Eaton Cooper Power Series Installation Instructions

Deadbreak Connector
Catalog Data
CA650019EN
600 A 15 kV class PUSH-OP™
insulated adapter cap
Effective April 2015
Supersedes 600-19 January 1990
COOPER POWER
General
Eaton's Cooper Power™ series 600 A, 15 kV Class
PUSH-OP™ adapter cap is a factory assembled
LRTP and T-body with a stainless steel shroud
and tin-plated copper probe. It meets all the
requirements of IEEE Std 386™-2006 standard,
Separable Connector Sys tems.
The PUSH-OP adapter cap has a non-bolted
connection that eliminates any need for threading
and its associated problems.
The device is used to cap a 600 A PUSH-OP type
bushing tap inter face with the 200 A loadbreak
interface allowing for live testing and visible
grounding. The 200 A tap is three-phase switch ing
and three-phase fault close rated. Used with a
200 A insulated pro tec tive cap, Eaton's Cooper
Power series M.O.V.E. arrester or ground ing
elbow, a PUSH-OP adapter cap provides a fully
shielded, sub mers ible unit.
Installation
The PUSH-OP adapter cap is installed on a
de-energized 600 A special PUSH-OP bushing
inter face using a clampstick. Refer to Service
Information S600-19-1 600 A 15, 25, and 35 kV
Class PUSH-OP Bushing Adapter Cap Installation
Instructions for details. Installation of the factory
assembled LRTP and T-body to the 600 A
PUSH-OP bushing requires no threading.
Production tests
Tests are conducted in accordance with IEEE Std
386™-2006 standard.
ac 60 Hz 1 Minute Withstand
•
34 kV
•
Minimum Corona Voltage Level
•
11 kV
•
Tests are conducted in accordance with Eaton
requirements.
Physical In spec tion
•
Periodic Dissection
•
Periodic Fluoroscopic Analysis
•
