Page 10
ENGLISH
SFTM22-1.5 AND SFTM24-2.0 PERFORMANCE
45
40
35
30
25
20
15
10
5
0
0
5.4 CHANGING THE FILTER SAND
Filter sand will need to be removed from the multiport
valve opening.
1. Loosen bolts from clamp.
2. Remove clamp.
3. Remove Multiport Valve.
4. Use a wet/dry vacuum or similar suction device to vacuum old
sand from filter tank.

5.5 WINTERIZING

Turn off the pump.
1. Move the Multiport valve handle to "Winter".
2. Remove any drain plugs from the filter.

SECTION 6. DIMENSIONS AND REPLACEMENT PARTS

6.1 APPROXIMATE DIMENSIONS

Ø22"
(558mm)
33"
(844mm)
SFTM22-1.5
4"
(98mm)
Jandy
Pro Series Sand Filter SFTM22-1.5, SFTM24-2.0
®
10
20
30
40
36"
(910 mm)
31"
(783mm)
19"
(483mm)
50
60
70
80
FLOW - GPM
5. Keep enough water in filter tank to keep sand in a semi fluid
"slurry" state
6. Using steps from "4.4 Fill With Sand" on page 6 replace the
sand in the filter.
Be sure to dispose of used fi lter sand appropriately. Used fi lter sand is not
appropriate for human or pet contact
3. Vent the filter by removing the pressure gauge or disconnecting
one of the unions.
4. Drain system piping of all water.
5. Cover the system with a tarpaulin or plastic sheet to protect
from the weather.
35.75"
(908mm)
38.75"
(984mm)
4"
(106mm)
|
Installation & Operation Manual
SFTM24-2.0 FLOW
SFTM22-1.5 FLOW
90
100
WARNING
41.85"
(1.06m)
SFTM24-2.0
19"
(483mm)
Ø23.75"
(603mm)
