POWER-UP

At power-up, the following appears on the LCD:
Firmware Revision 5.67 or Higher
Electronics Revision
It takes 2 seconds for these messages to be displayed, during which time the output of the
flowmeter is clamped at zero flow. After 2 seconds, the output signal starts indicating actual
flow.

LCD READOUT

If the flowmeter is configured for High-Speed (HS) response, the LCD only shows "run". No
other parameters can be viewed on the LCD in this mode.
LCD in HS mode:
In Low-Speed (LS) (see Select Response Time) the user can toggle the readout between flow
rate, total, pressure, and temperature. When in Run mode, use A2 pushbutton to select. The
selection is stored in the internal memory, so if power is removed from the flowmeter it
remembers the selection next time it is powered up.
Note: The output signal and alarms always indicate "flow rate".
FSMAN.6 081214 Page 14
