Xilinx LogiCORE IP Product Manual page 14

Table 2‐7: Resource Utilization for Zynq‐7000 Families
SDI Channel
Number
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
LogiCORE IP SMPTE2022‐5/6 RX v2.1
PG033 December 18, 2012
FEC Include FFs
0 8116
0 10921
0 13709
0 16476
0 19262
0 22032
0 24804
0 27564
1 11759
1 15056
1 18363
1 21612
1 24870
1 28110
1 31361
1 34600
www.xilinx.com
Chapter 2: Product Specification
LUT‐FF
LUTs Slices pairs
7486 3176 9743
9312 3749 12169
11033 4801 15232
11754 5576 17739
14129 6926 21252
15227 7801 24393
17671 9020 27021
17097 9324 29141
10269 4102 13105
12607 5144 16558
15006 6749 20614
16147 7913 23625
19289 9099 27607
20785 10282 31695
23657 12021 35388
23442 12694 38136
36k 18k
BRAMs BRAMs
14 2
21 3
28 4
35 5
42 6
49 7
56 8
63 9
44 6
51 9
72 12
79 15
114 23
121 21
128 24
135 27
14
