DynaPro/DynaPro v3 Operation

During normal operation, the operator selects the type of transaction from the PMS/POS terminal software. Data is entered on the
DynaPro/DynaPro v3 keypad in response to the prompts on the device display.

Options - Privacy Shield | Stylus | NFC

Privacy Shield Installation
To install the privacy shield, hold the smaller end
firmly against the privacy shield clip holes that are
above the chip card insertion slot. Then pivot the
larger end down and press it onto the device until
you feel a click.

DynaPro/DynaPro v3 with Ethernet Connection

DynaPro/DynaPro v3 Ethernet Power
DynaPro/DynaPro v3 with Ethernet connection requires an external power supply.
Connecting the MagTek DynaPro/DynaPro v3
The device comes with Ethernet cable part number 30019327. The Ethernet cable included with the device has a
junction box approximately two feet from the end for an AC adapter. Plug the AC adapter cable into the junction box. Plug
the Ethernet cable into the nearest available network port. Plug the other end of the AC adapter into the nearest available
power outlet.
Verify Connection and Power
After the AC adapter is plugged in, DynaPro powers on. Initialization takes approximately 30 seconds. "Welcome" appears
on the display screen when ready. Contact MagTek support if the "Welcome" screen does not appear. Check with your
host software provider for specific user functionality and network connectivity validation.
Stylus (optional)
Stylus with USB
Junction box
Stylus with Ethernet
Ethernet cable
(Cables and devices not shown at actual size or to scale)
NFC Capabilities
DynaPro/DynaPro v3 offer
an optional contactless card
reader. Tap contactless cards
on the device's display.
PC
