Hondex HDX-121 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION MANUAL
(Including Guidelines for Safe Opereation)
HDX-121 HDX-121-BB
HDX-122 HDX-122-BB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDX-121 and is the answer not in the manual?

Questions and answers

Related Manuals for Hondex HDX-121

Summary of Contents for Hondex HDX-121

  • Page 1 OPERATION MANUAL (Including Guidelines for Safe Opereation) HDX-121 HDX-121-BB HDX-122 HDX-122-BB...
  • Page 2 INTRODUCTION Thank you very much for purchasing our product. Please be sure to read this manual carefully and understand the contents before the actual operation in order to keep your safety. Please store this manual safely at the convenient place so that you can read it when needed.

  • Page 3: Table Of Contents

    CONTENTS CAUTION ON SAFETY (BE SURE TO READ THIS) ································ 1 1. HANDLING OF MAIN UNIT ······················································· 1 2. HANDLING OF CABLE ····························································· 2 3. HANDLING TRANSDUCER AND WATER TEMP SENSOR ················· 3 4. REMOTE ··············································································· 3 5. HANDLING OF GPS ································································ 4 6.
  • Page 4 WAYPOINT NAVIGATION ·······························································49 CANCEL WAYPOINT NAVIGATION ···················································50 DRAW LINE ················································································51 DRAW LINE BY POSITION ·····························································52 ERASE LINE ················································································52 SAVE (ERASE) ROUTE ··································································54 RECALL SAVED ROUTE (ROUTE NAVIGATION) ··································55 ADVANCE WAYPOINT / RETURN WAYPOINT ·····································56 DISPLAY LAT/LONG LINE ······························································57 SOUND ARRIVAL / ANCHOR WATCH / OFF-COURSE ALARM ················57 OWN VESSEL VECTOR AND OWN VESSEL MARK COLOR ····················58 READOUT SET-UP FOR EACH INFO ·················································58 CHANGE FONT SIZE / COLOR FOR LETTERS ····································59...
  • Page 5 CLUTTER ····················································································91 DEPTH UNIT ···············································································92 SCALE LINE ················································································92 SUPER RANGE ·············································································92 WATER TEMP GRAPH ····································································93 AUTO RANGE MAX. DEPTH ····························································93 CLEAN ECHO ··············································································93 STC ···························································································94 OUTPUT POWER ··········································································94 PULSE LENGTH ···········································································95 SENSITIVITY MODE ·····································································96 SOUNDER CURSOR FUNCTION ······················································96 SOUNDER DISTANCE SCALE ··························································97 SEARCHING AREA ·······································································97 SOUNDER FREEZE FUNCTION ························································98 BOTTOM HARDNESS FUNCTION ·····················································98...

  • Page 6: Caution On Safety (Be Sure To Read This)

    CAUTION ON SAFETY (BE SURE TO READ THIS) This explains the important cautions in order to prevent the users and surrounding people from physical injuries and property damages. 1. HANDLING OF MAIN UNIT DANGER High voltage is used for the unit inside. No one besides authorized personnel should disassemble or modify the unit.

  • Page 7: Handling Of Cable

    CAUTION Do NOT install the unit where rain or spray dashes hit directly. It causes the firing and electric shock. Do NOT install the unit at heated places. It causes the firing from the increase of internal temperature, injury, and electric shock. Use the earthing.

  • Page 8: Handling Transducer And Water Temp Sensor

    3. HANDLING TRANSDUCER AND WATER TEMP SENSOR DANGER Any works on the vessel are very unstable and risky. Installation/Maintenance of transducer and water temp sensor should be handled after landing the vessel on ground or fixing the vessel at shipyard etc. WARNING Be sure to ventilate well inside the vessel when installing the transducer at the bottom of vessel.

  • Page 9: Handling Of Gps

    5. HANDLING OF GPS DANGER Do NOT work on GPS while piloting. The work such as installation or maintenance should be carried out on ground. CAUTION Place GPS antenna at highest location as possible for stable GPS signal. Searching time for GPS signals take longer, and GPS accuracy becomes lower if any obstacles are located near by GPS antenna.

  • Page 10: Operation

    7. OPERATION Power OFF when starting engine. Battery voltage varies when the engine starts. It may cause some damages onto the unit. Set the power OFF when starting the engine. Power Supply 11-35V Operate the unit within the range of DC11-35V. Organic solution is prohibited.
  • Page 11 MEMO...

  • Page 12: Descriptions

    Brightness adjustment ( page18) Card slot for SD and USB device ADJUST of DISTANCE MARKER (VRM) Reduce distance marker (VRM). ( page63) EVENT MARK < HDX-121> < HDX-122> ( page63) Enter event mark EVENT MARK Zoom out ( page25) Enter event mark + ( page63)

  • Page 13: Rear View

    < HDX-121 / HDX-122 > RGB monitor output Monitor power output (5P) Water temp sensor (TEMP, 8P) *option External input/output (NMEA1, 6P) Remote (4P) *option External input/output (NMEA2, 6P) GPS (GPS, 6P) Transducer (5P) 1kW or 1.8kW(only for HDX-121) DC Power (2P) Earth Terminal...
  • Page 14 < HDX-121-BB / HDX-122-BB > Water temp sensor (TEMP, 8P) External input/output (NMEA1, 6P) Remote (4P) *option External input/output (NMEA2, 6P) GPS (GPS, 6P) Mark input terminal RGB monitor output Transducer (only for HDX-121-BB) Earth Terminal DC Power (2P)

  • Page 15: Remote (Option)

    . REMOTE (OPTION) Power On/Off ( page15) Mode display switch ( page17) User key Direction key Zoom in ( page25) North Up ( page26) Course Up ( page26) Line ( page51) Wake On/Off ( page39) Depth ( page80) Mark input ( page63) Gain2 (sensitivity) ( page82)
  • Page 16 REMOTE option DANGER Do NOT use any leaked AA-batteries. (for IR usage) It may cause human injuries if a person touches the leaked liquid. CAUTION Place the remote for safe location when not being used. Prevent from dropping and human accident. 2pcs AA-batteries required for cordless usage.

  • Page 17: How To See The Display

    HOW TO SEE THE DISPLAY Water temp sensor : Option...

  • Page 18: How To Operate Menu

    HOW TO OPERATE MENU How to Operate Menu Contents of items can be changed by using MENU/DIRECTION/SET/CLR keys. MENU key SET key Press MENU key. Use direction key (up/down) to select. Also, input “assigned number” to do the CENTER key same.

  • Page 19: Basic Operation

    BASIC OPERATION POWER ON/OFF ··········································································15 INITIAL SET-UP(TD LOCATION SET-UP) ··········································16 DISPLAY MODE SWITCH ·······························································17 SCREEN BRIGHTNESS ··································································18 SIMULATION MODE ·····································································19 NMEA0183 OUTPUT ·····································································20 SCREEN CAPTURE TO USB DEVICE ·················································21 INITIALIZE ·················································································21...

  • Page 20: Power On/Off

    POWER ON/OFF Power ON/OFF Press ON key to turn on the power after beep sound followed by caution and chart display. Press OFF key for 2sec or more to turn off the power. ON key OFF key REMOTE (option) Press&Hold ON key to turn on the power after beep sound followed by caution and chart display.

  • Page 21: Initial Set-Up(Td Location Set

    INITIAL SET-UP (TD LOCATION SET-UP) HDX-121 and HDX-121-BB only The following display appears after 1 time power on. Select the proper one. Also, this TD set-up can be changed from menu. (Refer to “TRANSDUCER THRU-HULL / IN-HULL SET-UP” p99.)

  • Page 22: Display Mode Switch

    DISPLAY MODE SWITCH Mode Change Press MODE key to change the display to Echosounder/Plotter – Plotter – Echosounder. Plotter Display Plotter Display Display MODE key Displ a y Plotter Change Display Ratio Display Only for “Echosounder/Plotter” mode, possible to change each display ratio. Displ a y Press&Hold MODE key to show “DISPLAY CORRECTION”...

  • Page 23: Screen Brightness

    SCREEN BRIGHTNESS Brightness Adjustment Quick Press ON : Brighter Quick Press OFF : Darker Brightness indicator will disappear itself. Otherwise, press any keys except ON/OFF to close it. ON key OFF key Case of Remote option Quick Press ON : Brighter Quick Press OFF : Darker...

  • Page 24: Simulation Mode

    SIMULATION MODE SIMULATION Go to 8.OTHERS – 8.INITIAL – SET key 5.SIMULATION. Use Direction key to select the different demo mode. No simulation mode Fixed location of own vessel CENTER key MOVE Vessel keeps moving. ROTATE Vessel keeps rotating. ONE WAY Vessel moves to one direction.

  • Page 25: Nmea0183 Output

    NMEA0183 OUTPUT On/Off NMEA Output Go to 8.OTHER – 7.EXT TERMINAL – 3.NMEA1 OUTPUT or 4.NMEA2 OUTPUT. : Output : No output NMEA0183 Output Interval Go to 8.OTHER – 7.EXT TERMINAL – 1.lNTERVAL SETUP or 2.INTERVAL SETUP. Each interval can be selected. Interval set-up may be disabled when outputting too much data.

  • Page 26: Screen Capture To Usb Device

    SCREEN CAPTURE TO USB DEVICE Possible to save the screen image to USB device. PNG format 800x600 Enable the Save Function Go to 8.OTHERS – 3.USER KEY. Select SAVE PICTURE Instruction Pull the card slot cover. Insert USB device into the USB connector. Pull the card slot cover.

  • Page 27: Operation Of Plotter

    OPERATION OF PLOTTER CURSOR ················································································································ 23 SHIFT DISPLAY ······································································································· 24 ZOOM IN / ZOOM OUT ····························································································· 25 DISPLAY DIRECTION ······························································································· 26 MAP CARD ············································································································· 27 USB DEVICE ··········································································································· 28 MARK INPUT ·········································································································· 32 SPOT SOUNDING FUNCTION (DEPTH INFO DISPLAY) ···················································· 33 ERASE MARK ··········································································································...

  • Page 28: Cursor

    CURSOR On/Off Cursor Use of Cursor Display the selected Lat/Long. Display distance/bearing/time from own vessel to cursor. Input/Erase mark or waypoint. CURSOR ON/OFF key Press CURSOR ON/OFF key to show the cursor. Press one more time to cancel. Cursor Line “Cursor Line”...

  • Page 29: Shift Display

    SHIFT DISPLAY Move Chart Display Press CURSOR ON/OFF to cancel cursor. Use DIRECTION key to move the display. Shift Display CENTER key When own vessel is out of the screen, CURSOR ON/OFF key you can always go back by pressing CENTER key (center of DIRECTION key).

  • Page 30: Zoom In / Zoom Out

    ZOOM IN / ZOOM OUT Zoom In/Out Zoom In/Out Cursor ON ZOOM OUT ZOOM IN : Zoom In/Out at the center of cursor position. Cursor OFF : Zoom In/Out at own vessel position. Scale “Scale” helps you to understand the distance on the screen.

  • Page 31: Display Direction

    DISPLAY DIRECTION Selection of Direction NORTH UP : North is up on the screen. COURSE UP : Vessel bearing is up on the screen. Course Up “Manual/Auto” course-up can be selected NORTH UP key COURSE UP key in the menu. ( page73) Auto course-up ON: Bearing direction is always upper side of the screen.

  • Page 32: Map Card

    MAP CARD Chart Data Insert Card Pull the card slot cover at lower right on the unit. Insert the card into the slot. Card slot cover USB connector Chart (no use) connector Chart SD card Insert chart card (sticker side on the left) Seal the card slot cover.

  • Page 33: Usb Device

    USB DEVICE Possible to copy the data between unit and USB device. Any USB devices up to 8GB specs Copy Data Contents Wake, Mark, Waypoint, Line, Route It may take sometimes to recognize the connected USB device. Software may act slow when USB device is connected. Save Data from Unit to USB Device SET key Go to 8.OTHERS –...
  • Page 34 Load Data from USB Device SET key Go to 8.OTHERS – 2.MEMORY CARD – 3.STORE FROM USB-DRIVE TO UNIT. CLR key Input the block number of USB device. Red-colored block number means some CENTER key data contained. NUMBER key Use DIRECTION key to select the item. Red-colored block number means some data contained inside USB device.
  • Page 35 ERASE USB DATA Erase all the saved data of USB device. Pull the card slot cover. Insert USB device. Go to 8.OTHERS – 2.MEMORY CARD – 1.ERASE USB-DRIVE DATA. Press SET key to erase all the data inside USB device. USB slot Set key Direction key...
  • Page 36 REMOVE USB DEVICE Be sure to execute the following when removing USB device from unit. If not, it may cause the damage onto the stored data. Go to 8.OTHERS – 2.MEMORY CARD – 4.REMOVE USB-DEVICE. Press SET key to hear beep sound so that USB device can be removed.

  • Page 37: Mark Input

    MARK INPUT Input Mark at Own Vessel Position EVENT MARK key Press MARK key input mark at own vessel. When the cursor is ON, mark is input at cursor location. CHANGE SHAPE key Mark shape can be changed by SHAPE key or from MENU 3.EVENT MARK –...

  • Page 38: Spot Sounding Function (Depth Info Display)

    Go to 8.OTHERS – 8.INITIAL – MODE key 6.SPEICAL MENU – 1.REMOTE MARK KEY and select. ( page63) In case of HDX-122 Event Mark key In case of HDX-121 Echo Sounder key (Event Mark key) Event Mark Event Mark Event Mark Event Mark...

  • Page 39: Erase Mark

    User Key Go to 8.OTHERS – 3.USER KEY. Select “SPOT S.”. Press USER key to input an event mark. ERASE MARK Erase by Color Erase marks by color. Go to 3.EVENT MARK – 1.ERASE – 1.ERASE BY COLOR. Select the color you want to erase. SET key Press SET key to erase all marks of selected color.
  • Page 40 Erase All Erase all marks at once. Go to 3.EVENT MARK – 1.ERASE – 3.ERASE ALL. SET key Press SET key to erase all marks. Erase Marks by Date Erase mark by selected date. Go to 3.EVENT MARK – 1.ERASE – 4.ERASE BY DATE.
  • Page 41 Erase by Cursor CURSOR ON/OFF key Go to 3.EVENT MARK – 1.ERASE – 5. ERASE BY CURSOR. Select ON. Press CURSOR ON/OFF key to display a cursor. CLR key SET key Use DIRECTION key to overlap the cursor on the selected mark. Press SET key to erase.

  • Page 42: Edit Mark

    EDIT MARK Mark Edition Possible to edit shape, color, and lat/long manually. Comment can be added also. RANGE change key List MENU key Go to 3.EVENT MARK – 5.LIST/EDIT. SET key CLR key Use DIRECTION key (left/right) to move the cursor and press SET key to execute. NEXT Display next 10 items.
  • Page 43 Input Characters Symbol, Number, Alphabet (Capital/Small). Edit Mode Up/Down DIRECTION key Select character and mark. Left/Right DIRECTION key Move the cursor. SET key Save the edit data. (No save unless all the data is input except comment.) CLR key Cancel the edit. (Comment is deleted when the cursor is located at comment section.) Number key...

  • Page 44: Display (Record) Wake

    DISPLAY (RECORD) WAKE WAKE Press WAKE ON/OFF key to start recording the wake. “ ” appears when recording. Waypoint Mark WAKE COLOR WAKE ON/OFF key Wake Event Mark Press WAKE ON/OFF key to cancel recording the wake. “ ” disappears after the cancel. Press WAKE COLOR key to change the wake color.

  • Page 45: Wake Line Width

    Recording Limit Max.64,000 points. Old wake will be deleted after exceeding 64,000 point. Better to set to longer interval for long hrs (distance). 1sec: 1sec x 64000 / 60 / 60 = 17.7hrs Max. 5sec: 5sec x 64000 / 60 / 60 = 88.8hrs Max. Go to 1.WAKE to see the current recording points shown at the bottom of MENU.

  • Page 46: Erase Wake

    ERASE WAKE Erase by Color Go to 1.WAKE – 4.ERASE WAKE – 1.ERASE BY COLOR. Select a color. SET key Press SET key to erase the selected color. Erase All Erase all wakes. Go to 1.WAKE – 4.ERASE WAKE – 2.ERASE ALL.
  • Page 47 Erase by Cursor Go to 1.WAKE – 4.ERASE WAKE – CURSOR ON/OFF key 4.ERASE BY CURSOR. Press CURSOR ON/OFF key to display a cursor. CLR key Use DIRECTION key to overlap the cursor SET key on the selected wake point. Press SET key to erase.

  • Page 48: Waypoint Mark

    WAYPOINT MARK Waypoint Mark Shape: 8 types Color: Red, Yellow, Green, Magenta, White, Cyan, Blue, Color of wake Upper Limit: 2,000 points Press WP SAVE key to set a waypoint WP SAVE key mark and number. Waypoint Mark Waypoint Number When the cursor is ON, a waypoint mark is saved at the cursor location.

  • Page 49: Erase Waypoint Mark

    ERASE WAYPOINT MARK Erase by Color Go to 2.WAYPOINT – 3.ERASE WAYPOINT – 1.ERASE BY COLOR. Select a color. SET key Press SET key to erase the selected waypoint marks. Erase by Shape Go to 2.WAYPOINT – 3.ERASE WAYPOINT – 2.ERASE BY SHAPE. Select a shape.
  • Page 50 Erase All Go to 2.WAYPOINT – 3.ERASE WAYPOINT – 3.ERASE ALL. Press SET key to erase all waypoint SET key marks. Erase by Date Go to 2.WAYPOINT – 3.ERASE WAYPOINT – 4.ERASE BY DATE. Select a waypoint to be erased. SET key [1.ERASE TODAY WAYPOINT] Erase today’s waypoints.
  • Page 51 ERASE BY CURSOR Go to 2.WAYPOINT – 3.ERASE WAYPOINT CURSOR ON/OFF key – 5.ERASE BY CURSOR. Select ON. Press CURSOR ON/OFF key to display a cursor. CLR key SET key Use DIRECTION key to overlap the cursor to a waypoint mark to be erased. Press CLR key to erase.

  • Page 52: Edit Waypoint Mark

    EDIT WAYPOINT MARK Edit Waypoint Mark Possible to edit shape, color, and lat/long manually. Comment can be added also. RANGE Change key MENU key List SET key Go to 2.WAYPOINT – 7.LIST/EDIT. CLR key Use DIRECTION key (left/right) to move CENTER the cursor and press SET key to execute.
  • Page 53 Input Characters Symbol, Number, Alphabet (Capital/Small). Edit Mode Up/Down DIRECTION key Select character and mark. Left/Right DIRECTION key Move the cursor. SET key Save the edit data. (No save unless all the data is input except comment.) CLR key Cancel the edit. (Comment is deleted when the cursor is located at comment section.) Number key...

  • Page 54: Waypoint Navigation

    WAYPOINT NAVIGATION Set-up Waypoint Navigation Waypoint navigation shows line from own vessel to the waypoint. On the upper left screen, you may see waypoint’s lat/long and distance/time between waypoint and own vessel. WP RECALL key Press WP RECALL key. Or, go to 2.WAYPOINT –...

  • Page 55: Cancel Waypoint Navigation

    SIMPLE WAYPOINT NAVIGATION Press CURSOR key to display a cursor on the screen. WP SAVE key Use DIRECTION key to move to the desired location. Press&Hold WPT key to activate a simply CURSOR ON/OFF key waypoint navigation. Simple waypoint navigation is only a temporary waypoint.

  • Page 56: Draw Line

    DRAW LINE Draw Line Line Possible to draw desired lines. Max.8,000 points Press CURSOR key to display a cursor. Go to 8.OTHERS – 1.DRAW LINE – 1.START DRAW. Press SET key. Move a cursor to the starting point and press SET key. CURSOR ON/OFF key Use DIRECTION key to move the cursor SET key...

  • Page 57: Draw Line By Position

    DRAW LINE BY POSITION Lat/Long Input Box Go to 8.OTHERS – 1.DRAW LINE – 5.DRAW MODE. Select POSITION. Press SET key to start drawing. Lat/Long input box appears on upper left of screen. SET key Use NUMBER key to input lat/long. Use DIRECTION key (left/right) to go back to the pre-set wrong value for correction if needed.
  • Page 58 ERASE by Cursor Erase individual lines by using a cursor. CURSOR ON/OFF key Go to 8.OTHERS – 1.DRAW LINE – 4.ERASE LINE – 3.ERASE BY CURSOR. CLR key Select ON. ( page75) CENTER Press CURSOR ON/OFF key to display a cursor.

  • Page 59: Save (Erase) Route

    SAVE (ERASE) ROUTE Save (Erase) Route Route Max. 40 routes (max.20 passing points) The created route remains until it’s erased. Go to 4.ROUTE – 4.ENTER ROUTE. SET key CLR key CENTER NUMBER Enter route number press SET key. Red-colored route number is already registered.

  • Page 60: Recall Saved Route (Route Navigation)

    RECALL SAVED ROUTE (ROUTE NAVIGATION) Recall Route (Start Route Navigation) Go to 4.ROUTE – 1.RECALL ROUTE. Input the route number. SET key Press set key to set the route navigation. Route Navigation It always sets to next passing point automatically every time the vessel reach a passing point.

  • Page 61: Advance Waypoint / Return Waypoint

    ADVANCE WAYPOINT / RETURN WAYPOINT Advance / Return Waypoint Set a route navigation. ( page54) Go to 4.ROUTE – 5.ADVANCE WAYPOINT. SET key Each time pressing SET key skips to the following passing point. Go to 4.ROUTE – 6.RETURN WAYPOINT when setting the waypoint one earlier.

  • Page 62: Display Lat/Long Line

    DISPLAY LAT/LONG LINE Lat/Long Go to 6.READOUT SETUP – 1.C-MAP SETUP – 2.LAT/LON GRID. Use DIRECTION key (left/right) to set. OFF eliminates lat/long line. SOUND ARRIVAL / ANCHOR WATCH / OFF-COURSE ALARM Sound Alarm Following 3 different alarms can be set for waypoint navigation.

  • Page 63: Own Vessel Vector And Own Vessel Mark Color

    OWN VESSEL VECTOR AND OWN VESSEL MARK COLOR Own Vessel Vector and Own Vessel Mark Color Own Vessel Vector This vector points the course. Vector color is same as vessel color. Go to 6.READOUT SETUP – 3.OWN BOAT READOUT – 2.OWN BOAT VECTOR. Select one choice.

  • Page 64: Change Font Size/Color For Letters

    CHANGE FONT SIZE/COLOR FOR LETTERS Change Font Size/Color e.g.) Change font size related to own vessel. CENTER Go to 6.READOUT SETUP – 5.DISPLAY LETTERS – 5.OWN BOAT LETTER – 1.LAT/LON LETTER. Use DIRECTION key to select the font size. Select OFF to hide. Cursor character and Waypoint character can be changed as well.

  • Page 65: Loran C Chain

    LORAN C CHAIN Display with Loran C Loran C Loran C (Long Range Navigation) is the hyperbolic navigation system using long wave band. This unit enables you to set correction of Loran C chain, two slave stations and each slave station. Go to 6.READOUT SETUP –...

  • Page 66: Smoothing

    SMOOTHING Smoothing Set-up Apply the averaging to show the smooth wake information. Go to 8.OTHERS – 5.GPS SETUP – 1.SMOOTHING. Use DIRECTION key (left/right) to select the smoothing level. Low, Mid, High 2. Bearing LV (level) Averaging for bearing variation. 3.

  • Page 67: Gps Status Info

    GPS STATUS INFO GPS Satellite Status is shown on the screen. GPS Status Time DOP Value # of Satellite Go to 7.FIND – 3.SATELLITE. Press SET key to show the satellite status. Press CLR key or MENU key to return. DOP value : Smaller is better&accurate.

  • Page 68: Assign Sounder Key To Plotter Key

    ASSIGN SOUNDER KEY TO PLOTTER KEY Change Sounder Key Function to Plotter Possible to assign the sounder key to plotter key when showing plotter display only on the screen. Go to 8.OTEHRS – 8.INITIAL – 6.SPECIAL MENU – 1.REMOTE MARK KEY.

  • Page 69: Clock

    CLOCK Clock Display Go to 6.READOUT SETUP – 7.CLOCK. Pink-colored clock hand: Expected arrival time Select ON to show clock. When using waypoint navigation, the expected arrival time is shown with pink clock hands. CLOCK ALARM Alarm Go to 5.ALARM – 6.TIME ALARM. Select ON to set the alarm time.

  • Page 70: Front View

    FRONT VIEW Front Expansion View Front view shows the expanded chart of bearing direction. Go to 6.READOUT SETUP – 1.C-MAP SETUP – 7.OTHER SETUP – 8.FRONT VIEW. Select ON. AIS TARGET DISPLAY Optional AIS cable is required. Baud rate: 38400. ( page20) Place a cursor to the target vessel to display MMSI# and Vessel Name(when possible).
  • Page 71 AIS DISPLAY RANGE Scale range applied for AIS display. ( page25) Go to 8.OTHERS – 9.AIS SETUP – 1.AIS DISP RANGE. No display 1, 2, 5, 10 Other vessels appear when the scale range is within the selected range. AIS Target Color Color set-up for each country vessel.

  • Page 72: Radar Range Display

    RADAR RANGE DISPLAY Radar Range Display Input “RSD” NMEA0183 sentence from radar device to indicate same radar range on the plotter with yellow circle. Go to 6.READOUT SETUP – 3.OWN BOAT READOUT – 7.RADAR CIRCLE. OFF No show Radar range circle appears.

  • Page 73: Chart Set

    CHART SET-UP Depth Unit: m, ft, fa Go to 6.READOUT SETUP – 1.C-MAP SETUP – 1. DPETH SETUP. Depth Line Go to 6.READOUT SETUP – 1.C-MAP SETUP – 1.DEPTH SETUP – 2.DEPTH LINE. Lat/Long Grid Go to 6.READOUT SETUP – 1.C-MAP SETUP – 2.LAT/LON GRID. Tide, Current Go to 6.READOUT SETUP –...
  • Page 74 Mixing Level Go to 6.READOUT SETUP – 1.C-MAP SETUP – 7.OTHER SETUP – 2.MIXING LEVEL. Use DIRECTION key to select ON or OFF. Mixing level enables to show the charts with different scale set-up. No chart data is shown when selecting “OFF” for this mixing level. Declutter Go to 6.READOUT SETUP –...
  • Page 75 Move Direction Go to 6.READOUT SETUP – 1.C-MAP SETUP – 7.OTEHR SETUP – 7.MOVE DIRECTION. Automatic Info Object information appears automatically by a cursor. Go to 6.READOUT SETUP – 1.C-MAP SETUP – 8.AUTO INFO. ON POINT: Auto info of POINT appears when a cursor is located on items such as port service/tide/light/wreck/rock/buoy/beacon/obstruction/land mark etc.

  • Page 76: List Of Plotter Menu

    LIST OF PLOTTER MENU Menu Item Factory set-up 1. WAKE 1. WAKE MEMORY( page39) OFF , ON 2. WAKE COLOR ( page39) RED BLUE 3. DISPLAY COLOR 1. RED OFF , ON ( page39) 7. BLUE 8. ALL COLORS 9. NO EXC. WAKE 4.
  • Page 77 Menu Item Factory set-up OFF , ON 5. DISPLAY COLOR 1. RED ( page43) 7. BLUE 8. ALL COLORS 9. NO DISPLAY 6. CHANGE OF 1. MEMORIZED SHAPE SHAPE ( page43) 7. LIST / EDIT( page47,48) 8. OTHER SETUP 1. WAYPOINT RECALL OFF , ON MEMORY 2.
  • Page 78 Menu Item Factory set-up 5. ALARM 1. ARR / ANCHOR 1. ALARM SET OFF , ARRIVAL , ANCHOR ALARM 2. DISTANCE SET 0.50NM(km) 0.00 9.99NM(km) ( page57) 2. OFF COURSE 1. ALARM SET OFF , ON ALARM 2. COURSE WIDTH SET 0.50NM(km) 0.01 9.99NM(km) ( page57) 3.
  • Page 79 Menu Item Factory set-up 1. LAT/LON, LORAN C LAT/LON , LORAN C 2 LORAN C SETUP 1. CHAIN POSITION 5930 2. SLAVE STATION1 READOUT Y 25 3. SLAVE STATION2 ( page60) Z 38 4. SLAVE STA1 0.00 s 5. SLAVE STA2 0.00 s 3.
  • Page 80 Menu Item Factory set-up 6. COLOR TONE NORM , NIGHT 7 CLOCK ( page64) OFF , ON 7. FIND 1. PORT 2. TIDE STATION 3. SATELLITES 8. OTHERS 1. DRAW 1. START DRAW LINE 2. LINE COLOR WAKE (RED BLUE , WAKE) ( page51)3.
  • Page 81 Menu Item Factory set-up OFF , 1 , 2 , 4sec 7. EXT 1. INTERVAL 1. GGA OFF , 1 , 2 , 4sec TERMINAL SETUP 2. GLL OFF , 1 , 2 , 4sec 3. VTG ( page20) 4. RMC OFF , 1 , 2 , 4sec 5.
  • Page 82 MEMO...

  • Page 83: Operation Of Echo Sounder

    OPERATION OF ECHO SOUNDER for HDX-121 , HDX-121-BB SOUNDER SCREEN ······································································79 DEPTH SET-UP ············································································80 SENSITIVITY ··············································································81 EXPANSION MODE ·······································································83 EXPANSION AREA ········································································84 WATER TEMP ALARM ····································································85 FISH ALARM ···············································································85 DEPTH ALARM ·············································································86 WATER TEMP CORRECTION ···························································86 FREQUENCY DISPLAY ···································································87 SWEEP SPEED ·············································································87 SOUNDER SET-UP ········································································88...

  • Page 84: Sounder Screen

    SOUNDER SCREEN Example: Low-Freq – High Freq Display Frequency 1 Fish School Own Boat position Gain Bar Gain Level 200kHz Image Bottom Depth (Displayed Unit) 50kHz Image 2nd Reflection Depth Depth Water Voltage Unit Temp 2 1 Frequency Choose from 50-200, 200-50, 50-50, 200-200, 50, 200. 2 Water temperature Optional water temp sensor is required to show water temp.

  • Page 85: Depth Set

    DEPTH SET-UP Depth Range This is only selected scale-range on the screen. The measuring capability varies depending on the water conditions etc. Range Key Press key for shallower range. Press key for deeper range. The depth may not appear when detecting very shallow bottom with very deep range.

  • Page 86: Sensitivity

    SENSITIVITY Whole Display Gain Adjustment Digital echo sounder is capable of changing the whole past image. This function helps to find the optimized gain set-up for whole image (past recording data) with easy manual operation. Single Frequency Display Operation for single frequency display. Both keys, [GAIN1] and [GAIN2], changes the sensitivity.
  • Page 87 Dual Frequency Display For dual frequency display, GAIN1 is for right display, and GAIN2 is for left display. Adjust the sensitivity of left display with GAIN2 key. Lower Sensitivity Press GAIN2 key to lower the sensitivity and gain bar. Higher Sensitivity Press GAIN2 key to increase the sensitivity and gain bar.

  • Page 88: Expansion Mode

    EXPANSION MODE Expansion Mode Expansion Display Expanded display appears on the left side. When selecting dual frequency mode, the right-side frequency is applied for expanded display. Press 9.SOUNDER – 4.EXPANSION – 1.EXP MODE. Normal display appears. BOTTOM LOCK Straight bottom contour and expanded area from the bottom.

  • Page 89: Expansion Area

    EXPANSION AREA Expansion Area Possible to move the expansion area to either sea surface or bottom side. [Zoom] key can be only used during manual expansion mode. Expansion ratio can be selected from x2, x4, x8. x4: factory set-up Go to 9.SOUNDER – 4.EXPANSION – 1.EXP MODE.

  • Page 90: Water Temp Alarm

    WATER TEMP ALARM Water Temp Alarm Alarm is ON within or exceeding the range of 2 different water temps. Optional water temp sensor is required for water temp alarm. Go to 5.ALARM – 3.TEMP ALARM – 1.ALARM SET. Alarm set-up Within Range Alarm is ON within the range of 2 selected temps.

  • Page 91: Depth Alarm

    DEPTH ALARM Depth Alarm Alarm is ON within or exceeding the range of 2 different depths (Depth Set1, Depth Set2). Go to 5.ALARM – 5.DEPTH ALARM – 1.ALARM SET. Alarm set-up. Within range Alarm is ON within the range of 2 selected depths.

  • Page 92: Frequency Display

    FREQUENCY DISPLAY Frequency Display Possible to select dual frequency display as follows. Go to 9.SOUNDER – 1.DISPLAY. Set-up. 50kHz display 200kHz display 200kHz on the left, 50kHz on 200-50 <In case of “50-200”> the right 50kHz on the left, 200kHz on 50-200 When using Auto-Gain the right...

  • Page 93: Sounder Set

    SOUNDER SET-UP Select AUTO or MANUAL set-up for the depth (range) & sensitivity (gain). Go to 9.SOUNDER – 3.AUTO MODE. AUTO enables the selected AUTO functions in the following detailed set-up. AUTO or MANU indicator appears above gain bar. DETAIL SET-UP Auto Gain Automatic gain control Go to 9.SOUNDER –...

  • Page 94: A Mode

    A MODE A Mode A mode appears between sounder image and depth indication. The width changes depending on the strength of reflected echo signal. Go to 9.SOUNDER – 7.OTHER – 6.DISPLAY SETUP – 1.A-MODE. Select one. BACKGROUND COLOR Background Color Visual image of display looks differently by surrounding brightness.

  • Page 95: Color Configuration

    COLOR CONFIGURATION Color Configuration Reflected signal of sound wave is converted into 17 ranks of digital signal according to the strength of response. Color configuration is the color set-up for 16 ranks except background color. Sounder image is shown by the color configuration. The displayed color shows the strength of reaction.

  • Page 96: Intense Level

    INTENSE LEVEL Intense Level This set-up shows more color of strong reflection (signal). Go to 9.SOUNDER – 5.COLOR SETUP – 4.INTENSE COL. Select one. CLUTTER Clutter Fish school and bottom are displayed with the set-up of reflected echo strength and color tone. “Clutter” easily distinguishes the fish school by erasing the color from weakest reflection such as plankton or dirt under the water.

  • Page 97: Depth Unit

    DEPTH UNIT Depth Unit Select from “meter”, “feet”, “fathom”, or “Brazas”. Go to 9.SOUNDER – 7.OTHER – 1.DEPTH UNIT. Select one. SCALE LINE Scale Line Horizontal line (scale line) appears on the screen. Go to 9.SOUNDER – 6.DISPLAY SETUP – 2.SCALE LINE.

  • Page 98: Water Temp Graph

    WATER TEMP GRAPH Water Temp Graph Water temp graph appears. Easy to see the fishing points by knowing the variation of water temp and tide change. Go to 9.SOUNDER – 6.DISPLAY SETUP – 4.TEMP GRAPH. Optional water temp sensor is required to show the graph. AUTO RANGE MAX.

  • Page 99: Stc

    Reduce the sensitivity of shallow water area less than approx.100m and present the clear image by eliminating the noise signal such as plankton and air bubbles. Go to 9.SOUNDER – 7.OTHER – 3.SPECIAL SETUP – 3.STC SETUP. Select one. OUTPUT POWER Output Power Go to 9.SOUNDER –...

  • Page 100: Pulse Length

    PULSE LENGTH Pulse Length The pulse length is the ultrasonic length transmitted each time. 3 selections to choose from. The resolution may vary for each option. Go to 9.SOUNDER – 7.OTHER – 3.SPECIFAL SETUP – 5.PULSE LENGTH. Short High resolution but shallow depth penetration.

  • Page 101: Sensitivity Mode

    SENSITIVITY MODE Sensitivity Set-up the sensitivity level of sounder. Go to 9.SOUNDER – 7.OTHER – 3.SPECIAL SETUP – 6.SENSITIVITY. Standard (Normal) level HIGH High sensitivity level Use GAIN1/GAIN2 key ( page81) for everyday’s Gain (sensitivity) set-up. SOUNDER CURSOR FUNCTION Possible to locate the target point from sounder’s past image. Easy to add Mark or Waypoint for the specific target area.

  • Page 102: Sounder Distance Scale

    SOUNDER DISTANCE SCALE Distance scale displayed on the sounder screen. To give you an idea of how far away the target is located from an own vessel. Go to 9.SOUNDER – 6.DISPLAY SETUP – 5.DIST SCALE. No show Scale display on the top BOTTOM Scale display at the bottom Distance scale number does not appear until echo image reaches to the...

  • Page 103: Sounder Freeze Function

    SOUNDER FREEZE FUNCTION Stop Sounder Transmit Cancel the sounder function when showing only plotter mode on the screen. It helps low power consumption. Go to 9.SOUNDER – 7.OTHER – 2.FREEZE SOUNDER AT PL. OFF Sounder is in operation during PL mode. Sounder is stopped during PL mode.

  • Page 104: Transducer Thru-Hull / In-Hull Set

    TRANSDUCER THRU-HULL / IN-HULL SET-UP TD Location Go to 9.SOUNDER – 7.OTHER – 3.SPECIAL SETUP – 8.TD LOCATION. Select one. THRU-HULL-A :Custom. Not to be used normally. THRU-HULL-B :Normal. Select this when using thru-hull installation. IN-HULL-A :Select this when using in-hull or inside-case installation.

  • Page 105: List Of Echo Sounder Menu

    LIST OF ECHO SOUNDER MENU Factory set-up Menu Item 9. SOUNDER 1. DISPLAY ( page87) 50 , 200 , 200-50 , 50-200 , 50-50 , 200-200 2. SWEEP SPEED( page87) OFF 1 2 3 S x2 x3 3. AUTO MODE ( page88) MANUAL , AUTO 4.
  • Page 106 Menu Item Factory set-up 7. AUTO MODE SETUP 1. AUTO GAIN OFF , LOW , HIGH 2. AUTO RANGE OFF , RANGE , SHIFT 8. TD LOCATION IN-HULL-A , IN-HULL-B , ( page99) THRU-HULL-A , THRU-HULL-B 9. OTHER SPECIAL SETUP 1.
  • Page 107 MEMO...

  • Page 108: Reference Document

    REFERENCE DOCUMENT DIMENSIONAL DRAWING ···························································· 104 CONNECTION WITH MAIN UNIT ··················································· 107 CONNECTOR DIAGRAM ······························································· 109 GPS ANTENNA MADE BY OTHER COMPANY ···································· 109 NMEA CONNECTOR ···································································· 110 NMEA0183 OUTPUT SENTENCE ···················································· 110 MAIN UNIT INSTALLATION ·························································· 111 BUILT-IN INSTALLATION ····························································· 113 TRANSDUCER INSTALLATION ······················································...

  • Page 109: Dimensional Drawing

    DIMENSIONAL DRAWING 1.MAIN UNIT Unit : mm < HDX-121 / HDX-122 > 29.5 < HDX-121-BB / HDX-122-BB >...
  • Page 110 2.BRACKET Unit : mm < HDX-121 / HDX-122 >...
  • Page 111 3.REMOTE & REMOTE HOLDER (OPTION) UNIT...

  • Page 112: Connection With Main Unit

    CONNECTION WITH MAIN UNIT < HDX-121 / HDX-122 > GPS Receiver (6P) Video Signal Output NMEA Equipment Monitor Power Supply (5P) Power Supply Cable Battery 11 35V DC Remote (4P) Transducer(5P) (Option) TD47T (50&200kHz 1kW TD67T (50&200kHz 1.8kW Water Temp Sensor (8P) (Option)
  • Page 113 < HDX-121-BB / HDX-122-BB > Remote (4P) GPS Receiver (6P) NMEA IN/OUT Mark input terminal Power Supply Cable White (+) Black (-) Battery 11 35V DC Video Signal Output Water Temp Sensor (8P) (Option) Transducer(5P) TD47T (50&200kHz 1kW TD67T (50&200kHz 1.8kW...

  • Page 114: Connector Diagram

    CONNECTOR DIAGRAM Caution: Connectors on display unit. 1. Connector for Power Supply 1. Power Supply (+) 11 35V 2. Power Supply (-) 2. Connector 5P for Transducer 1. TD 50kHz 2. TD 200kHz 3. Shield 4. TD 200kHz 5. TD 50kHz (Example) TD Line Info 5P Spec -(Black) 50kHz...

  • Page 115: Nmea Connector

    NMEA CONNECTOR Input/Output Connector To be used when connecting to other device. Data Format Baud Rate Format NMEA0183 4800, 9600, Start bit=1, Data bit=8 GGA,GLL,VTG,RMC,APB, 38400bps Parity bit=none, Stop bit=1 XTE,BOD,DBT/MTW,HDG/HDT Main Unit External Input/Output Device TXD C TXD H RXD C RXD H Data Output...

  • Page 116: Main Unit Installation

    Do NOT install the unit where rain or spray dashes hit directly. It causes the firing and electric shock. Procedure of Installation (HDX-121 / HDX-122) Installation of Unit Fix the unit with enclosed screws by using bracket holes (4 locations).
  • Page 117 Procedure of Installation (HDX-121-BB / HDX-122-BB) Installation of Unit Fix the unit with enclosed screws by using bracket holes (4 locations). Refer to the picture below. 1 Put brackets with pan-head screws with spring washer M4x20 on above four holes.

  • Page 118: Built-In Installation

    BUILT-IN INSTALLATION WARNING If not, it may cause the human injuries. Be sure to follow the instruction below and official installation method. (HDX-121 / HDX-122) Fix the unit by using 4 holes on the front panel. 4pcs for Flash-Mount 1 Refer to the following figure for fixation holes.
  • Page 119 2 Raise 2pcs side covers. 3 Remove the covers. 4 Flash-mount it. 5 Fix with 4pcs 4×30 screws. 6 Put the side covers back.

  • Page 120: Transducer Installation

    TRANSDUCER INSTALLATION DANGER Any works on the vessel are very unstable and risky. Installation/maintenance of transducer should be handled after landing the vessel on ground or fixing the vessel at shipyard etc. If not, it may cause serious injuries. WARNING Be sure to ventilate well inside the vessel when installing the transducer at the bottom of vessel.

  • Page 121: Inside-Hull

    1 INSIDE-HULL Effective for FRP vessels with single hull layer of 10mm or less. Size and shape vary for each transducer. Look for the best picture location before the fixation by putting adequate water on the transducer surface and vessel bottom followed by pressing the transducer onto the vessel bottom.

  • Page 123: Water Temp. Sensor Installation

    WATER TEMP. SENSOR INSTALLATION Water temp sensor: Option DANGER Any works on the vessel are very unstable and risky. Installation/maintenance of water temp sensor should be handled after landing the vessel on ground or fixing the vessel at shipyard etc. If not, it may cause serious injuries. Do not operate the electronic tools with wet hands.

  • Page 124: Standard Configuration

    STANDARD CONFIGURATION < HDX-121 / HDX-122 > Main Unit 12.1” Bracket 1pc Clamping Knob 2pcs Rubber Washer 2pcs Bracket Washer 2pcs Screws for Main Unit and Bracket Screw for Buit-in Installation 4×30 SUS×4pcs 5×20 SUS×4pcs Front Cover (CV08) Power Supply Cable...
  • Page 125 < HDX-121-BB / HDX-122-BB > Main Unit Fixing plate 4pcs Screws with spring washer 20 4pcs × Screws for Main Unit 5×20 SUS×4pcs Remote (CR04) Power Supply Cable DC06 2P 2m 4P 4m Operation Manual Paper Temperate for Built-in Fixation...

  • Page 126: Options

    Transom Water Temp Sensor TC02C + TCK01) TC03-05 8P 5m) 8P 15m TC03-10 8P 10m GPS Receiver GP-17H/17HD GP-16H *GP-17HD(heading sensor included) Remote (CR04) for HDX-121,HDX-122 4P 4m Transducer For HDX-121 / HDX-121-BB TD47T (5P 12m) TD67T (5P 12m) 50&200kHz 1kW 50&200kHz 1.8kW...

  • Page 127: Theory Of Echo Sounder

    THEORY OF ECHO SOUNDER 1 Theory of Echo Sounder Theory of echo sounder is same as echo among hills. Ultrasonic wave transmitted from the transducer directly beneath the vessel is reflected at the sea bottom and received by transducer. Echo sounder indicates the depth by calculating the round-trip time to distance. Also, the unit shows the color image of fish school size/density or sea floor condition according to the strength of reflected wave.
  • Page 128 2 Distinguish of Fish School Important tip is comparison between fish school image and actual fish. Possible to judge the fish type to some extent from the image of fish school. The shape of fish school changes even for same fish group by time (day/night, season, current change).

  • Page 129: Trouble Shooting

    TROUBLE SHOOTING When the unit has any problems, please check the following points before returning the unit for repair. Symptom Cause Remedy Power cannot be Voltage of battery is lower Recharge the battery. turned ON. than standard value (11V). Contact of power connector is Retighten it.
  • Page 130 Symptom Cause Remedy Bottom or fish Contact problem with transducer Retighten the connection. cannot be displayed connector. Remove/clean the rust/dust. at all. Replace it in the case of corrosion. Exchange transducer. Send it for repair. Problem with Transducer Check followings and replace it in the case of actual problems. It's normal if you hear the sound like "Bo Bo"...
  • Page 131 Symptom Cause Remedy Too much noise. Too high sensitivity. Lower the sensitivity. Set to auto gain (auto gain control) Interference with other Noise disappears after other vessel's echo sounder. vessel moves far away. Noise from engine. Change the routing of cables such as transducer and power cables.

  • Page 132: Specifications

    SPECIFICATIONS HDX-121 / HDX-122 HDX-121-BB / HDX-122-BB Display 12.1" TFT Color LCD Display Style Portrait Number of Pixel 800 × 600 Operating Voltage DC11V 35V Dimension of Main 242(H)×358(W)×146(D) 89(H)×268(W)×238.5(D) Unit(mm) Weight of Main Unit Approx. 3.5kg Approx. 1.65kg Chart Presentation...
  • Page 133 Frequency 50&200 Output Power 1kW / 1.8kW 0~1500m Depth Range Auto Range OFF / Range / Shift Auto Gain OFF / Low / High A-Mode OFF / ON OFF / S / L Fish Alarm Water Temp Alarm OFF / In Range / Out of Range Depth Alarm OFF / In Range / Out of Range OFF / Bottom Lock / Automatic Expansion / Manual...
  • Page 134 MAR2017 1st Edition...

This manual is also suitable for:

Hdx-121-bbHdx-122Hdx-122-bb

Table of Contents

Save PDF
