Table 5-24 defines the valid extended error codes for the CompactFlash Memory Card Series
product. The extended error code is returned to the host in the Error Register. This command
must be the next command issued to the card following the command that returned an error.
Table 5-24
Extended Error Code
35h, 36h
05h, 30-34h, 37h, 3Eh
10h, 14h
0Ch, 38h, 3Bh, 3Ch, 3Fh
5.1.17 Seek–7XH
This command is effectively a NOP command to the card although it does perform a range
check of cylinder and head or LBA address and returns an error if the address is out of range.
Table 5-25
Command (7)
C/D/H (6)
Cyl High (5)
Cyl Low (4)
Sec Num (3)
Sec Cnt (2)
Feature (1)
© 2007 SanDisk Corporation
Extended Error Codes
00h No error detected
01h Self test OK (no error)
09h Miscellaneous error
20h Invalid command
21h Invalid address (requested head or sector invalid)
2Fh Address overflow (address too large)
Supply or generated voltage out of tolerance
11h Uncorrectable ECC error
18h Corrected ECC error
Self test or diagnostic failed
ID not found
3Ah Spare sectors exhausted
1Fh Data transfer error/aborted command
Corrupted media format
03h Write/erase failed
Seek
Bit 7 6
1 LBA
5-19
ATA Command Description
Description
5 4 3 2
7XH
1 Drive Head (LBA 27-24)
Cylinder High (LBA 23-16)
Cylinder Low (LBA 15-8)
Sector Number (LBA 7-0)
X
X
1 0
