OUTDOOR PATIO HEATER
INSTRUCTION MANUAL
FOR OUTDOOR USE ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR REFERENCE
e-mail: customercare@jrhome.com
WARNING: For outdoor use only.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately
call gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapours or liquids
in the vicinity of this or any other
appliance.
For cus tomer service, parts
or warranty issues:
Call 1-800-561-5550
or e-mail customercare@jrhome.com
Establishing a burner ignition for
the FIRST time or after changing
the cylinder tank may take up to
2-3 minutes in order for the gas
to purge through the feeder lines.
1
Item#：PH-S-129-SS
Model#：YBT-VH01
Advertisement
Related Manuals for Paramount Fitness YBT-VH01
Summary of Contents for Paramount Fitness YBT-VH01
- Page 1 Item#：PH-S-129-SS Model#：YBT-VH01 OUTDOOR PATIO HEATER INSTRUCTION MANUAL WARNING: For outdoor use only. FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odour continues, immediately call gas supplier. FOR YOUR SAFETY...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ** WARNING ** Contents Page 2 Improper operation, installation, adjustment, alteration, servicing or maintenance cause severe Before You Begin Page 2 property damage and /or serious damage and /or General Description Page 3 serious injury or death. Please read the installation, operating and maintenance instructions thoroughly Security and Caution Page 4... -
Page 3: General Description
GENERAL DESCRIPTION This appliance is a propane portable heater. The burner is controlled and adjusted by the gas control knob. Gas supply is controlled by the valve on the gas cylinder. The burner is made of stainless steel. Heat diffusion is assisted by the reflector. -
Page 4: Security And Caution
SECURITY AND CAUTION FOR YOUR SAFETY If you smell gas : Close gas supply at cylinder valve b. Extinguish all open flames c. Proceed to p e r f o r m a leak test with a soapy water solution (50% soap/ 50% water) If bubbles are detected, retighten connections. -
Page 5: Tools And Accessories
TOOLS AND ACCESSORIES CAUTION • DO NOT operate the heater in an explosive environment Keep this appliance away from areas where you have stored gas or other vapors and flammable liquids. • Before use verify that no parts are damaged, inspect gas hose. •... - Page 6 TOOLS AND ACCESSORIES PREPARATION Before beginning assembly of this appliance, make sure all parts are present. Compare all parts with package contents list and hardware contents as listed on page 5 of this manual. If any part is missing or damaged, do not attempt to assemble this product.
- Page 7 ASSEMBLY AND INSTRUCTIONS 3/16" 3/16" Fix 3 vertical support to the base with 3 xM8*16 bolts. M8x 16 3/16"x5/8" Fasten post to the vertical supports. with 6 bolts M6 X 35 and 6 nuts M6. And slide cylinder cover thru the post on M6 x 35 the base Before assembling the burner head on...
- Page 8 ASSEMBLY AND INSTRUCTIONS M6 x 10 Slide hose through bottom of post and connect to burner head, be sure it’s fixed properly by wrench to avoid any gas leakage. Then fasten burner on post with 4 bolts M6x10mm. Fasten it properly. Sectional reflector ONLY Assemble the reflector pieces to the middle piece with wing nuts and bolts.
- Page 9 ASSEMBLY AND INSTRUCTIONS Install a full gas cylinder on the base. Connect the gas regulator hose to the QCC1 Cylinder valve by turning the knob clockwise manually. Do not use a tool, tighten firmly by hand. Replace cylinder cover. LEAK TEST Now that the heater is assembled, for your safety you must perform a leak test of all connections and hoses.
-
Page 10: Care And Maintenance
OPERATION TO LIGHT： 1. From‘OFF’position, depress knob, turn 90° counter-clockwise and hold. 2. Press the igniter until flame is established. 3. Release the knob and check that the flame stays lit. 4. If the flame goes out, wait 5 minutes then repeat steps 1 & 2 above. 5. - Page 11 OPERATIONS FOR YOUR SAFETY Be careful when attempting to manually ignite this heater. Holding in the control knob for more than 10 seconds before igniting the gas may cause a ball of flame upon ignition. When heater is ON: Emitter screen will become bright red due to intense heat. The color is more visible at night.
-
Page 12: Troubleshooting
TROUBLE SHOOTING TROUBLE SHOOTING GUIDE If you are having this If this condition exists: You will need to do the following: problem Open valve at cylinder. Turn cylinder 1. Cylinder valve may be OFF. valve in counter-clockwise direction. Refill LPG tank 2. - Page 13 STORAGE AND MAINTENANCE CUSTOMER SERVICE ATTENTION : Consumer ... Please use the customer information listed below for any questions concerning assembly, care information, warranty issues and/or replacement parts. To ensure your satisfaction and maintain high standards for quality and workmanship, we want to hear from you should you have any questions or comments.
- Page 14 IMPORTANT For questions, concerns or problems with our product please email our customer service department: customercare@jrhome.com DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment. If a part (excluding light bulbs and fuses*) within one year from the date of purchase proves to be defective in material or fabrication under normal use, the part will be repaired or replaced.
