3.4 Detector Responsivity

INT-COM-1300 uses InGaAs PIN photodiodes. Figure 6 shows a typical responsivity
curve for this photodiode type.
This wavelength dependency affects the output signal amplitude. In order to
compensate this responsivity, the measured electrical signal must be multiplied by
the normalized wavelength dependent responsivity.
1,0
0,8
0,6
0,4
0,2
0,0
800 1000
Wavelength (nm)
Figure 6: INT-COM-1300 detector responsivity
1200 1400 1600
3 Detailed Description
1800
