MPLAB Starter Kit for Serial Memory Products User's Guide
1.2

OPERATIONAL REQUIREMENTS

To communicate with and program the MPLAB Starter Kit for Serial Memory Products,
the following hardware and software requirements must be met:
• PC compatible system
• An available USB port on PC or powered USB hub
• CD-ROM drive
• Windows
Operating Systems
* Only initial testing has been performed on 32-bit Vista for this release. 64-bit
Vista is not supported at this time.
1.3

BOARD SETUP

Figure 1-1 is a drawing of a set up MPLAB Starter Kit for Serial Memory Products. The
USB connection provides communication and power to the board.
FIGURE 1-1:
DS22087B-page 8
®
2000 SP4, Windows XP SP2, and Windows Vista™ (32-Bit)*
MPLAB STARTER KIT FOR SERIAL MEMORY PRODUCTS
SETUP
USB
Memory Starter Kit
®
MPLAB IDE
