2 Getting Started Quickly

This section is intended to provide information how to set up quickly the
INT-COM-1300. More details and advanced features are described in further
sections.

2.1 Unpacking

The INT-COM-1300 Common Path OCT Interferometer consists of the following
items:
• INT-COM-1300 Common Path OCT Interferometer
• Power supply (±12V, 0.2A), 110V or 230V line voltage
• Operation manual
Please check prior to operation, if the indicated line voltage range on the
power supply matches with your local mains voltage!
If you want to use your own power supply, you can ask Thorlabs for an

2.2 Setup

• Carefully unpack the unit and accessories. If any damage is noticed, do not
use the unit. Call Thorlabs and have us replace the defective unit.
• If necessary, mount the unit on your optical table or application. The unit has
four tapped 6-32 mounting holes (see section 3.5 for details).
• Plug the power connector cable into the DC INPUT.
• Plug the power supply into a 50-60Hz, 100-120VAC outlet (220V-240VAC for
EC version).
• Use coaxial cables with SMA connectors for OUTPUT.
NOTE
NOTE
appropriate power connector cable.
