CIS Description
Table 6-1
Attribute
Offset
0BEh
0C0h
0C2h
0C4h
0C6h
02/07, Rev. 12.0
Card Information Structure
Data 7 6 5 4
C1h I D Configuration Index
1 1
41h W R P B
0 1 0 0
99h M MS IR
1 0 1
27h R DI PI AI
0 0 1 0
55h X Mantissa
0 Ah = 5.0
6-8
SanDisk CompactFlash Card OEM Product Manual
3 2 1 0 Content Description
I/O Mapped Contiguous
16 Registers
1
Configuration.
Configuration Index for
this entry is 1. Interface
Byte follows this byte.
Default Configuration,
therefore is not
dependent on previous
Default Configuration.
D: Default Configuration
I: Interface Byte follows
Interface Type I/O Interface(1), Bvd's
and wProt not used;
1
Ready/-Busy active but
Wait not used for
memory cycles.
B: Battery Volt
Detects Used
P: Write Protect Used
R: Ready/-Busy Used
W: Wait Used for
Memory Cycles
IO T P V Only Power
CC
Descriptors; No Timing;
1 0 1
I/O and IRQ present; No
Memory Space; Misc
Entry Present
P: Power Info type
T: Timing Info present
IO :I/O Port Info present
IR: Interrupt Info present
MS: Memory Space Info
type
M: Misc Info Byte(s)
present
SI HV LV NV Nominal Voltage Follows
0 1 1 1 NV: Nominal Voltage
LV: Mimimum Voltage
HB: Maximum Voltage
SI: Static Current
AI: Average Current
PI: Peak Current
DI: Power Down Current
Exponent V Nominal is 5V
CC
5h = 1V
© 2007 SanDisk Corporation
CIS
Function
TPCE_INDX
TPCE_IF
TPCE_FS
Power
Parameters
for V
CC
V Nominal
CC
Value
