Ecom -D Operating Instructions Manual page 12

Search word: It is also possible to search for a specific saved record,
if you know the file number.
Select "Search word" and confirm with <Enter>. Using the software
keyboard, type in at least 3 characters of the file number.
Example: "25.09" for file number 25.09.2009
Next, press <F1> to start the search. All files match-
ing this number will be shown. The results can be
scrolled using the arrow keys (F1 for the first file, F2
for the last). Once found, you can view the desired
data file with <Enter>. The last measurement on
this in this file can be viewed pressing <Enter> /
<View memory> / <Enter>. All measured and cal-
culated values can are viewed on 5 display pages,
using the arrow keys to scroll between pages.
Memory number 1
25.09.2009
O2 value in air
19.5
O2
CO
0.01
Draught
O2 value in air 12:15 25.09.09
Memory number 1
Press <ESC> to leave measurement data and the recording of the
current data can begin.
Page 12
