FIG.D
FIG.E
PCV
FIG.F
18-023
Unplug
Stk
www.powercommander.com
8
Unplug the stock wiring harness from the ignition coil (Fig. D).
This is a BLACK, 2 pin connector on the right hand side.
9
Plug the PCV in-line of the stock wiring harness and stock ignition coil (Fig. E)
10 Unplug the stock Throttle Position Sensor connector (Fig. F).
This is a BLACK, 6 pin connector on the RH side of the throttle body.
11 Plug the PCV in-line of the stock TPS and wiring harness.
17-18 RC/Duke 390 - PCV - 4
