Description

2.1

Product overview

2.1.1

Explosion proof instrument

1 Enclosure lid
2 Bezel with main
electronics
3 Relay board (optional)
4 Enclosure bottom
5 Sensor
6 Assembled instrument
Dräger Polytron 5200 / Dräger Polytron 53X0
2.1.2 Explosion proof instrument with increased safety
wiring compartment (e-box)
1 Enclosure lid
2 Bezel with main
electronics
3 Relay board (optional)
4 Enclosure bottom
5 Sensor
6 Feed-through
7 Field wire terminals
(not shown)
8 e-box
9 Assembled instrument
