NATURAL GAS PATIO HEATER
INSTRUCTION MANUAL
5000199
FOR OUTDOOR USE ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR REFERENCE
Item# ：
Model# ：
For customer service, parts
or warranty issues:
Call 1-800-561-5550 or email
customercare@jrhome.com
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, keep away from
appliance and immediately call your gas
supplier or fire department
WARNING
Do not store or use gasoline or other
flammable vapours or liquids in the
vicinity of this or any other appliance.
NOTE: Please retain these instructions
for future use
WARNING: For outdoor use only
FOR OUTDOOR USE ONLY | USES NATURAL GAS ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
Made in China
PH-NG103
KLD7002S,KLD7002SS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KLD7002S and is the answer not in the manual?

Questions and answers

Related Manuals for Paramount Fitness KLD7002S

Summary of Contents for Paramount Fitness KLD7002S

  • Page 1 Item# ： PH-NG103 Model# ： KLD7002S,KLD7002SS NATURAL GAS PATIO HEATER INSTRUCTION MANUAL For customer service, parts or warranty issues: Call 1-800-561-5550 or email customercare@jrhome.com DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame.

  • Page 2: For Outdoor Use Only

    FOR OUTDOOR USE ONLY WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. NOTE： Operating pressure:7.0'' W.C. Do not use if the environment temperature is below 40 degrees F / 4.4 degrees C.

  • Page 3: Check For Leaks

    All leak tests should be done with a soapy solution. NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS. At least once a year, the unit should be inspected for the presence of spiders, spider webs or other insects. CHECK THE HEATER IMMEDIATELY IF ANY OF THE FOLLOWING EXIST: 1.

  • Page 4: Tools And Accessories

    TOO LS A N D A CCESSORIES PART DESCRI PTI ON Reflector Panel 4 pcs Reflector Center Cap Head Assembly Main Post 1 (attached to Gas Hose Head Assembly) Lower Post Base Cover Tools needed: 2SHQ HQG ZUHQFK  PP LQFOXGHG NOT included: $GMXVWDEOH RSHQLQJ ZUHQFK ¶¶...
  • Page 5 ASSEMBLY 1.To protect your heater from strong winds, it is best to anchor the base securely to the ground. There are two methods you may use to secure the base. OPTION A (for solid ground such as concrete): Using the holes in the base as a template, drill 4 - 12.5-13mm diameter holes (1/2") that are at least 300mm (4") deep.
  • Page 6 ASSE M BL Y 2. Slide the base cover (H) over the lower post (F) and base (G). 3.Screw the 2 pcs of main post together.
  • Page 7 5. Route natural gas hose (E) down into main/lower post assembly (D) by first removing the large end of the quick connector, the yellow cap and safety papers. Note: there is a small piece of protective foam located in the neck of the heat assembly that MUST be removed prior to attaching head assembly to the upper post.
  • Page 8 7. While supporting heater, tilt the head assembly (C) and slide the assembled reflector over the 3 bolts that extend from the head assembly. Use 3 M8 wing nuts and 3 M8 washers to secure the assembled reflector to the head assembly of the heater.
  • Page 9 A minimum supply pressure of 7" W.C. is required for the purpose of input adjustment of natural gas. Storage of an appliance indoors is permissible only if the source is disconnected and removed from the appliance. A gas source must be stored outdoors in a well-ventilated area out of the reach of children. A disconnected gas source must have dust caps tightly installed and must not be stored in a building, garage, or any other enclosed area.

  • Page 10: Carbon Monoxide Hazard

    3. A leak is detected at regulator/gas source valve connection, disconnect, reconnect, and perform another leak test. If you continue to see bubbles after several attempts, call our customer service hotline. IF NO BUBBLES APPEAR AT ANY CONNECTION, THE CONNECTIONS ARE SECURE. Note: Whenever gas connections are loosened or removed, you must perform a complete leak test.

  • Page 11: For Your Safety

    7. Wait at least 5 minutes before attempting to re-light the heater. 8. Turn the natural gas source valve to OFF or closed. If you experience any ignition problems, please consult “Troubleshooting” on page 14. Caution: Avoid inhaling fumes emitted from the heaters first use. Smoke and odor from the burning of oils used in the manufacturing will appear.
  • Page 12 Operation Checklist: For a safe and pleasurable heating experience, perform this check before each use: Before Operating: 1. I am familiar with entire owner's manual and understand all precautions noted. 2. All components are properly assembled, intact and operable. 3. No alterations have been made. 4.
  • Page 13 WARNING FOR YOUR SAFETY *Do NOT touch or move heater for at least 45 minutes after use. *Reflector is hot to the touch. *Allow reflector to cool before touching. To enjoy years of outstanding performance from your heater, make sure you perform the following maintenance activities on a regular basis: Keep exterior surfaces clean.
  • Page 14 If you have any questions regarding this product, please call our customer service hotline.

  • Page 15: Warranty

    IMPORTANT For questions, concerns or problems with our product please email our customer service department: customercare@jrhome.com or call 1-800-561-5550. DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE. WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment.
