SXRXLXX1 - SIL IntelliPoint RF Series User's Manual
1.5

Dual Compartment Housing Detail

Conduit Entries (2)
¾-inch NPT (FM/FMc Systems)
M20 x 1.5 (ATEX/IECEx Systems)
140 mm
(5.5 inches)
Sensing Element
Circuit Board
Dual Compartment Housing Detail
The Input/Output Module (IOM) is located on
Customer Connection side; sensing element/circuit
board are on opposite side.
LABEL
(see below)
External
Tag Loop (2)
Equipotential Connection
165 mm (6.5 inches)
Locked Unlocked
Lid Locking
Mechanism
(ATEX Systems)
Figure 1-3
4
Input/Output Module
114 mm
(4.5 inches)
External Lid Lock (2)
M4 2.5 mm Hex Drive
