SATO MB200/201i Operator's Manual

SATO MB200/201i Operator's Manual

Sato direct thermal printer operator's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M B 2 0 0 / 2 0 1
i
D i r e c t T h e r m a l
P r i n t e r
Operator's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB200/201i and is the answer not in the manual?

Questions and answers

Related Manuals for SATO MB200/201i

Summary of Contents for SATO MB200/201i

  • Page 1 M B 2 0 0 / 2 0 1 D i r e c t T h e r m a l P r i n t e r Operator’s Manual...
  • Page 2 SATO Asia Pacific Pte. Ltd. The materials in this document is provided for general information and is subject to change without notice. SATO Asia Pacific Pte. Ltd. assumes no responsibilities for any errors that may appear.

  • Page 3: Safety Precautions

    Safety Precautions As a preventive measure to ensure safe usage of this machine so as to safeguard against damage to yourself, other people or property, there are many display diagrams used in this instruction manual and on this machine. The displays and their meanings are illustrated in the following pages.

  • Page 4: Explanation Of Hazard Symbols

    Safety Precautions Explanation of hazard symbols The triangle sign means ‘Be careful’. The content within the triangle illustrates specific hazards. In this case, the sign on the left means ‘beware of electric shock’. The circular sign means ‘prohibited’. The content within the circle illustrates a specific prohibition.

  • Page 5: Warnings

    Warnings Liquids Do not place any liquids or small metallic objects near the printer. Should any of these fall into the printer, immediately turn off the power and contact your nearest dealer or service center. Continued use increases the risk of fire or electric shocks.

  • Page 6: Abnormal Conditions

    Warning Warnings Abnormal Conditions Continued use of the printer while it is emitting smoke or strange odors increases the risk of fire or electric shocks. Immediately turn off the power and contact your nearest dealer or service center. Do not try to service the printer by yourself.
  • Page 7 • Never modify, excessively bend, twist, or pull the power cord. Continued use of the printer in any of the above situations can lead to increased risks of fire or electric shocks. Warning...

  • Page 8: Cautions

    Location Do not locate the printer in the area subjected to high humidity or dew. If dew forms inside the printer, immediately turn off the printer and do not use it until all moisture has dried up. Continued use creates the danger of electric shock or the printer damage.

  • Page 9: Replacing The Battery Pack

    Long periods of non usage If you have no plan to use the print for a long time, remove the battery pack from the printer and unplug the AC adapter from the wall outlet. Maintenance and Cleaning...

  • Page 10: Other Precautions

    Other Precautions Avoid placement in extreme temperatures Do not place the printer in highly humid areas or at outside the -15°C to 50°C temperature range. When the printer is being transported... The normal vibration encountered during transportation is acceptable, but avoid dropping the printer or exposing it to extreme vibrations.

  • Page 11: Table Of Contents

    Part Names ... 2-2 Functions of various parts ... 2-4 Charging the battery pack with a charger... 2-5 Charging the battery pack with the printer... 2-7 Using the battery pack ... 2-8 Using the optional AC Adapter for power... 2-10 O p e r a t i o n a n d C o n f i g u r a t i o n .
  • Page 12 I n t e r f a c e S p e c i f i c a t i o n s ..... . . 4 - 1 C l e a n i n g a n d M a i n t e n a n c e .

  • Page 13: I N T R O D U C T I O N

    • Durable and rugged design • Supports media up to 67 mm in width • Supports the Mobile Programming Language or Sato Basic Programming Language of the MB200 Please read this manual* carefully to make full use of this product.

  • Page 14: Notes On Bluetooth/Wireless Communication

    Introduction Notes on Bluetooth/Wireless Communication Compliance Statement This product has been certified for compliance with the relevant radio interference regulations of your country or region. To ensure continued compliance, do not: • Disassemble or modify this product • Remove the certificate label (serial number seal) af- fixed to this product Use of this product near microwave and/or other wire- less LAN equipment, or where static electricity or radio...

  • Page 15: S E T U P

    If any component shown here is missing, contact your nearest dealer or service center. Notes: The printer is shipped with an integrated belt holder. Cushioning material may vary for different regions. An external battery charger is available separately but is a standard item in the Starter kit.

  • Page 16: Part Names

    Setup Part Names...
  • Page 17 Setup Part Names (cont’d)

  • Page 18: Functions Of Various Parts

    Offline Status LED Indicates the status of the printer. (See pages 3-13,3-14, 6-1 and 6-2) Belt clip Suspends the printer on a belt, to allow greater mobility * Do not hang the printer on to anything but a belt...

  • Page 19: Charging The Battery Pack With A Charger

    Charging the battery pack with a charger If your printer comes with the optional battery charger, you can use it to charge the supplied battery pack. Follow the steps below: 1. Connect the charger to the wall outlet and turn on the power.

  • Page 20: Charging Time

    Setup Notes: • If the POWER lamp does not light when you turn on the power, check the power cord connection. • If the CHARGE lamp does not light at the start of charging, make sure the battery pack is firmly mounted into the charger.

  • Page 21: Charging The Battery Pack With The Printer

    When the battery pack is fully charged, the battery indicator goes off. In the case of the MB200/201i Wireless LAN interface model, the CHARGE LED on the LCD screen lights red when charging starts, and goes off when charging is complete.

  • Page 22: Using The Battery Pack

    Setup Using the battery pack Turn the printer off before removing or replacing the battery. Insertion 1. Unlatch the battery compartment cover. 2. Align the battery pack so that its metal terminals are facing forward. Insert the battery pack while pressing and holding the gray hook.
  • Page 23 Using the battery pack (cont’d) Notes Remove the battery pack only when the STATUS LED is OFF. When the printer is turned off, the STATUS LED goes off. Do not remove the battery while the STATUS LED is on. Otherwise, the...

  • Page 24: Using The Optional Ac Adapter For Power

    POWER lamp on the adapter lights green. Notes: Be sure to turn the printer power off when removing the DC output terminal of AC adapter or disconnecting the power source. Otherwise, the information stored in the printer may not be updated.
  • Page 25 A battery pack is unnecessary when an AC adapter is used. If a battery pack and an AC adapter are being used at the same time, the printer will attempt to charge the battery pack (if it is not already fully charged).
  • Page 26 Cover Open/Close lever downwards to release the cover. 2. Place the label roll into the printer. Make sure the label roll is placed with the first label feeding from the bottom of the roll and not from the top (see picture).
  • Page 27 4. Close the cover after confirming that the leading edge of the label is outside the printer. This completes the label installation for continuous mode operation. Setup 2-13...
  • Page 28 Setup Installing the label roll (cont’d) For operating in the Dispense mode, the following label loading procedures apply. 1. Make sure you can see the red platen roller. If not, slide the dispenser unit down, by lifting its top edge upwards at the two arrow marks.
  • Page 29 Installing the label roll (cont’d) 3. Insert the label roll into the printer. Make sure the first label emerges from the bottom (not top) of the roll. 4. Lift up the label guide adjust dial cover and turn the dial till the label guides press loosely against label roll.
  • Page 30 Setup Installing the label roll (cont’d) 3. Close the cover after confirming that the leading edge of the label is outside the printer by at least 10mm. * When using non- separate labels, press the FEED button to feed a piece of label and pull the label upward to cut it along the perforation.

  • Page 31: Operation And Configuration

    O P E R A T I O N A N D C O N F I G U R A T I O N After setting up the printer and label roll in Section 2, you can now operate the printer properly.

  • Page 32: Performing A Test Print

    Make sure the printer is running on AC or on a full battery during a test print. Notes: If any fault is detected, contact your SATO dealer or service center. Before asking for a repair, please read the Troubleshooting section of this manual.

  • Page 33: Printing Via The Rs-232C Interface

    Make sure that the arrow mark on the connector of the RS- 232C cable matches with the arrow mark by the side of the printer’s port. 3. Plug the other end of the RS-232C cable to the corresponding RS-232C connector of the computer or handy terminal.

  • Page 34: Printing Via The Irda Interface

    Printing via the IrDA Interface Use the following procedure to print through IrDA interface. 1. Place the printer 20 cm away from the IrDA port of the computer or handy terminal. Adjust the printer position so that the center of its IrDA filter projects a 30°...

  • Page 35: Printing Via The Wireless Lan Interface

    Printing via the Wireless LAN Interface To print using the Wireless LAN MB200/201i, you need to have a properly configured wireless LAN set up. The next step is to configure the MB200/201i to share the same network settings in order to establish communication.

  • Page 36: Printing Via The Bluetooth Interface

    Refer to the instruction manual of the computing device for details on how to set these parameters. For the MB200/201i, these parameters can be set by a SATO-certified System Integrator/dealer, or by using Bluetooth communication software available from your SATO dealer or service center.

  • Page 37: Optional Lcd Screen

    Optional LCD screen The Wireless LAN version of the printer is factory- fitted with a Liquid Crystal Display (LCD). The screen can display the following information: Dispense Mode Manual/Auto status Battery MANU strength ONLINE Two-line text QTY:0000 display Battery strength: Three-segment indicator. When all segments are lit, voltage level is greater than 8.0 V.
  • Page 38 Operation and Configuration Optional LCD screen (cont’d) Two-line text display: Displays the following: 1) Various status messages: Firmware version, Online mode, Offline mode, labels remaining in print queue, Test Print status, Default Setting, Complete, Factory Clear, Press Feed Key, Press Print Key, Hex Dump Mode, Set up Display, Adjust LCD, Exit, Contrast, Back Light On 2) Warning messages: Cover Open, Paper End,...

  • Page 39: Printing Procedure

    Notes • The number of sheets you can print is determined by the printer’s mode (continuous or peel mode). • When printing non-separate labels and you have torn the labels at a wrong place, stop the printing and follow the instructions on the next page to correct the print job.

  • Page 40: Adjusting Printing For Non-Separate Labels

    1. Interrupt printing on the computer, or by pressing the PRINT key in the ONLINE state to take the printer OFFLINE. (STATUS LED goes off). 2. Press the FEED button to feed a label. When the feeding stops, tear off the...

  • Page 41: Choosing The Label Dispensing Mode

    Choosing the Label Dispensing mode You can choose to dispense labels in Continuous Mode and Dispense Mode. In either mode, test printing and online printing are available. You can select Dispense mode for non-separate labels by using the printer setting tool. 3-11...

  • Page 42: Configuring Dispense Mode

    To switch between Auto or Manual Print for the Dispense Mode, set the DIP switches and then hold down the PRINT or FEED button when turning the printer ON. The new settings take effect when the printer is next turned ON. Setting Auto Print dispense mode:...

  • Page 43: Other Printer Modes

    Note: The Battery indicator (only available on the Bluetooth/WLAN model) remains lit even when the printer is OFFLINE. During the Standby state, the printer resumes normal operational status upon sensing any incoming data or pressing of the buttons. Operation and Configuration...

  • Page 44: Test Print Mode

    Operation and Configuration Printer modes (cont’d) Test Print Mode Enter Test Print mode as shown, by using the FEED and POWER buttons. STATUS LED behaviour in Test Print Mode Operational State ENTERING TEST PRINT MODE START OF TEST PRINT DURING TEST PRINT...

  • Page 45: Head Check Setting Mode

    “Performing a Test Print” on page 2. When setting the Head Check options, the STATUS LED blinks green, and turns into a steady green signal upon completion of setting. Turn off the printer ONLY when the STATUS LED is a steady green light. Operation and Configuration...
  • Page 46 “Performing a Test Print” on page 2. When setting the online command compatibility options, the STATUS LED blinks green, and turns into a steady green signal upon completion of setting. Turn off the printer ONLY when the STATUS LED is a steady green light. 3-16 DSW-2...

  • Page 47: Offset Configuration Via Programming

    Offset Configuration via Programming The following offset adjustments for the MB200/201i printer are usually unnecessary. Almost all adjustments are electrical in nature due to the printer’s advanced self aligning and balancing design features. However, if you need to perform the adjustments, they can be sent as commands to the printer.
  • Page 48 Operation and Configuration POSITION ADJUSTMENTS Pitch Offset Use the <PO3> programming command. Dispense Offset Use the <PO1> programming command. Tear-Off Offset Use the <PO2> programming command. 3-18 Takes effect instantly; the value is cleared once the power is turned off. Takes effect instantly;...

  • Page 49: I N T E R F A C E S P E C I F I C A T I O N S

    S P E C I F I C A T I O N S Through a combination of DIP switch settings and turning the printer ON with certain buttons held down, you can enable or disable special functions/features. DIP Switch Power ON with Cover Open, Print button held down, FEED button held down –...
  • Page 50 Interface Specifications RS-232C settings Power ON with Cover Closed, PRINT button not held down, FEED button not held down –RS-232C Normal mode Power ON with Cover Closed, PRINT button not held down, FEED button held down – RS-232C User test print mode Power ON with Cover Open, PRINT button held down, FEED button not held down –...

  • Page 51: Printing A Hex Dump

    Bluetooth/WLAN Settings Power ON with Cover Closed, PRINT button not held down, FEED button not held down – Normal operation mode Power ON with Cover Closed, PRINT button not held down, FEED button held down – Test Print mode Power ON with Cover Open, Print button not held down, FEED button held down –...
  • Page 52 Note: Some hosts monitor the Request-To-Send (RTS) signal (pin 4 of 25) to determine if the printer is ready to receive data. Since the printer does not generate this signal, the RTS line must be held true (high) in order to allow communication.

  • Page 53: C L E A N I N G A N D M A I N T E N A N C E

    C L E A N I N G A N D M A I N T E N A N C E By cleaning and maintaining the printer regularly, you will prolong its durability and reliability, and also reduce the inconvenience of unnecessary malfunctions.

  • Page 54: Cleaning The Platen And Peel Roller

    Cleaning and Maintenance Cleaning the Platen and Peel Roller Users can perform test prints to evaluate the print quality and also diagnose problems. Slide the Cover Open/ Close lever to release the cover. If the lever is not accessible, first slide the dispenser unit away by lifting the top edge where the arrow marks are located.

  • Page 55: Troubleshooting

    1. Clean the print head 2. Replace the print head 1. Retry with different label paper. Use only SATO-certified media for best print quality and minimal problems 2. Clean the platen and peel roller (See Section 5: “Cleaning and Mainte- nance”)
  • Page 56 Head over- (Green->off- modes heat >Red->off) protection every 1s feature * Contact your nearest dealer or SATO representative for support Cause Remedy Battery charge level is low. Recharge the battery Interface module error Replace the board (Bluetooth, wireless LAN) Flash ROM read/write...
  • Page 57 Troubleshooting WARNING: NEVER CONNECT OR DISCONNECT INTER- FACE CABLES (OR USE A SWITCH BOX) WITH POWER APPLIED TO EITHER THE PRINTER OR THE HOST. THIS MAY CAUSE DAMAGE TO THE INTERFACE CIRCUITRY AND IS NOT COVERED BY WARRANTY.
  • Page 58 Troubleshooting...

  • Page 59: Basic Specifications

    Basic Specifications & Optional Accessories B A S I C S P E C I F I C A T I O N S & O P T I O N A L A C C E S S O R I E S Basic Specifications Attribute Printing system...
  • Page 60 Label printing modes Self-diagnosis Power saving features 0.064 ~ 0.190 mm (use only SATO- certified paper). Roll paper: Wound with surface out Maximum diameter: 57.5 mm Width: 25.4 to 55 mm (28.4 to 57.5 Pitch: 13 to 160 mm (16 to 163 67 mm (2.63”) outer diameter...
  • Page 61 Reflection type (eye mark), Transmission type (gap) 1 to 6 times 0°, 90°, 180°, 270° SATO standard font: XU, XS, XM, XL, OCR-A, OCR-B, POP charac- ter Kanji: 16 x 16, 22 x 22, 24 x 24 Square Gothic (JIS Level 1, Level...
  • Page 62 Basic Specifications & Optional Accessories Barcode Two-dimensional code Switches Indicators Application standards Protective feature JAN8/13, UPC-E/UPC-A, NW-7, CODE39, CODE93, CODE128, INTERLEAVED2of5, POSTNET, RSS-14. However, barcode shall be used with the following. Parallel barcode: Thin bar width of 2 dots or more Serial barcode: Thin bar width of 3 dots or more Any one of PDF417 (ver 2.4), QR code (ver 8.1 including micro QR),...
  • Page 63 Basic Specifications & Optional Accessories Waterproof feature Environmental condition (including battery pack)* *Does not apply to label media Options Notes: 1. Before using a wireless interface with this equipment, make sure that any radio transmission/ reception equipment onsite, do not share the same frequency range as this product’s wireless setup.
  • Page 64 Basic Specifications & Optional Accessories measure to prevent interference (e.g., installing partitions). MB200/200i Radio Frequency characteristics 2.4FH1 Freq band used Modulation system Assumed distance of interference Availability of fre- quency change 2.4 GHz Frequency Hopped - Spread Spectrum system 10 mm max. All area is used and exclu- sion of the band for equip- ment for mobile object...

  • Page 65: Optional Accessories

    Basic Specifications & Optional Accessories Optional Accessories The MB200/201i direct thermal printer is supported by a wide range of accessories to increase its flexibility. Battery Items Spare battery pack—having a spare pack reduces interruption during extended periods of printer operation.

  • Page 66: Portability Enhancements

    Basic Specifications & Optional Accessories Optional Accessories Portability enhancements Belt Hook—allows users to attach or detach the printer for the waist belt easily. Single-slot Battery Charger— use this to charge a battery pack without using the printer connected to an AC outlet.
  • Page 67 Basic Specifications & Optional Accessories Optional Accessories Portability enhancements Shoulder Belt—allows users to hang the printer from the shoulder. Installation: Pass the shoulder belt through the belt hole of the printer from the outside in. Pass one end of the shoulder belt through the buckle and adjust the length.
  • Page 68 Installation: Pinch the Rainproof case with the belt clip of the printer. If the Rainproof case is not pinched with the belt clip correctly, the printer may fall off. 7-10...
  • Page 69 Installation: Pinch the Waist case with the belt clip of the printer. If the Waist case is not pinched by the belt clip correctly, the printer may fall off. 7-11...

  • Page 70: Connectivity Options

    Bluetooth Interface—allows printing via a Bluetooth connection. The interface comes with an LCD on the front panel to display the status of Bluetooth communication. For more details about the optional accessories, consult your authorized SATO representative. 7-12...
