Flow Rate

Available with:
Not Available with:
In Run Mode:
1. Press A2 (or press and release a few times) until "rATE" is displayed.
2. Release A2. The flowmeter will display Flow Rate.

Totalizer

Available with:
Not Available with:
Note: In order to view the Totalizer, it must first be "Started" in the User Menu (see
ON/OFF).
1. The first time A2 is pressed, "rATE" is displayed as shown above, to indicate the current
selection. Press A2 again until "tot" is displayed.
2. Release A2.
FSMAN.6 081214
All models in Low-
Speed mode
High-Speed mode
Low-Speed
Single-Gas
Multi-Gas
4-20mA
0-5V (1-5V)
0-10V (2-10V)
0-1000 Hz
Battery-operated
200-1200 Hz
Pulse output
Bi-directional
Press until "rATE"
shown then release
Press until "tot" shown
then release
Totalizer
