ASSEMBLY
1.To protect your heater from strong winds, it is best to anchor the base securely to the ground. There
are two methods you may use to secure the base.
OPTION A (for solid ground such as concrete):
Using the holes in the base as a template, drill
4 - 12.5-13mm diameter holes (1/2") that are
at least 300mm (4") deep. Fig .1
Then insert the expandable bolts (4 pcs) into
the holes. Fig. 2
Slide the base down over the expandable
bolts. Fig. 3
Affix the base to the expandable bolts using
the M8 nut / washers. Fig. 4
Hardware Used: 4- M8xll0 expandable bolts, 4 - M8 nut / washer
OPTION B (for soft ground such as soil):
Set the base in the desired location. Insert anchoring
pin through hole in base and using a rubber mallet tap
the anchoring pin into the soil. Fig.1
Repeat with the other 3 - anchoring pins to secure
the base to the soil. Fig.2
Hardware Used: 4 - Anchoring Pins
