This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.
Invacare® Storm®⁴ Series
Storm⁴, Storm⁴ X-plore, Storm⁴ True Track® Plus
en Power Wheelchair
User Manual
