ATA Command Description
•
Bits 2-0: Advanced True IDE PIO Mode Support
Indicates the maximum True IDE PIO mode supported by the card.
Value
0
1
2
3-7
•
Bits 5-3: Advanced True IDE Multiword DMA Mode Support
Indicates the maximum True IDE Multiword DMA mode supported by the card.
Value
0
1
2
3-7
•
Bits 8-6: Advanced True IDE PIO Mode Selected
Indicates the current True IDE PIO mode selected on the card.
Value
0
1
2
3-7
•
Bits 11-9: Advanced True IDE Multiword DMA Mode Selected
Indicates the current True IDE Multiword DMA Mode Selected on the card.
Value
0
1
2
3-7
•
Bits 15-12: Reserved
02/07, Rev. 12.0
SanDisk CompactFlash Card OEM Product Manual
Maximum PIO Mode Timing Supported
Specified in Word 64
PIO Mode 5
PIO Mode 6
Reserved
Maximum Multiword DMA Mode Timing Supported
Specified in Word 63
Multiword DMA Mode 3
Multiword DMA Mode 4
Reserved
Current PIO Timing Mode Selected
Specified in Word 64
PIO Mode 5
PIO Mode 6
Reserved
Current Multiword DMA Timing Mode Selected
Specified in Word 63
Multiword DMA Mode 3
Multiword DMA Mode 4
Reserved
