Customizing and Generating the Core
This chapter includes information on using Xilinx tools to customize and generate the core
using the Vivado™ Design Suite. For more information about the Vivado Design Suite, see
the Vivado Design Suite - 2012.4 User Guides web page.

GUI

The core is configured to meet the developer's specific needs before instantiation through
the Vivado design tools Graphical User Interface (GUI). This section provides a quick
reference to parameters that can be configured at generation time.
X-Ref Target - Figure 4-1
LogiCORE IP SMPTE2022‐5/6 RX v2.1
PG033 December 18, 2012
Figure 4‐1: Vivado tools Graphical User Interface
