Set High Flow Alarm

Available with:
Not Available with:
1. Press A1 until "HFLo" is displayed, then release A1.
2. Press A2 and hold until the setpoint is displayed on the LCD (in this example, high flow
alarm is set at 80.0). Then release A2. The first digit starts blinking.
3. Use A1 to change the blinking digit. The setpoint is changed one digit at a time. A1
increments each individual digit (9 rolls over back to 0), while A2 is used for recording
the new digit value and selecting the next digit.
4. Use A2 to record the new value and select the second
digit.
5. After the last digit is set, continue holding A2 until "SEt" is displayed. If you want to
change the first digit again, do not hold A2. Momentarily press and release A2 and the
first digit starts blinking again.
6. When finished recording the new setpoint ("SEt" is displayed), release A2.
FSMAN.6 081214
High-Speed
Low-Speed
Single-Gas
Multi-Gas
4-20mA
0-5V (1-5V)
0-10V (2-10V)
0-1000 Hz
200-1200 Hz
Pulse output
Battery-operated
Bi-directional
Press and release
Press and hold
Press and release to
change the value
Press to record the
new value
Press and hold after the last digit
Page 26
