Chapter 2. Using the Memory Starter Kit

This chapter describes the Memory Starter Kit functionality and how to:

• Connect the board to the PC

• Select a Device, Write and Read
• Use the Endurance Utility
• Change the Voltage and SPI Mode
2.1 CONNECT THE BOARD TO THE PC
To run the Memory Starter Kit take these basic steps:
1. Power up the starter kit by connecting the board to the USB port of a computer.
2. Start the MPLAB program and select the Memory Starter Kit from the "Tools"
2.2 SELECT A DEVICE, WRITE AND READ
Once you have the board connected, select a device:
• Go to the Configure tool bar and the Select Device window will open. Select
"SEExxx" from the Device Family pull-down menu if it is not already selected.
• Next, Select the memory device from the Devices menu.
• Now you are ready to use the Memory Starter Kit.
• Install the device into the 16-pin socket on the board. Be sure to place all
Microwire devices in the upper half of the socket, all other devices including SPI,
2
I C, and UNI/O bus parts will go into the bottom half of the socket.
• Read or write to the device by using the Read and Write icons on the top of the
GUI. These buttons work in conjunction with the "Read/Write options" pull-downs
on the upper left. You can write a pattern or the buffer contents to the array. Select
Entire Device or Selected Range for either writing or reading. Check the pull-down
menus before reading or writing to get the desired operation.
2.3 USE THE ENDURANCE UTILITY
The Memory Starter Kit includes a utility that will allow you to test the endurance of any
of the serial memory products that Microchip offers. By clicking on the Endurance
button, you may select a user defined pattern or select from one of the patterns
provided. When writing you have the ability to continuously write, read in between
cycles, or even alternate data patterns. The endurance utility will automatically stop
whenever a failure occurs.
