ATA Command Description
Table 5-8
Word
Address
51
52
53
54
55
56
57-58
59
60-61
62
63
64
65
66
67
68
69-79
80
81
82
83
84
85
86
87
88
89
90
91
92-127
128-159
160
161
162
02/07, Rev. 12.0
Identify Device Information
Default Value Total Bytes
0200h 2
0000h 2
0003h 2
XXXXh 2
XXXXh 2
XXXXh 2
XXXXh 4
010Xh 2
XXXXh 4
0000h 2
0X07h 2
0003h 2
0078h 2
(IDE Mode only)
0078h 2
(IDE Mode only)
0078h 2
0078h 2
0000h 20
00XXh 2
0000h 2
00X0h 2
4004h 2
4000h 2
0000h 2
0004h 2
4000h 2
0000h 2
XXXXh 2
0000h 2
XXXXh 2
0000h 72
0000h 64
0000h 2
0000h 2
0000h 2
5-6
