SanDisk CompactFlash Card OEM Product Manual
5.1.21 Standby–96H, E2H
This command causes the card to set BSY, enter the Sleep mode (which corresponds to the
ATA "Standby" Mode), clear BSY and return the interrupt immediately. Recovery from sleep
mode is accomplished by simply issuing another command (reset is not required).
Table 5-30
Command (7)
C/D/H (6)
Cyl High (5)
Cyl Low (4)
Sec Num (3)
Sec Cnt (2)
Feature (1)
5.1.22 Standby Immediate–94H, E0H
This command causes the card to set BSY, enter the Sleep mode (which corresponds to the
ATA "Standby" Mode), clear BSY and return the interrupt immediately. Recovery from sleep
mode is accomplished by simply issuing another command (reset is not required).
Table 5-31
Command (7)
C/D/H (6)
Cyl High (5)
Cyl Low (4)
Sec Num (3)
Sec Cnt (2)
Feature (1)
5.1.23 Translate Sector–87H
When this command is issued, the controller responds with a 512-byte buffer of information
on the desired cylinder, head and sector with the actual Logical Address.
Table 5-32
Command (7)
C/D/H (6)
Cyl High (5)
Cyl Low (4)
Sec Num (3)
Sec Cnt (2)
Feature (1)
© 2007 SanDisk Corporation
Standby
Bit 7 6
X
Standby Immediate
Bit 7 6
X
Translate Sector
Bit 7 6
1 LBA
5-23
ATA Command Description
5 4 3 2
E2H or 96H
Drive X
X
X
X
X
X
5 4 3 2
E0H or 94H
Drive X
X
X
X
X
X
5 4 3 2
87H
1 Drive Head (LBA 27-24)
Cylinder High (LBA 23-16)
Cylinder Low (LBA 15-8)
Sector Number (LBA 7-0)
X
X
1 0
1 0
1 0
Rev. 12.0, 02/07
