Dynojet Power Commander V Installation Instructions Manual

For yamaha fz-07 2015; yamaha fz-07 2016; yamaha fz-07 2017; yamaha fz-07 2018; yamaha mt-07 2015; yamaha mt-07 2016; yamaha mt-07 2017; yamaha mt-07 2018
Hide thumbs Also See for Power Commander V:
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
FUEL AND IGNITION
2015-2018 Yamaha FZ-07 / MT-07
I n s t a l l a t i o n I n s t r u c t i o n s
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
22-065
www.powercommander.com
2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
PARTS LIST
1
Power Commander
1
USB Cable
1
Installation Guide
2
Power Commander Decals
2
Dynojet Decals
3
Velcro strips
1
Alcohol swab
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
THE LATEST POWER COMMANDER
SOFTWARE AND MAP FILES CAN BE
DOWNLOADED FROM OUR WEB SITE AT:
www.powercommander.com
15-18 Yamaha FZ-07/MT-07 - PCV F/I - 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Power Commander V and is the answer not in the manual?

Questions and answers

Related Manuals for Dynojet Power Commander V

Summary of Contents for Dynojet Power Commander V

  • Page 1 Power Commander USB Cable Installation Guide FUEL AND IGNITION Power Commander Decals Dynojet Decals 2015-2018 Yamaha FZ-07 / MT-07 Velcro strips I n s t a l l a t i o n I n s t r u c t i o n s Alcohol swab THE IGNITION MUST BE TURNED...

  • Page 2: Usb Connection

    POWER COMMANDER V INPUT ACCESSORY GUIDE ACCESSORY INPUTS Map - (Input 1 or 2) The PCV has the ability to hold 2 different base maps. You can switch on the fly between these two base maps when you hook up a switch to the MAP inputs. You can USB CONNECTION use any open/close type switch. The polarity of the wires is not important. When using the Autotune kit one position will hold a base map and the other position will let you activate the learning mode. When the switch is “CLOSED” Autotune will be activated. (Set to Switch Input #1 by default.) Shifter- (Input 1 or 2) These inputs are for use with the Dynojet quickshifter. Insert the wires from the CRANK Dynojet quickshifter into the SHIFTER inputs. ANALOG The polarity of the wires is not important. (Set to Switch Input #2 by default.) SPEED EXPANSION PORTS 1 & 2 INPUT 2 (Grnd)
  • Page 3 FIG.A Remove Remove both seats, both side panels, the bodywork surrounding the fuel tank, the panel between the seats, and the plastic panel above the right footpeg (Fig. A). Remove the fuel tank. Remove FIG.B Store the PCV module in the tail section beneath the passenger seat (tool kit area). The supplied Velcro strips can be used to secure the module. Clean both surfaces with the supplied alcohol swab prior to applying the Velcro adhesive. Route the PCV wiring harness forward along the right side frame rail (Fig. B). FIG.C Secure the PCV ground wire with the small ring lug to the negative (-) terminal of the bike’s battery (Fig. C). Continue routing the wiring harness forward and towards the throttle bodies. 22-065 www.powercommander.com 15-18 Yamaha FZ-07/MT-07 - PCV F/I - 3...
  • Page 4 FIG.D Unplug Unplug the stock wiring harness from both Fuel Injectors (Fig. D). FIG.E Plug the PCV wiring harness in-line of the Fuel Injectors and the stock wiring harness (Fig. E). The pair of PCV leads with ORANGE colored wires go to the left cylinder injector (#1); and the pair with YELLOW colored wires go to right cylinder (#2). Only the right cylinder injector connections can be seen in Figure E. FIG.F Unplug the stock wiring harness from the Throttle Position Sensor located on the right side of the throttle bodies (Fig. F). Unplug 22-065 www.powercommander.com 15-18 Yamaha FZ-07/MT-07 - PCV F/I - 4...
  • Page 5 FIG.G 10 Plug the PCV wiring harness in-line of the TPS and the stock wiring harness (Fig. G). 11 Route the rest of the PCV wiring harness forward towards the top of the engine where the Ignition Coils are located. FIG.H 12 Unplug the stock wiring harness from both of the Ignition Coils (Fig. H). FIG.J 13 Plug the PCV wiring harness in-line of the Ignition Coils and the stock wiring harness (Fig. J). The pair of PCV leads with GREEN colored wires go to the left cylinder coil stick (#1); and the pair with BLUE colored wires go to right cylinder coil stick (#2). 14 Route the last pair of connections on the PCV wiring harness out to the left side of the bike below the voltage regulator/rectifier. 22-065 www.powercommander.com 15-18 Yamaha FZ-07/MT-07 - PCV F/I - 5...
  • Page 6 FIG.K 15 Just below the regulator/rectifier, locate and unplug the stock connectors for Unplug the bike’s Crank Position Sensor (Fig. K). This is a pair of CLEAR (opaque) 2-pin connectors with a WHITE and a GREY wire. FIG.L 16 Plug the PCV wiring harness in-line of the stock CPS connectors (Fig. L). 17 Reinstall bodywork, fuel tank and seats. 22-065 www.powercommander.com 15-18 Yamaha FZ-07/MT-07 - PCV F/I - 6...
