Eaton Cooper Power Series Assembly/Installation Instructions

Eaton Cooper Power Series Assembly/Installation Instructions

Separable splice connector, deadbreak apparatus connectors
Hide thumbs Also See for Cooper Power Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual, Manual
Deadbreak Apparatus
Connectors
MN650005EN
600 A 15/25 kV class BOL-T™ and separable splice connector assembly
installation instructions
Effective February 2015
Supersedes S600-10-2 July 2014
COOPER POWER
SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cooper Power Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton Cooper Power Series

Summary of Contents for Eaton Cooper Power Series

  • Page 1 COOPER POWER Deadbreak Apparatus Connectors SERIES Effective February 2015 MN650005EN Supersedes S600-10-2 July 2014 600 A 15/25 kV class BOL-T™ and separable splice connector assembly installation instructions...
  • Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other- wise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to damage or...

  • Page 3: Table Of Contents

    Contents SAFETY INFORMATION Safety Information ................iv PRODUCT INFORMATION Introduction .

  • Page 4: Safety Information

    FOR LIFE FOR LIFE Eaton meets or exceeds all applicable industry standards relating to product safety in its Cooper Power™ series products. We actively promote safe practices in the use and maintenance of our products through our service literature, instructional training programs, and the continuous efforts of all Eaton employees involved in product design, manufacture, marketing, and service.

  • Page 5: Product Information

    Cable Adapter shielded, submersible, and meet the requirements of IEEE Std 386™-2006 standard – “Separable Insulated Connector Systems” . 600 A deadbreak connectors from Eaton are fully interchangeable with all other manufacturers that also Neutral Wire certify compliance with IEEE Std 386™-2006 standard.

  • Page 6: Equipment Required

    Installation of connectors IMPORTANT Installation Instructions to be used for 600 A, 15/25 kV Class BOL-T connector with shear bolt connector. Please Shear bolt installation procedures see page 7 for installation instructions using a compression (For compression connector procedures, see page 7) connector.
  • Page 7 Table 1. Shear Bolt Connector Cable Conductor Size Shear Bolt Connector AWG or kcmil Centering Ring & Compact Compressed Concentric Standard Sizes Color Conductor Code Catalog Number Grey CDT630SB150 Black None Black White CDT630SB300 None None CDT630SB400 Table 2. Shear Bolt Stripback Dimensions Connector Code Allen Wrench (mm)
  • Page 8 Step 2. Step 4. Remove concentric neutral wires or jacket Put tape marker in place Measure 1" (25 mm) from end of insulation shield. (Refer ote: Care should be taken to not cut or score the • to Figure 5.) neutral conductors when cutting the cable jacket.
  • Page 9 Step 7. Clean insulation ote: Do not apply solvent directly to cable. Clean insulation thoroughly with solvent dampened rag, Cable • Insulation wiping from conductor end toward insulation shield. Major OD (Refer to Figure 8.) flared out bulge Ensure that all traces of conductive residue are re moved. •...
  • Page 10 Step 9. Install shear bolt connector "E" ote: Refer to the separate installation instructions See Table 2 supplied with the shear bolt connector. Shear Bolt Connector Install centering ring. • Refer to Figure 11 and Table 1 to determine what size •...

  • Page 11: Compression Connector Procedure

    Compression connector installation procedures Cable preparation Step 1 Equipment provided Train cable BOL-T Connector Assembly Kit including: • Position cable vertically so that it is centered between • T-body apparatus bushing and parking pocket, parallel to, and 6" • Cable Adapter (152 mm) from apparatus frontplate.
  • Page 12 Step 2. Step 4. Remove concentric neutral wires or jacket Put tape marker in place Measure 1" (25 mm) from end of insulation shield. (Refer ote: Care should be taken to not cut or score the • to Figure 16.) neutral conductors when cutting the cable jacket.
  • Page 13 Step 7. Clean insulation ote: Do not apply solvent directly to cable. Clean insulation thoroughly with solvent dampened rag, Cable • Insulation wiping from conductor end toward insulation shield. Major OD (Refer to Figure 19.) flared out Ensure that all traces of conductive residue are re moved. bulge •...
  • Page 14 Step 9. Step 10. Install compression connector Check di men sions Check length from end of com pres sion con nec tor to top ote: Refer to the chart supplied with the crimp • of cable adapter. connector for tool and die to be used. Length should be be tween 6.50-7 .25"...

  • Page 15: Installation Of Bol -T Connector Onto Apparatus Bushing

    Install BOL-T T-body with mating parts Step 11. Install DT625 T-body Clean and lubricate outside of cable adapter with lubricant • supplied. Clean and lubricate inside of T-body with lubricant • supplied. ote: If test point T-body is used, insure test point is opposite front plate side of T-body.

  • Page 16: Completing T-Body Termination

    Completing T-body termination Install BOL-T connector onto apparatus bushing Step 13. Step 12. Install T-body onto apparatus bushing Install STUD into apparatus bushing Clean and lubricate mating interfaces of apparatus • bushing and T-body with lubricant supplied. ote: Use only the symmetrical aluminum (STUD-A) or copper (STUD-C) stud in separable splice and BOL -T Push T-body onto apparatus bushing ensuring that the •...
  • Page 17 Step 14. Step 15. Install insulating plug Check tightness of termination Clean and lubricate the mating interfaces of T-body and Check tightness by hand by moving T-body forward and • • insulating plug. back (perpendicular to the apparatus frontplate). Do not move side to side as this may loosen the connection.

  • Page 18: Separable Splice Assembly Instructions

    Separable Splice Assembly Instructions Step 17. ote: Use only the symmetrical aluminum (STUD-A) or Ground system copper (STUD-C) stud in BOL -T separable splice Connect one concentric neutral wire to drain wire tab of • applications. Do not use the copper alloy non- the T-body or use a separate uninsulated copper wire symmetrical extended length T-OP II (STUD-T) stud.
  • Page 19 Repeat the previous assembly procedures for each • In su lat ing Plug additional splice tap. (Refer to Figure 32.) Connecting Plug Connecting Plug After the last connecting plug and T-body are installed, • 1" Wrench 5/16" Hex obtain the second insulating plug. If stud has not Shaft been factory installed, hand thread a 5/8"...
  • Page 20 © 2015 Eaton IEEE Std 386™-2006 standard is a All Rights Reserved trademark of the Institute of Electrical and For Eaton's Cooper Power series BOL -T Electronics Engineers, Inc., (IEEE). This connector product information call Printed in USA 1-877-277-4636 or visit: Publication No.
