PATIO HEATER INSTRUCTION MANUAL
5000199
Item # LIP-10-TGG-HS,L10-SS-PP,
PH-S-112-MK,L10-SS-BK P
Model # KLD7002S,KLD7002SS
For customer service, parts
or warranty issues:
Call 1-800-561-5550 or e-mail
customercare@jrhome.com
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, keep away from
appliance and immediately call your gas
supplier or firedepartment
WARNING
Do not store or use gasoline or other
flammable vapours or liquids in the
vicinity of this or any other appliance.
An LP-Cylinder not connected for use
shall not be stored in the vicinity of this
or any other applience
NOTE: Please retain these instructions
for future use
WARNING: For outdoor use only
FOR OUTDOOR USE ONLY | USES PROPANE LPG ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
Made in China
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Paramount Fitness KLD7002S
Summary of Contents for Paramount Fitness KLD7002S
- Page 1 PATIO HEATER INSTRUCTION MANUAL Item # LIP-10-TGG-HS,L10-SS-PP, PH-S-112-MK,L10-SS-BK P Model # KLD7002S,KLD7002SS For customer service, parts or warranty issues: Call 1-800-561-5550 or e-mail customercare@jrhome.com DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame.
-
Page 2: Tools And Parts Needed For Assembly
Tools and parts needed for assembly DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odour. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. - Page 3 PRECAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES WARNING: This heater must only be used outdoors. Using this product in an enclosed area may cause injury, death or property damage. Only use in a well-ventilated space. Do not use in a building, garage, or any other enclosed area.
- Page 4 PRECAUTIONS CHECK THE HEATER IMMEDIATELY IF ANY OF THE FOLLOWING EXIST: 1. The smell of gas in conjunction with extreme yellow colored tips of the burner flames. 2. The heater does not reach temperature. 3. The burner makes a popping noise during use (a slight popping noise is normal when the burner is extinguished after using).
- Page 5 ASSEMBLY Reflector 4 outer pcs and 1 center cap Gas Hose 1 pc (attached to head assembly) Post Assembly 2 pcs LPG Cylinder Holder Anchoring Arms/Pins 1 pc (hardware is pre-assembled Wheel Assembly to wheel assembly) M4x10 screw x 4pcs M6 flange nut x 12pcs M8x16 washer x 6pcs M6x12 screw x 10pcs...
- Page 6 ASSEMBLY ATTACHING WHEEL ASSEMBLY Step 1 1-1. Locate Wheel Assembly (17) and 2 nuts/bolts Fig. 1 contained in plastic bag with Wheel Assembly (Fig. 1). Step 2 2-1. Turn Base (15) so that holes for attachment of Fig. 2 Wheel Assembly are facing you (Fig. 2). 2-2.
- Page 7 M6 Flange nut 3 - M8x12 screws,3 - M8 nuts M8x45...
- Page 8 ASSEMBLY Attach the upper pole with the lower pole using 4 - M4x10mm screws...
- Page 9 ASSEMBLY...
- Page 10 ASSEMBLY M8 x 16...
-
Page 11: Check For Leaks
ASSEMBLY Check for Leaks Your patio heater has been checked at all factory connections for leaks, but you should always check when you attach the LPG cylinder. To check for leaks, following these instructions: --Assemble all gas connections; --Connect regulator assembly to the propane tank; --Make sure the heater valve is turned OFF. - Page 12 ASSEMBLY If bubbles still appear, close the propane tank valve and contact your gas supplier. If a leak is detected , DO NOT attempt to use the heater. MAKE SURE to check all THREE connections between the cylinder and gas line. NOTE: 1) The cylinder must be provided with a shut off valve terminating in a LPG supply cylinder valve outlet specified, as applicable, for connection NO 510...
-
Page 13: Before Turning Gas Supply On
ASSEMBLY C. Spoon several drops (or use squirt bottle) of the solution onto gas hose connection and connection. D. Inspect the connections and look for bubbles. E. If no bubbles appear, the connection is safe. F. If bubbles appear, there is a leak. Close the propane tank valve and loosen and re-tighten this connection. -
Page 14: Lighting Instructions
OPERATION LIGHTING INSTRUCTIONS TO TURN ON THE HEATER: 1. Turn the control knob “OFF” position. 2. Open gas valve fully. 3. Press and turn the control knob to “HI” position (counterclockwise 90°). Press down the control knob and hold for 3-5 seconds. - Page 15 OPERATION CAUTON: Avoid inhaling fumes emitted from the heater’s first use. Smoke and odor from the burning of oils used in manufacturing will appear. Both smoke and odor will dissipate after approximately 30 minutes. The heater should not produce thick black smoke. Note: The burner may be noisy when initially turned on.
- Page 16 LOCATION OF HEATER WHILE IN USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is to be used for the heating of outdoor patios, decks, spas, pool, and open working areas.
-
Page 17: Cleaning And Maintenance
MAINTENANCE WARNING CLEANING AND MAINTENANCE FOR YOUR SAFETY DO NOT touch or move To enjoy years of outstanding performance from your heater for at least 45 heater, make sure you perform the following maintenance minutes after use. on a regular basis: Allow all burner elements to cool before touching. -
Page 18: Troubleshooting
TROUBLESHOOTING Problem Cause solution Burner will not light Pressure is low Fuel tank is near empty Control valve not ON Turn valve to ON mode Thermocouple bad Replace thermocouple Light assembly bent Place in proper position or not in correct location and retry Burner flame is low The main gas house is... - Page 19 IMPORTANT For questions, concerns or problems with our product please email our customer service department: customercare@jrhome.com or call 1-800-561-5550. DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE. WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment.
