELD #3
DEPTH CELL #2, FIELD #4
(SEQUENCE CONTINUES FOR UP TO Maximum # BINS)
DEPTH CELL #Maximum , FIELD #1
DEPTH CELL #Maximum , FIELD #2
DEPTH CELL #Maximum , FIELD #3
DEPTH CELL #Maximum , FIELD #4

Correlation Magnitude, Echo Intensity, and Percent-Good Data Format

Description
Stores the correlation magnitude data identification word (00 02h).
Stores correlation magnitude data for depth cell #1, beam #1. See above.
Stores correlation magnitude data for depth cell #1, beam #2. See above.
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
3 2 1
September 2017
0
LSB
MSB
↓
Page 263
