The settings for <Printer> can be changed as follows:
- Select value you want to change and confirm with <Enter>
- Make the desired adjustment with the arrow keys
- Confirm with <Enter>
The setting for <Store> can be changed as follows:
- Select value you want to change and confirm with <Enter>
- Activate the memory function with <F1> or deactivate it with <F4>
Press <Start measurement> / <Enter> to start the
evaluation of the measurement values. On the dis-
play, the actual average values will be shown and
will be updated as new measurements come in. You
can switch to the actual values with the arrow keys
<up/down>. You can also scroll through the values
with the arrow keys <right/left>. You can interrupt
the measurement with <F2> or stop it completely
with <F4>.
After the measurement time has elapsed, you can print the results
containing all average values (only instruments with printer - key
<Print>).
Ecom-D
O2 3.2 %
CO2 13.1 %
CO 0 ppm
Eff. 92.5 %
Losses 7.5 %
Exc. air 1.18
T.Gas 184 °C
T.Air 20 °C
Mean value
15:35min
