rows is the distance between the two digital rows one is made according to the Arduino shield
standard (e.g. you want to mount the row there if using Arduino certified shield), the other one is
adjusted properly at 100mil step (e.g. you want to solder the digital pins here if using properly
adjusted shields).
The pinhole names are printed near the actual pinhole on the top of the board.
Pin Signal Name
RST RST
3V3 3.3V
5V 5V
GND GND
GND GND
VIN VIN
Pin Signal Name
D0 PA3/USART_RX
D1 PA2/USART_TX
D2 PG7
D3 PG8
D4 PG12
D5 PG13
D6 PG14
D7 PG15
Arduino platform pinholes
CON1
Processor pin#
25
-
-
-
-
-
Arduino platform pinholes
CON3
Processor pin#
37
36
92
93
127
128
129
132
Pin Signal Name
A0 PC0
A1 PC1
A2 PB0
A3 PB1
A4 PC4
A5 PC5
Pin Signal Name
D8 PA1
D9 PB11
D10 PA4
D11 PA7
D12 PA6
D13 PA5
GND AGND
AREF AREF
Page 17 of 30
STM32-H407 user's manual
CON2
Processor pin#
26
27
46
47
44
45
CON4
Processor pin#
35
70
40
43
42
41
31
32
