Page 1 Yes, you can. ® Invacare® Storm & Storm X-plore Power wheelchair User manual...
Page 3 How can you get in touch with Invacare®? If you have any questions or need support, please contact your authorised Invacare® Dealer, who has the necessary know-how and equipment plus the special knowledge concerning your Invacare® product, and can offer you all-round satisfactory service. Should you wish to contact Invacare® directly, you can reach us in Europe at the following addresses and phone numbers.
Page 4 +44 (0)1656 77 62 20 Pencoed uk@invacare.com Bridgend CF35 5AQ WWW: www.invacare.co.uk United Kingdom Invacare Mecc San s.r.l. +39 0445 38 00 59 Via dei Pini, 62 Fax: +39 0445 38 00 34 I - 36016 Thiene (VI) italia@invacare.com ITALIA WWW: www.invacare.it...
Page 5 +46 (0)8 761 81 08 Fagerstagatan 9 sweden@invacare.com S-163 91 Spånga finland@invacare.com Sverige WWW: www.invacare.se Tillverkare: MÖLNDAL Invacare® Deutschland GmbH  : +46 (0)31 86 36 00 Kleiststraße 49 Fax: +46 (0)31 86 36 06 D-32457 Porta Westfalica ginvacare@invacare.com Deutschland LANDSKRONA ...
Page 6: Table Of Contents
Table of Contents Chapter Page Introduction Important symbols in this manual ..................14 Important symbols found on the vehicle ................16 1.2.1 Explanation of symbols on lifter warning sticker............19 Type classification and permissible use................20 Indications..........................20 Usability............................21 Warranty ...........................22 Life expectancy........................22 Safety notes General safety notes .......................23 Safety information with regard to care and maintenance ...........26 Safety information on electromagnetic interference ............27...
Page 7 Information about getting in and out..................38 Using the cane holder ......................39 Driving Before driving for the first time....................40 Parking and stationary......................41 Taking Obstacles........................42 6.3.1 Maximum obstacle height .....................42 6.3.2 Safety information when ascending obstacles .............42 6.3.3 The correct way to overcome obstacles ...............43 Driving up and down gradients....................43 Using foldable antitipper wheels ...................45 Use on public roads ........................46...
Page 8 9.3.3 Adjusting the width of the travelling armrests ...............58 9.3.4 Adjusting the mobility of the travelling armrests ............60 9.3.5 Adjusting the arm support positions for the travelling armrests........61 Adjustment options for the Modulite seat unit..............63 9.4.1 Setting the height of the armrests.................63 9.4.2 Adjusting the width of the armrests ................63 9.4.3...
Page 9 9.9.1 Explanation of symbols on lifter warning sticker............85 9.10 Adjusting the trunk support (Easy-Adapt seating system)..........86 9.10.1 Adjusting the width......................86 9.10.2 Adjusting the height ......................87 9.10.3 Adjusting the depth .......................88 9.11 Adjusting and removing the tray ...................89 9.11.1 Laterally adjusting the tray....................89 9.11.2 Adjusting the depth of the tray / removing the tray............90 9.11.3 Swinging the tray away to the side ................90 9.12...
Page 10 10.1.2.2 Adjusting the length of the legrest .................114 10.1.2.3 Adjusting the calf plate to the calf width of the user ..........115 10.1.2.4 Adjusting the angle of the foot plate ..............116 10.2 Legrests or footrests attached to the side................117 10.2.1 Vari-F footrest ......................117 10.2.1.1 Swivelling the footrest outward and/or removing...........117 10.2.1.2...
Page 11 11 Electrical system 11.1 Electronics protection system .....................147 11.2 Batteries ..........................148 11.2.1 Charging the batteries ....................148 11.2.1.1 General information on charging ................148 11.2.1.2 General instructions on charging................148 11.2.1.3 How to charge the batteries...................149 11.2.1.4 How to disconnect the batteries after charging .............150 11.2.2 Storage and Maintenance...................151 11.2.3 Instructions on using the batteries................151 11.2.4 Transporting batteries....................153...
Page 12 13.2.2 How the user is secured within the wheelchair............173 13.3 Securing the wheelchair for transport without passengers ..........177 13.3.1 Opening the rear cover ....................178 13.3.2 Making the batteries accessible .................179 13.3.3 Removing/Installing the batteries ................182 14 Refurbishment 15 Disposal 16 Technical specifications 17 Inspections Performed...
Page 13: Introduction
If you find that the font size in the print version of the user manual is difficult to read, you can download it as a pdf from the Invacare website. This can then be scaled on screen to a font size that is more comfortable for you.
Page 14: Important Symbols In This Manual
Some maintenance and settings can be performed by the user or his/hers attendants. Certain adjustments do however require technical training and may only be carried out by your Invacare® specialist dealer. Damages and errors caused by nonobservance of the user manual or as a result of incorrect maintenance are excluded from all guarantees.
Page 15 BURN Risk! This symbol warns of the risk of burns, for example, as a result of hot motor surfaces. • Follow the instructions in order to avoid injury or damage to the product. RISK OF CRUSHING! This symbol warns of a risk of crushing caused by being careless with heavy components.
Page 16: Important Symbols Found On The Vehicle
Requirements: • This symbol identifies a list of various tools, components and items which you will need in order to carry out certain work. Please do not attempt to carry out the work if you do not have the listed tools available. READ WELL BEFORE OPERATION! This symbol advises you to read information carefully.
Page 17 This symbol indicates the “Push” position of the coupling lever. In this position the motor is disengaged and the motor brakes are not operational. The wheelchair can be pushed by an attendant and the wheels turn freely. • Please note that the control panel must be switched off. •...
Page 18 • Please always make sure that the wheelchair is equipped with a headrest approved by Invacare before using it as a vehicle seat! This symbol indicates the maximum width to which an armrest may be adjusted. Pulling the armrest out further can cause it to fall out of it's fixation.
Page 19: Explanation Of Symbols On Lifter Warning Sticker
1.2.1 Explanation of symbols on lifter warning sticker Do not lean out Do not drive up Do not allow any Never drive with Never drive over when the lifter is or down slopes body parts to get two people! uneven surfaces raised! when the lifter is under a raised...
Page 20: Type Classification And Permissible Use
Type classification and permissible use This vehicle was designed for persons whose ability to walk is impaired, but who are still in terms of their eyesight and physically and mentally able to operate an electric vehicle. It has been classified according to EN 12184 as a class B mobility product (for indoor and outdoor areas).
Page 21: Usability
• You should immediately stop using your power wheelchair if its usability is restricted due to: - brake failure • You should immediately contact an authorised Invacare® dealer if the usability of your power wheelchair is restricted due to: - the lighting system failing or being defective...
Page 22: Warranty
- unusual sounds developing or occurring Or if you have the feeling that something is wrong with your wheelchair. Warranty The terms and conditions of the warranty are part of the general terms and conditions particular to the individual countries in which this product is sold. Life expectancy We estimate a life expectancy of five years for this product, provided it is used in strict accordance with the intended use as set out in this document and all maintenance and service requirements...
Page 23: Safety Notes
Safety notes READ WELL BEFORE OPERATION! General safety notes Danger of injury if mobility device is used in any other way than the purpose described in this manual! • Only ever use the mobility device in accordance with the instructions in this User's Manual (see chapter "Type classification and permissible use"...
Page 24 Danger of injury if the mobility device is switched off while driving, for example by pressing the On/Off Button or disconnecting a cable, due to it coming to an abrupt, sharp stop! • If you have to brake in an emergency, simply release the joystick which will bring you to a halt. (refer to the joystick operating manual for more information).
Page 25 Danger of fire or breaking down due to electric devices being connected! • Do not connect any electric devices to your mobility device that are not expressly certified by Invacare® for this purpose. Have all electrical installations done by your authorised Invacare® Dealer.
Page 26: Safety Information With Regard To Care And Maintenance
Safety information with regard to care and maintenance Danger of accident and loss of guarantee if maintenance is insufficient! • For reasons of safety and in order to avoid accidents which result from unnoticed wear, it is important that this electric mobility product undergoes an inspection once every year under normal operating conditions (see inspection plan contained in service instructions).
Page 27: Safety Information On Electromagnetic Interference
Safety information on electromagnetic interference This electric vehicle was successfully tested in accordance with International standards as to its compliance with Electromagnetic Interference (EMI) regulations. However, electromagnetic fields, such as those generated by radio and television transmitters, and cellular phones can influence the functions of electric vehicles.
Page 28: Safety Information On Driving And Freewheel Mode
Safety information on driving and freewheel mode Danger of injury if the wheelchair tips over! • Inclines and declines can only be travelled up to the maximum safe slope (see chapter "Technical specifications" from page 186). • Always return the backrest of your seat or the seat tilt to an upright position before ascending slopes.
Page 29 Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area! • If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant! Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion! •...
Page 30: Safety Information Regarding Changes And Modifications To The Mobility Device
EEC / MPG (Medical Devices Act) and only applies to the complete product. The CE marking is invalidated if components or accessories are replaced or added that have not been approved for this product by Invacare. In this case, the company that adds or replaces the components or accessories is responsible for the conformity assessment/ CE marking or for registering the wheelchair as a special design and for the relevant documentation.
Page 31 • Only use seating systems that have been approved by Invacare® for this power wheelchair. Electrical and electronic components which have not been approved by Invacare® for use with this mobility aid can cause fire hazards and lead to electromagnetic damage! •...
Page 32: Safety Information On Wheelchairs With A Lifter
Safety information on wheelchairs with a lifter WARNING! Danger of injury by moving parts! • Never let objects get caught in the space underneath a raised lifter! • Make sure that neither you nor anyone else is injured by placing hands, feet other body extremities under the raised seat! •...
Page 33 CAUTION! Damage to mobility aid caused by one-sided loading on lifter pillar! • One-sided loading occurs if the seat is raised and/or tilted. Always return your seat backrest to the upright position and the seat tilting to the horizontal position before ascending slopes! ! Never subject the lifter pillar to continuous single-sided loading! The raising and tilting function of the seat only provides additional rest positions.
Page 34: Safety Information On Wheelchairs With Recaro Seats And Aj Optimist Seats
Safety Information on Wheelchairs with Recaro Seats and AJ Optimist Seats Danger of injury if the wheelchair tips over! The centre of gravity of a Recaro seat or AJ Optimist seat is higher than that of other seats. These seats are also heavier than other seating systems. The backrest can be leaned back 90°...
Page 35: Key Features
Key features 1) Headrest 2) Backrest 3) Armrest 4) Battery case (rear) 5) Drive wheel 6) Drive motor (with engaging lever) 7) Remote 8) Legrests 9) Castor wheel 10) Suspension, rear (both not visible in illustration, adjustable for Storm plore only) 11) Suspension, centre (Storm X-plore only)
Page 36: The Position Of The Labels On The Product
The position of the labels on the product 1) Note: Remove the table before transporting 2) Identification of the lashing eyes at the front and back Warning that the wheelchair may not be used as a vehicle seat Note on required head support if the wheelchair may be used as a vehicle seat 3) Warning regarding the use of the lifter 4) Identification of the position of the coupling...
Page 37: Getting In And Out Of The Wheelchair
Getting in and out of the wheelchair Important information for getting into and out of the wheelchair from the side! The armrest must be removed in order to get into or out of the wheelchair from the side. Removing the armrests to get in If you want to get out on the side where the remote is installed, you can disconnect the remote cable from the remote (depending on your version).
Page 38: Information About Getting In And Out
Information about getting in and out Getting into the wheelchair: • Position your wheelchair as close as possible to your seat. This might have to be done by an attendant. • Switch your wheelchair off. • Apply the manual wheel lock of your wheelchair (if existing). •...
Page 39: Using The Cane Holder
Using the cane holder If your mobility device is fitted with a cane holder, it can be used for the safe transport of a walking cane, underarm or forearm crutches. The cane holder consists of a plastic container (bottom) and a Velcro fastener (top).
Page 40: Driving
Driving NOTE The maximum load capacity that is stated in the technical data only states that the system is designed for this mass in total. However, this does not mean that one can sit a person with this body weight in the wheelchair without restrictions. Attention must be paid to the body proportions, such as height, weight distribution, abdominal girth, leg and calf girth and seat depth.
Page 41: Parking And Stationary
• The rear mirror (if installed) is adjusted so you can look behind at all times without having to bend forward or shift your seating position. Parking and stationary When parking your vehicle or if your vehicle is stationary for a prolonged period: •...
Page 42: Taking Obstacles
Taking Obstacles 6.3.1 Maximum obstacle height You can find information about maximum obstacle heights in the chapter entitled "Technical specifications" from page 186. 6.3.2 Safety information when ascending obstacles CAUTION: Danger of Tipping Over! • Never approach obstacles at an angle but at 90 degrees as shown below. •...
Page 43: The Correct Way To Overcome Obstacles
6.3.3 The correct way to overcome obstacles Ascending Right • Approach the obstacle or the kerb slowly, head-on and at a right angle. • Depending on the wheel drive type, stop in one of the following positions: - In the case of centrally driven wheelchairs: 5 - 10 cm before the obstacle. - For all other drives: approx.
Page 44 WARNING: Danger of tipping over! • Only ever drive downhill at a maximum of 2/3 of the top speed. Avoid sudden changes of direction or abrupt braking when driving on slopes. • Always return the backrest of your seat or the seat tilt (if adjustable seat tilt is available) to an upright position before ascending slopes.
Page 45: Using Foldable Antitipper Wheels
Using foldable antitipper wheels (Storm4) Where space is restricted, e.g. in an elevator or when being transported in a car, the mobility device may be too long. Foldable antitipper wheels can be useful here. These can only be operated by an attendant as they are positioned beyond the reach of the user.
Page 46: Use On Public Roads
If you wish to use your wheelchair on public roads and lighting is required by national legislation, then your wheelchair needs to be equipped with an appropriate lighting system. Please contact your Invacare ® dealer if you have any questions.
Page 47: Pushing The Mobility Device In Freewheel Mode
Pushing the mobility device in freewheel mode The motors of the wheelchair are equipped with automatic brakes, preventing that the wheelchair starts rolling out of control when the joystick box is switched off. When pushing the wheelchair manually whilst freewheeling, the magnetic brakes must be disengaged. NOTE: Pushing the wheelchair by hand may require more physical force than expected (more than 100 N).
Page 48: Remotes
Disengaging the motor: • Switch off remote. • Pull the engaging lever (1) upwards. The motor is disengaged. Engaging the motor: • Push the engaging lever down (1). The motor is engaged. Please note that both motors must always be engaged before driving! Remotes Your wheelchair may be equipped with one of several different remotes.
Page 49: Adjusting The Wheelchair To The User's Seating Posture
Adjusting the wheelchair to the user's seating posture CAUTION: Damage to wheelchair and accident hazard! It is possible that collisions can occur between wheelchair components due to various combinations of adjustment options and their individual settings! • The wheelchair is fitted with an individual, multiply adjustable seating system including adjustable legrests, armrests, a headrest or other options.
Page 50: Adjustment Possibility For Control Panel
Adjustment possibility for control panel The following information is valid for all seating systems. CAUTION: Danger of the control panel being pushed backwards during an accidental collision with an obstacle, such as a doorframe or table, and the joystick being jammed against the armpad if the position of the control panel is adjusted and all screws are not completely tightened! This will cause the mobility device to drive forward uncontrollably and potentially injure the mobility device user and any person standing in the way!
Page 51: Adjusting The Height Of The Remote (Only For Foldable Remote Holders)
9.1.2 Adjusting the height of the remote (only for foldable remote holders) Pre-requisites: • 1x 6 mm Allen key • Unscrew screw (1) with Allen key. • Adjust remote to required height. • Retighten the screw.
Page 52: Swivelling The Remote To The Side
9.1.3 Swivelling the remote to the side If your wheelchair is fitted with a swing-away remote bracket, then the remote can be moved away to the side, for example to drive up close to a table.
Page 53: Adjustment Facilities For Standard Armrests
Adjustment facilities for standard armrests 9.2.1 Changing the arm support position Requirements: • 1x Allen key 3 mm The arm support has 12 possible positions. • To change the position of the arm support, loosen the screw (1) and remove it. •...
Page 54: Setting The Height Of The Armrests
9.2.2 Setting the height of the armrests Requirements: • Allen key 3 mm • Unscrew screw (1) with Allen key. • Adjust armrest to required height. • Retighten the screw.
Page 55: Adjusting The Width Of The Armrests
9.2.3 Adjusting the width of the armrests WARNING! Serious injury hazard if one of the armrests falls out of its bracket because they have been adjusted to a width which exceeds the permissible value! • The width adjustment is fitted with small stickers with markings and the word "STOP"! The armrests must never be pulled out further than the point at which the word "STOP"...
Page 56: Adjustment Facilities For Travelling Armrests
Adjustment facilities for travelling armrests 9.3.1 Setting the height of the parallel sliding armrests The height of the travelling armrest is set using the armrest angle. • Release the knob to adjust the armrest angle (1). • Set the angle for the armrest. •...
Page 57: Adjusting The Angle Of The Armpad On The Parallel Sliding Armrests
9.3.2 Adjusting the angle of the armpad on the parallel sliding armrests Requirements: • Allen key 5 mm • Release the bolts to adjust the armrest angle (1) with the allen key. • Set the angle for the armrest. • Re-tighten the bolts. Make sure that the Nordlock washers used are re-inserted.
Page 58: Adjusting The Width Of The Travelling Armrests
9.3.3 Adjusting the width of the travelling armrests The travelling armrests can be adapted to the backrest in eight widths. Pre-requisites: • 1x 4 mm Allen key • Undo the bolts on both sides of the backrest cover (1). The photograph only shows the bolts on the left- hand side.
Page 59 • Adjust the armrest width. The possible positions for the armrest are predefined by the drill-holes in the torque support and the armrest axel. • Insert the locating pin. • Retighten the screw. • Repeat the procedure for the other armrest. •...
Page 60: Adjusting The Mobility Of The Travelling Armrests
9.3.4 Adjusting the mobility of the travelling armrests The flexibility of the travelling armrest can be adjusted to easier or stiffer. Requirements: • Allen key 5 mm • To make the armrest easier to move, release the bolt of the adjusting wrench (1) with the Allen key. •...
Page 61: Adjusting The Arm Support Positions For The Travelling Armrests
9.3.5 Adjusting the arm support positions for the travelling armrests Requirements: • Allen key 5 mm • Put the armrest in the vertical position. • Release the interior bolts (1) with the Allen key.
Page 62 • Position the armrest horizontally. • Re-tighten the bolts. Make sure that the Nordlock washers used are re-inserted.
Page 63: Adjustment Options For The Modulite Seat Unit
Adjustment options for the Modulite seat unit 9.4.1 Setting the height of the armrests • Loosen the wing screw (1). • Set the armrest to the desired height. • Re-tighten wing screw. 9.4.2 Adjusting the width of the armrests WARNING! Serious injury hazard if one of the armrests falls out of its bracket because they have been adjusted to a width which exceeds the permissible value! •...
Page 64 Note Depending on the side, the screw is accessible from the front or the rear. Requirements: • Allen key 8 mm Carrying out adjustments • Loosen screw (1) • Adjust armrest to required position. • Retighten the screw. • Repeat this procedure for the second armrest.
Page 65: Adjusting The Position Of The Armrest In Depth (Modulite Seat Unit)
The description of how the width is adjusted in contained in the service instructions for this mobility device. The service instructions can be ordered from Invacare®. However, they contain instructions for specially trained service technicians and describe operations that are not intended for the end...
Page 66: Adjusting The Seat Depth (Modulite Seat Unit)
See "Adjusting the center of gravity of the seat" in the service instructions for this mobility device. The service instructions can be ordered from Invacare®. However, they contain instructions for specially trained technicians and describe operations that are not intended for the end user.
Page 67 • On both sides, loosen the bottom backrest screw (A). Do not remove the screws! • Move the backrest to the required seat depth. You can adjust the seat depth steplessly. Use scale (B) on the seat as a guide for this purpose. Ensure that the same seat depth is set on both sides.
Page 68: Adjusting The Seat Angle
Adjusting the seat angle CAUTION! Adjusting the seat tilt or the backrest angle changes the geometry of the mobility device and directly influences its tipping stability! • For details regarding tipping stability, negotiating gradients and obstacles and the correct adjustment of seat tilt or backrest angle, please see chapters "Taking Obstacles" on page 42 and "Driving up and down gradients"...
Page 69 • Switch the power supply off (ON/OFF key). • Unscrew Allen screws (1). • Adjust the seat angle by raising or lowering the seat. • Insert the Allen screws again and tighten.
Page 70: Adjusting The Backrest
Adjusting the backrest CAUTION! Adjusting the seat tilt or the backrest angle changes the geometry of the mobility device and directly influences its tipping stability! • For details regarding tipping stability, negotiating gradients and obstacles and the correct adjustment of seat tilt or backrest angle, please see chapters "Taking Obstacles" on page 42 and "Driving up and down gradients"...
Page 71: Adjusting The Back Seat Angle On The Easy-Adapt Seating System
9.6.2 Adjusting the back seat angle on the Easy-Adapt seating system 9.6.2.1 Electric Please consult the user manual for your remote for information about electrical adjustment. 9.6.2.2 Manual • Adjust the angle by turning the handwheel (1).
Page 72: Adjusting The Height Of The Backrest (Modulite Seat Unit)
9.6.3 Adjusting the height of the backrest (Modulite seat unit) The following section describes the procedures for adjusting the height of the backrest plate. Note The sling back is only available in fixed heights of 48 and 54 cm. Prerequisites: •...
Page 73: Adjusting The Width Of The Backrest (Modulite Seat Unit)
For a replacement description, see the service instructions for this mobility device. The service instructions can be ordered from Invacare®. However, they contain instructions for specially trained service technicians and describe operations that are not intended for the end user.
Page 74: Adjusting The Backrest Angle (Modulite Seat Unit)
• Loosen and remove the backrest plate screw (A). • Loosen the backrest plate screws (B). Do not remove the screws! • Move the backrest plate halves to the required width. • Re-insert screw (A). • Re-tighten the screws. 9.6.5 Adjusting the backrest angle (Modulite seat unit) CAUTION Every change to the seat angle and every backrest angle change alters the geometry of the electric wheelchair and affects its tipping stability...
Page 75: Manual
9.6.5.2 Manual Width-adjustable backrest Prerequisites: • 1x 5 mm Allen key • Loosen and remove the upper backrest screw (A) on both sides. • Set the required backrest angle. Use scale (B) on the backrest for this purpose. Ensure that you set the same angle on both sides. •...
Page 76 Simple backrest Prerequisites: • 1x 6 mm Allen key • On both sides, loosen and remove the middle backrest screw (A). • Set the required backrest angle in 7.5° steps. Ensure that you set the same angle on both sides. •...
Page 77: Adjusting The Adaptable Backrest Padding
9.6.6 Adjusting the adaptable backrest padding (FDX, Storm 4) There are two ways of adapting the backrest padding. • Using a snap buckle which is accessible without having to remove the backrest cushion. Please see Method 1. • With adjustment straps which are adjustable using Velcro. Please see Method 2. Method 1 •...
Page 78 Method 2 • Remove the backrest cushion (fixed with Velcro straps) by pulling it up and away so that you can access the adjusting straps. • Adjust the tension of the individual straps as required. • Replace the backrest cushion.
Page 79: Adjusting The Headrest
This can cause the neck to be hyperextended during collisions! • A headrest must be installed! The headrest optionally supplied for this mobility device by Invacare® is perfectly suitable for use during transport. • The headrest must be adjusted to the user's ear height.
Page 80: Adjusting The Position Of The Headrest Or Neckrest
9.7.1 Adjusting the position of the headrest or neckrest The adjustment of the position is the same for all headrests and neckrests. Pre-requisites: • Allen key 5 mm • Loosen the screws (1, 2) or the clamping lever (3). • Adjust the headrest or neckrest to the required position.
Page 81: Adjusting The Height Of The Headrest Or Neckrest
9.7.2 Adjusting the height of the headrest or neckrest The adjustment of the height is the same for all headrests and neckrests. • Loosen the thumb screw (1). • Adjust the headrest or neckrest to the required height. • Retighten thumb screw.
Page 82: Adjusting The Cheek Supports
9.7.3 Adjusting the cheek supports • Push the cheek supports inward or pull them out to the required position. Postural belts A postural belt is an option which can either be fixed to the wheelchair ex-works or can be retrofitted by your specialist dealer. If your wheelchair is fitted with a postural belt, your specialist dealer will have informed you about fitting and usage.
Page 83: Types Of Postural Belts
9.8.1 Types of postural belts Your wheelchair can be fitted with the following postural belt types ex-works. If your wheelchair has been fitted with a different belt to those listed below, please ensure that you have received the manufacturer's documentation with regard to correct fitting and use. Belt with metal buckle, adjustable one side Belt can only be adjusted on one side which can result in the buckle not sitting centrally.
Page 84: The Lifter
Information regarding operation of the lifter at temperatures of less than 0 °C Invacare® mobility aids are fitted with safety mechanisms that prevent capacity overload of the electronic components. At operating temperatures below freezing point this can, in particular, lead to the lifter actuator being shut down after approx.
Page 85: Explanation Of Symbols On Lifter Warning Sticker
CAUTION Risk of tipping, if the speed limiter sensors fail when the lifter is raised. • If you find that the speed reduction function is not working when the lifter is raised, do not drive with the lifter raised and immediately contact an authorized Invacare® dealer. 9.9.1...
Page 86: Adjusting The Trunk Support (Easy-Adapt Seating System)
9.10 Adjusting the trunk support (Easy-Adapt seating system) The trunk supports can be adjusted in width, height and depth. 9.10.1 Adjusting the width • Loosen the handscrews (1). • Adjust the trunk support to the required width. • Retighten the handscrews again.
Page 87: Adjusting The Height
9.10.2 Adjusting the height Requirements: • Allen key 5 mm • Undo the height adjustment Allen screws (1). • Set the trunk support to the required height. • Retighten the screws.
Page 88: Adjusting The Depth
9.10.3 Adjusting the depth Requirements: • Allen key 5 mm • Open the zip. • Undo the screws (1) for the depth adjustment. • Adjust the trunk support to the required position. • Retighten the screws. • Close the zip again.
Page 89: Adjusting And Removing The Tray
9.11 Adjusting and removing the tray CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 9.11.1 Laterally adjusting the tray •...
Page 90: Adjusting The Depth Of The Tray / Removing The Tray
9.11.2 Adjusting the depth of the tray / removing the tray • Loosen the wing-screw (1). • Adjust the table to the desired depth (or remove it entirely). • Re-tighten the screw. 9.11.3 Swinging the tray away to the side The tray can be swivelled up and away to the side to allow the user to get in and out of the mobility device CAUTION! Risk of injury! When the tray is raised it does not lock in place in this position!
Page 91: Seat Support
The tray can be swivelled upwards and pushed to the side as illustrated to enable getting on and off. 9.12 Seat support (FDX, Storm 4) 9.12.1 Adjusting seat width Note Please also refer to the following chapter entitled "Adjusting the seat depth". The seat width can be adjusted in stages between 380 and 530 mm.
Page 92: Exploded Drawing Of Seat Support
9.12.1.1 Exploded drawing of seat support...
Page 93 • Remove the seat cushion. • Remove the cover plates (1). • Undo the two Allen screws (6) at the rear on the crossmember and remove them. • Undo the two Allen screws (9) at the front on the seat support plate and remove them. •...
Page 94: Adjusting The Seat Depth
9.12.2 Adjusting the seat depth Note Please also refer to the previous chapter entitled "Adjusting the seat width". The seat depthcan be adjusted in stages between 380 and 530 mm. Requirements: • 4 mm Allen key • 8 mm jaw spanner •...
Page 95 Seat depth Holes used in front seat Holes used in rear seat frame Seat support plate required in cm frame order no.: 1524550 order no.: 1524555 6 & 7 A & B SHORT 5 & 7 A & C order no. 1526437 4 &...
Page 96: Exploded Drawing Of Seat Support
9.12.2.1 Exploded drawing of seat support...
Page 97: Adjusting The Seat Depth Without Replacing The Seat Support Plate
• Adjust the seat depth as described in the following chapter: - If the seat support plate does not need to be replaced, please refer to Chapter 9.12.2.2. - If the seat support plate does need to be replaced, please refer to Chapter 9.12.2.3. 9.12.2.2 Adjusting the seat depth without replacing the seat support plate •...
Page 98: Adjusting The Seat Depth With Replacing The Seat Support Plate
9.12.2.3 Adjusting the seat depth with replacing the seat support plate Disassembly: • Remove the legrests. • Remove the armrests. • Remove the seat cushion. • Remove any cable ties which hold cables from the remote or lighting which have been fitted. Remove the cables from any clips which have been glued on.
Page 99 • Insert the Allen screws (5) including washers again and tighten them. • If necessary, replace the seat support plate (2) in accordance with the table (see above). • Put the seat support plate (2) back in position. • Fit the two Allen screws (7) which are located at the front of the seat support, and connect them with the crossmembers (4).
Page 100: Backrest Unit With Ergonomic Length Compensation (Easy-Adapt)
9.13 Backrest unit with ergonomic length compensation (Easy-Adapt) 9.13.1 Adjusting the width Note Please also refer to the previous chapter entitled "Adjusting the seat width". The seat can be adjusted in width between 380 and 530 mm as standard. Requirements: •...
Page 101 • Loosen the three Allen screws (1). Do not, however, remove these screws completely. • Push the plate (2) as far as required until the required width in cm can be read off the scale (3). • Tighten the three Allen screws again. •...
Page 102: Adjusting The Suspension And The Shock Absorbance
These adjustments should only be carried out by trained specialists. Please contact your authorised Invacare specialist dealer. Note It is easier to adjust the suspension and shock absorbance if there is no-one sitting in the chair.
Page 103: Disabling The Suspension And Shock Absorbance
9.14.2 Disabling the suspension and shock absorbance You can disable the suspension and shock absorbance so that they are no longer working. • Move the lever (A) from "Active" ("open lock" symbol, B) to "Inactive" ("closed lock" symbol, C). The suspension and shock absorbance are disabled.
Page 104 9.14.3 Adjusting the shock absorbance (Storm X-plore only) In the case of the Storm X-plore, the shock absorbance can be quickly and simply adjusted using a wheel on the springs: • If you set the shock absorbance harder, you get a more direct response to the ground for more sportive driving with a less swinging chassis.
Page 105 Adjusting the shock absorbance harder • Turn the wheel (A) to the plus sign, to set harder shock absorbance. 10 is the hardest level of shock absorbance. Adjusting the shock absorbance softer • Turn the wheel (A) to the minus sign, to set softer shock absorbance.
Page 106: Adjusting Or Removing The Luggage Carrier
9.15 Adjusting or removing the luggage carrier CAUTION! Risk of damage as a result of collisions! Parts of the electric wheelchair may be damaged if the luggage carrier collides with the seat during seat angle or backrest adjustment. • Ensure that the luggage carrier is out of the range of both seat angle and backrest adjustment.
Page 107: Using The Klickfix Adapter
Your wheelchair can be fitted with the mini-adapter from the Rixen + Kaul KLICKfix system. To this you can attach various accessories such as the cellphone case supplied by Invacare, which you can use to transport your cellphone, sports glasses etc.
Page 108 The adapter can turn in 90° steps, allowing you to attach an accessory from any of four different ® directions. Please refer to the installation instructions which are available from your Invacare ® dealer or directly from Invacare More information on the KLICKfix system is available at http://www.klickfix.com.
Page 109: Adjusting Footrests And Legrests
Adjusting footrests and legrests 10.1 Centre-mounted legrests 10.1.1 Electric legrest Please consult the user manual for your remote for information about electrical adjustment. The electric legrest can be lowered completely to assist getting out of the wheelchair. To do so, move your seat into the correct position by lowering the lifter or by means of a negative seat angle (tilted slightly to the front).
Page 110: Lowering The Electric Legrest Completely To Assist Getting Out Of The Wheelchair
10.1.1.1 Lowering the electric legrest completely to assist getting out of the wheelchair Warning! Misuse may destroy the legrest. • Please read and carefully follow the instructions below. Getting in/out of the wheelchair • Set the lifter and tilt to a comfortable position. •...
Page 111 Lifting up the footplates • You are sitting in the wheelchair. • Put your feet beside the footplates. • Pull the lever (1). The footplates rise up automatically. • Let go the lever (1) and put your feet on the footplates.
Page 112 Warning! Danger of damage to the legrest! • Always make sure that the footplates are fully raised to the uppermost position before adjusting the angle of the legrest! • Disregarding this advice will cause damage to your legrest. Adjusting the legrest •...
Page 113: Adjustable Legrest
10.1.2 Adjustable legrest 10.1.2.1 Adjusting the angle Prerequisites: • 1x 10 mm open-ended spanner • Use the open-ended spanner to loosen the counternut (1). • Move the legrest to the desired position by turning the spindle (2). • Tighten the counternut.
Page 114: Adjusting The Length Of The Legrest
10.1.2.2 Adjusting the length of the legrest Prerequisites: • 1x 5 mm socket head spanner • Use the socket head spanner to loosen the fastening screws (1). • Slide the foot support to the desired height. • Tighten the fastening screws.
Page 115: Adjusting The Calf Plate To The Calf Width Of The User
10.1.2.3 Adjusting the calf plate to the calf width of the user The calf plate of the legrest can be adapted to the user’s calf width by bending apart or together. • Bending the calf plate to the desired width.
Page 116: Adjusting The Angle Of The Foot Plate
10.1.2.4 Adjusting the angle of the foot plate Prerequisites: • 1x 5 mm socket head spanner • Fold up the foot plates in order to access the adjusting screws. • Use the socket head spanner to adjust the adjusting screws (1). •...
Page 117: Legrests Or Footrests Attached To The Side
10.2 Legrests or footrests attached to the side 10.2.1 Vari-F footrest 10.2.1.1 Swivelling the footrest outward and/or removing The small unlocking button is located on the upper section of the footrest. When the footrest is unlocked, it can be swivelled inward or outward when getting into the wheelchair as well as being removed completely.
Page 118: Setting The Angle
10.2.1.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Requirements: •...
Page 119 • Loosen the screw (1) using the Allen key. • Set the desired angle. • Re-tighten the screw.
Page 120: Setting The End Stop Of The Footrest
10.2.1.3 Setting the end stop of the footrest Pre-requisites: • 1x 6 mm Allen key • 1x 10 mm open-ended spanner The end position of the footrest is determined by means of a rubber stop (1). The rubber stop can be screwed in or out (A) or pushed up or down (B).
Page 121 • Use the Allen key to loosen the screw (1) and swivel the footrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
Page 122 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the screw.
Page 123: Adjusting The Length Of The Footrest
10.2.1.4 Adjusting the length of the footrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...
Page 124: Vari-A Legrests
10.2.2 Vari-A legrests 10.2.2.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.
Page 125: Setting The Angle
10.2.2.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! •...
Page 126 • Loosen the fixing mechanism by tapping lightly against the handscrew. • Set the required angle. • Retighten the handscrew (1) again.
Page 127: Setting The End Stop Of The Legrest
10.2.2.3 Setting the end stop of the legrest Pre-requisites: • 1x 10 mm open-ended spanner The end position of the legrest is determined by means of a rubber stop (A). The rubber stop can be screwed in or out (A) or pushed up or down (B).
Page 128 • Loosen the locking knob (1) counter-clockwise at least one turn. • Hit the knob to release the locking mechanism.
Page 129 • Swivel the legrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
Page 130 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the legrest to the desired position. • Re-tighten the locking knob.
Page 131: Adjusting The Length Of The Legrest
10.2.2.4 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...
Page 132: Adjusting The Depth Of The Calf Plate
10.2.2.5 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.
Page 133: Adjusting The Height Of The Calf Pad
10.2.2.6 Adjusting the height of the calf pad Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.
Page 134: Unlocking And Swivelling The Calf Plate Backward When Alighting
10.2.2.7 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.
Page 135: Adjusting The Angle Adjustable Foot Plate
• Lift leg over the heel strap and place on the ground. 10.2.2.8 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...
Page 136: Adjusting The Angle And Depth Adjustable Foot Plate
10.2.2.9 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...
Page 137: Ade Legrests
10.2.3 ADE legrests 10.2.3.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.
Page 138: Setting The Angle
10.2.3.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! The electrically height-adjustable legrests are operated using the remote.
Page 139: Adjusting The Length Of The Legrest
10.2.3.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...
Page 140: Adjusting The Depth Of The Calf Plate
10.2.3.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.
Page 141: Adjusting The Height Of The Calf Pad
10.2.3.5 Adjusting the height of the calf pad Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.
Page 142: Unlocking And Swivelling The Calf Plate Backward When Alighting
10.2.3.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.
Page 143: Adjusting The Angle Adjustable Foot Plate
• Lift leg over the heel strap and place on the ground. 10.2.3.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...
Page 144: Adjusting The Angle And Depth Adjustable Foot Plate
10.2.3.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...
Page 145: Angle-Adjustable Footboard
10.2.4 Angle-adjustable footboard Requirements: • Torx spanner T25 • Allen key 5 mm • Release the screws (1) with the Torx spanner and remove. • Adjust to required width. • Retighten the bolts. • Glue the anti-slip rubber mat to the footboard.
Page 146: Adjusting The Width Of Side-Mounted Legrests
• Loosen the locking screw(1) on both sides with the mm Allen key. • Adjust the footboard to the required angle. • Retighten the bolts. 10.2.5 Adjusting the width of side-mounted legrests Pre-requisites: • 13 mm open-ended spanner The screws that allow width adjustment of side-mounted legrests are located under the seat (1).
Page 147: Electrical System
NOTE A defective main fuse may be replaced only after checking the entire electric system. An Invacare® specialised dealer must perform the replacement. You can find information on the fuse type in chapter "Technical specifications" starting on page 186.
Page 148: Batteries
11.2 Batteries Power is supplied by two 12 V batteries. The batteries are maintenance-free and only need regular charging. In the following, you find information on how to charge, handle, transport, store, maintain, and use batteries. 11.2.1 Charging the batteries 11.2.1.1 General information on charging New batteries should always be fully charged once before their first use.
Page 149: How To Charge The Batteries
10 °C. • Use only charging devices in Class 2. This class of chargers may be left unattended during charging. All charging devices which are supplied by Invacare® comply with these requirements.
Page 150: How To Disconnect The Batteries After Charging
Risk of explosion and destruction of batteries if the wrong battery charger is used! • Only ever use the battery charger supplied with your vehicle, or a charger that has been approved by Invacare®. Risk of electric shock and damage to the battery charger if it gets wet! •...
Page 151: Storage And Maintenance
11.2.2 Storage and Maintenance Follow the instructions listed below to ensure safe use and longevity of the batteries: • Always store the batteries fully charged. • Do not leave the batteries in a low state of charge for an extended length of time. Charge a discharged battery as soon as possible.
Page 152 The last 3 LED (two red and one orange) mean a remaining capacity of about 15 %. • Driving with blinking red LED’s means an extreme stress for the battery and should be avoided under normal circumstances. • When only one red LED is blinking, the Battery Safe feature is enabled. From this time, speed and acceleration is reduced drastically.
Page 153: Transporting Batteries
• Under normal operation, once a month the battery should be discharged until all green and orange LED are off. This should be done within one day. A 16 hour charge afterwards is necessary as reconditioning. 11.2.4 Transporting batteries The batteries supplied with your electric vehicle are not hazardous goods. This classification is based on the German GGVS Hazardous Goods Road Transport Ordinances, and the IATA/DGR Hazardous Goods Rail Transport / Air Transport Ordinances.
Page 154 • Only ever transport damaged batteries in an appropriate acid-resistant receptacle. • Wash all objects that have come into contact with acid with lots of water. Disposing of dead or damaged batteries correctly Dead or damaged batteries can be given back to your dealer or directly to Invacare®.
Page 155: Maintenance
Maintenance encompasses different areas, such as everyday care and cleaning, inspection checks, repair tasks and refurbishment. NOTE: Have your vehicle checked once a year by an authorised Invacare® dealer in order to maintain it's driving safety and roadworthiness. 12.1...
Page 156: Inspection Checks
Invacare® dealer. Please refer to the service manual for this mobility device for an extensive list of inspections and instructions for upkeep.
Page 157: Before Each Use Of The Mobility Device
12.2.1 Before each use of the mobility device Component Inspection If inspection is not passed Horn • • Check of correct mode of operation. Notify dealer Lighting unit • Check of correct operating mode for all • Notify dealer lights such as indicators, headlights and rear lights.
Page 158: Weekly
12.2.2 Weekly Component Inspection If inspection is not passed Armrests /side • • Check to ensure that the Tighten the screw or camping lever panels armrests can be correctly to fix the armrests (see chapter inserted in the holders and "Adjustment possibility for control panel"...
Page 159: Monthly
12.2.3 Monthly Item Inspection check Action All upholstered parts • • Check for damage and wear. Contact your dealer. Removable legrests • • Check whether the legrests can be fixed Contact your dealer. securely and whether the loosening mechanism is properly operable (see chapter "Adjusting footrests and legrests"...
Page 160: Repair Instructions
"Technical specifications" on page 186, or consult the Service Manual, available from Invacare® (in this connection please see the addresses and phone numbers in section "How can you get in touch with Invacare®?" on page 3). In case you require assistance, please contact your Invacare® Dealer.
Page 161: Repairing A Flat Tyre (Front)
12.3.2 Repairing a flat tyre (front) Requirements: • Allen key 5 mm • Open-end spanner 24 mm • Repair kit for inner tubes or a new inner tube. • Talcum powder Remove the wheel • Jack the vehicle up and place a block of wood underneath it to prop it up.
Page 162 Repair the flat tyre EXPLOSION HAZARD! The wheel explodes if the air is not left out before dismantling! • It is imperative that you let the air out of the tyre before dismantling it (press the pin in the middle of the valve downwards)! •...
Page 163 • Place the rim halves in the tyre from the outside. • Pump up the tyre a little. • Re-position the Allen screws in the rim and tighten them firmly. Make sure the inner tube does not get pinched between the rims halves! •...
Page 164: Repairing Tyre Punctures (Drive Wheel)
12.3.3 Repairing tyre punctures (drive wheel) Injury hazard! If the wheel has been insufficiently tightened during assembly, it can become loosened during driving! • When reassembling the drive wheels, tighten the Allen screws at a torque of 30 Nm! • Secure all screws using a suitable blocker (e.g. Loctite 243)! Requirements: •...
Page 165 NOTE Re-assembly is done in reverse order. Ensure that the tyre is replaced on the same side and in the same travel direction as it was previously mounted. Repairing the flat tyre EXPLOSION HAZARD! The wheel will explode if you do not let the air out of the tyre before removing the wheel! •...
Page 166 • Insert the wheel rim halves from outside into the tyre. • Pump a little air into the inner tube. • Reinsert the cylinder head screws and tighten to10 Nm. Avoid crushing the inner tube! • Ensure that the tyre outer is seated correctly. •...
Page 167: Transport
Transport CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair.
Page 168: Transferring The Wheelchair To A Vehicle
13.1 Transferring the wheelchair to a vehicle WARNING: The wheelchair is in danger of tipping over if it is transferred to a vehicle while the driver is still seated in the wheelchair! • Transfer the wheelchair without the driver whenever possible! •...
Page 169: Use Of The Wheelchair As A Seat In A Vehicle
Web: www.unwin-safety.com • An alternative way to safely use this wheelchair as a vehicle seat may be by using the Docking Station system if the wheelchair is compatible with that system, available separately! Please contact Invacare if you require the details.
Page 170 Caution: There is a danger of injury if the wheelchair is not properly secured during use as a vehicle seat! • If possible, the user should always leave the wheelchair to use a vehicle seat and the safety belts provided with the vehicle. •...
Page 171 (UK for example), but may also be obtained from Invacare® as an option in other countries. This power wheelchair complies with the requirements of ISO 7176-19:2001 and may be used as a vehicle seat in connection with an anchoring system that has been checked and approved in accordance with ISO 10542.
Page 172: How The Wheelchair Is Anchored In A Vehicle For Use As A Vehicle Seat
13.2.1 How the wheelchair is anchored in a vehicle for use as a vehicle seat The power wheelchair is fitted with four anchoring points, which are labelled with the symbol shown on the right. Snap hooks or belt loops can be used for fixation.
Page 173: How The User Is Secured Within The Wheelchair
13.2.2 How the user is secured within the wheelchair CAUTION: There is a danger of injury if the user is not properly secured within the wheelchair! • Even if the wheelchair is fitted with a postural belt, this is no substitute for a proper safety belt which complies with ISO 10542 in the transport vehicle.
Page 174 This can cause the neck to be hyperextended during collisions! • A headrest must be installed! The headrest optionally supplied for this mobility device by Invacare® is perfectly suitable for use during transport. • The headrest must be adjusted to the user's ear height.
Page 175 Seat belts may not be held at a distance The pelvic belt should be positioned in the from the user's body using parts of the area between the user's pelvis and thighs wheelchair such as armrests or wheels. so that it is unobstructed and not too loose. The ideal angle of the pelvic belt to the horizontal is between 45°...
Page 176 The safety belt installed in the transporting vehicle should be applied as shown in the illustration at right. 1) Centre line of the body 2) Centre of the sternum...
Page 177: Securing The Wheelchair For Transport Without Passengers
CAUTION: Injury hazard! ® • If you are unable to fasten your electric wheelchair securely in a transport vehicle, Invacare recommends that you do not transport it! • Before transporting your wheelchair, make sure the motors are engaged and that the Joystick Box is switched off.
Page 178: Opening The Rear Cover
13.3.1 Opening the rear cover (Storm 4, Storm 4 Max) Removing the rear cover: • Loosen and remove the two knurled screws (1) on the left and right side of the rear casing. • Lift the rear cover carefully. The front part of the cover is held at the top by a Velcro strip. This must also be released.
Page 179: Making The Batteries Accessible
Fitting the rear cover: • Fit the parts in the reverse order. • Tighten the two knurled screws by hand. 13.3.2 Making the batteries accessible WARNING! Fire and burn hazard due to short circuit at battery poles! • DO NOT short-circuit the battery poles with a tool or metal parts of the wheelchair! •...
Page 180 • Remove the rear cover as described in chapter 13.3.1 • Pull the snap fitting (1) beside the power module backwards. • Lift the power module with the holder and remove the mounting from the battery cap flap. • Place the power module and the mounting on top of the battery compartment or actuator module, if applicable.
Page 182: Removing/Installing The Batteries
13.3.3 Removing/Installing the batteries Requirements: • 11-mm socket spanner Removing the batteries: • Make the batteries accessible as described in chapter 13.3.2 • Remove the pole caps (1) from the accessible battery (3). • Remove the pole screws located under the pole caps using an 11-mm socket spanner. •...
Page 183 • Lift the battery from the battery carrier. • Pull the second battery forward using its strap. • Disconnect the cables of the second battery as well. • Lift the second battery from the battery carrier. Fitting the batteries: • Fit the batteries in the reverse order. •...
Page 184: Refurbishment
• Cleaning and disinfection. Please see chapter "Maintenance" on page 155. • Inspection according to service plan. Please consult service instructions, available from Invacare®. • Adaptation to the user. Please see chapter "Adjusting the wheelchair to the user's seating posture" on page 49.
Page 185: Disposal
• Electric components and printed circuit boards are disposed of as electronic scrap. • Exhausted or damaged batteries can be returned to your medical equipment supplier or Invacare®. • Disposal must be carried out in accordance with the respective national legal provisions.
Page 186: Technical Specifications
Technical specifications The technical information provided hereafter applies to a standard configuration or represents maximum achievable values. These can change if accessories are added. The precise changes to these values are detailed in the sections for the respective accessories. Permissible operating and storage conditions Temperature range for operation according to ISO 7176-9: •...
Page 187 Drive wheel tyres Tyre pressure The recommended maximum tyre pressure in bar or kpa is marked on the side wall of the tyre or the rim. If more than one value is listed, the lower one in the corresponding units applies. (Tolerance = -0.3 bar,1 bar = 100 kpa) Castor wheel tyres Tyre type...
Page 188 Dimensions Standard Easy-Adapt Matrx Total height • 970 mm • 1050 mm • 970 mm Drive unit width • 630 - 770 mm Total length (incl. standard legrests) • 1190 mm Total length (without standard legrests) • 910 mm Seat height *** (with lifter) •...
Page 189 Dimensions RECARO Optimist Modulite Total length (without • 910 mm • ca. 910 mm • 910 mm ******* standard legrests) Seat height *** (with • 400 - 650 mm (Storm lifter) • 440 - 690 mm (Storm X-plore) Seat height *** (without •...
Page 190 *** Measured without seat cushion **** The actual kerb weight depends on the fittings your mobility aid has been supplied with. Every Invacare® mobility aid is weighed when leaving the works. Please refer to the nameplate for the kerb weight (including batteries) measured.
Page 191: Inspections Performed
It is confirmed by stamp and signature that all jobs listed in the inspection schedule of the Service and Repair Instructions have been properly performed. The list of the inspection jobs to be performed can be found in the Service Manual which is available through Invacare®. Delivery Inspection...

Invacare Storm4 X-plore User Manual

1 Introduction

2 Safety Notes

3 Key Features

4 The Position of the Labels on the Product

5 Getting in and out of the Wheelchair

6 Driving

7 Pushing the Mobility Device in Freewheel Mode

8 Remotes

9 Adjusting the Wheelchair to the User's Seating Posture

10 Adjusting Footrests and Legrests

11 Electrical System

12 Maintenance

13 Transport

14 Refurbishment

15 Disposal

16 Technical Specifications

17 Inspections Performed

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Invacare Storm4 X-plore

Summary of Contents for Invacare Storm4 X-plore
