SATO MB200 Parts List

SATO MB200 Parts List

Direct thermal printer
Hide thumbs Also See for MB200:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

See also: Operator's Manual , User Manual
MB200
Direct Thermal Printer
PARTS LIST
PN 9001119A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SATO MB200

Summary of Contents for SATO MB200

  • Page 1: Parts List

    MB200 Direct Thermal Printer PARTS LIST PN 9001119A...
  • Page 2 THE ABOVE MENTIONED NAMES MAY BE FOUND IN THE “PART DESCRIPTION” COLUMN OF THE TABLES WITHIN THIS DOCUMENT. THIS DOCUMENT IS PROVIDED FOR GENERAL IN FORMATION AND IS SUBJECT TO CHANGE WITHOUT NOTICE. SATO AMERICA, INC. MAY NOT BE HELD REPSONSIBLE FOR ERRORS THAT MAY APPEAR. WARNING THE EQUIPMENT REFERENCED IN THIS DOCUMENT COMPLIES WITH THE REQUIREMENTS IN PART 15 OF FCC RULES FOR A CLASS B COMPUTING DEVICE.
  • Page 3 MH1200522 P-TIGHT SCREW, FLAT HEAD *The purchase of item 3 is required if replacing item 2. **The purchase of item 9 is required if replacing Item 8. SATO MB200 Parts List PART DESCRIPTION Figure PL1, Front Cover Assembly PN 9001119A...
  • Page 4 DISP PR SPRING (FEED ROLLER SPRING) PH0A30401 TOP CABINET (TOP HOUSING COVER) MH0200522 P-TIGHT SCREW, PAN HEAD RH1A30302 DISPENSER SENSOR PT9A30200 SPACER Figure PL2, Right Housing Cover Assembly SATO MB200 Parts List PART DESCRIPTION BASECOVERASSY24 BASECOVERASSY PN 9001119A FRONTCOVERASSY Page 2...
  • Page 5 HEAD AJUST BUSH (PRINT HEAD BUSHING) PC1A32110 PRINT BALANCE SPRING PR2A30000 BELT CLIP PE1A32101 CLIP BUSH (CLIP SHAFT CAPS) P00804000 CLIP SPRING PB0A30901 CLIP SHAFT RH1A30401 PRINT HEAD OPEN SWITCH RH1A30202 GAP SENSOR ASSEMBLY SATO MB200 Parts List PART DESCRIPTION PN 9001119A Page 3...
  • Page 6 ITEM PART NUMBER RH1A30100 BATTERY CABLE ASSEMBLY PE1A32810 FPC COVER (BATTERY CONNECTOR COVER) SATO MB200 Parts List PART DESCRIPTION Figure PL3, Print & Chassis Assemblies PN 9001119A Page 4...
  • Page 7 LABEL GUIDE (MEDIA GUIDE, LEFT) PE1A31400 GUIDE STOPPER MH0200522 P-TIGHT SCREW, PAN HEAD PE2A30100 MEDIA COLLAR PE1A32700 LOCK HOLDER (LATCH) MH1200522 P-TIGHT SCREW, FLAT HEAD PB0A31300 HINGE SHAFT (HINGE PIN) RJ4A30200 SENSOR ASSEMBLY SATO MB200 Parts List PART DESCRIPTION PN 9001119A Page 5...
  • Page 8 Figure PL4, Top Cover Assembly SATO MB200 Parts List PN 9001119A Page 6...
