PC28 A10
PC29 A11
PC30 A12
PC31 A13
Table 5-4. PIO Port D pin assignments and signal descriptions.
IO line Peripheral A
PD0 GTXCK/GREFCK
PD1 GTXEN
PD2 GTX0
PD3 GTX1
PD4 GCRSDV/GRXDV
PD5 GRX0
PD6 GRX1
PD7 GRXER
PD8 GMDC
PD9 GMDIO
PD10 GCRS
PD11 GRX2
PD12 GRX3
PD13 GCOL
PD14 GRXCK
PD15 GTX2
PD16 GTX3
PD17 GTXER
PD18 NCS1
PD19 NCS3
PD20 PWMH0
PD21 PWMH1
PD22 PWMH2
PD23 PWMH3
PD24 PWML0
PD25 PWML1
PD26 PWML2
PD27 PWML3
PD28
PD29
PD30
PD31
Table 5-5. PIO Port E pin assignments and signal descriptions.
IO line Peripheral A
PE0
PE1
PE2
PE3
PE4
TCLK4
TIOA5
TIOB5
TCLK5
Peripheral B Peripheral C
Peripheral B Peripheral C
AFE0_AD9
AFE0_AD10
AFE0_AD11
Peripheral D Extra
function
Peripheral D Extra
function
AFE0_BNC
AFE0_BNC
SYSIO Comments
and GPIO
MII_TXCK
MII_TXEN
MII_TX0
MII_TX1
MII_RXDV
MII_RX0
MII_RX1
MII_RXER
ETH_MDC
ETH_MDIO
MII_CRS
MII_RX2
MII_RX3
MII_COL
MII_RXCK
MII_TX2
MII_TX3
LCD_CS
LED_PWM (Amber)
LED_PWM (Green)
LED_PWR (RED)
SD_PWR_CTL
ETH_INTR
SYSIO Comments
and GPIO
CAN0_Rs
CAN0_EN
CAN1_Rs
CAN1_EN
QTouch_CHANGE#
