MicroNet SP659B Quick Installation Manual

Configuration
You can access this switch by RS-232 console port or by
Internet Browser over the network.
Console User Interface
To access via console port, you should attach RS-232 cable to
the serial port of a PC running a terminal emulation program,
just as HyperTerminal. And, then setup the operating mode of
console port with:
• Connection using: COM1/COM2
• Baud Rate (bps): 9600
• Date Bits: 8
• Parity Checking: None
• Stop Bits: 1
• Flow Control: None
When the management interface in text mode appears, you
should key in the UserName/password (admin/admin, by
default) before you start to configure.
Web-based User Interface
Users can access the switch by web browser over Internet.
Default system information is shown below:
• IP address: 192.168.1.1 Mask: 255.255.255.0
• Login User Name and Password: admin/admin
Before you configure this device, make sure the manager PC
must be set on the same IP network as 192.168.1.X and the
default subnet mask is 255.255.255.0.
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, the essential protection
requirement of Council Directive 89/336/EEC on the
approximation of the laws of the Member States relating to
electromagnetic compatibility.
Company has an on-going policy of upgrading its products and
it may be possible that information in this document is not up-
to-date. Please check with your local distributors for the latest
information. No part of this document can be copied or
reproduced in any form without written consent from the
company.
Trademarks:
All trade names and trademarks are the properties of their
respective companies.
Copyright © 2005, All Rights Reserved
5
P/N: 2300-0356
7
Specifications
Standard
Interface
Cable Connections
Network Speed
Filtering/Forwarding
Rate10Mb
Uplink
Switch Fabric
Features
Emission
Operating Temperature
Operating Humidity
Dimension
Power Supply
Quick Installation Guide
EtherFast 10/100M Smart Switch
Model No.: SP659B
Web: www.micronet.com.tw
IEEE802.3, IEEE802.3u,
IEEE802.3ab, IEEE802.3x,
IEEE802.1p
24* 10/100M RJ-45 ports
2* 10/100/1000M RJ-45 ports
1* RS-232 Console port
10BASE-T: Category 3, 4, 5
UTP/STP
100BASE-TX: Category 5
UTP/STP
1000BASE-T: Category 5, 5e
UTP/STP
10/100/1000M Auto-negotiation
10M: 14,880pps/14,880pps
100M: 148,800pps/148,800pps
1000M: 1,488,100pps
Auto Uplink (Auto MDI / MDI-X)
8.8Gbps
Port trunking, VLAN, QOS,
bandwidth control, auto discovery
FCC, CE
o o o o
0 - 40 C (32 - 104 F)
10% - 90% (Non-condensing)
441 x 130 x 44 mm
100 ~ 240V AC, 50/60Hz
Full range internal power supply
6
