S/N: 1033 AND ABOVE
GB745SH
PLEASE CONTACT GAGE BILT FOR
ALL OTHER SERIAL NUMBERS.
INSTALLATION TOOL
GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE
E-MAIL US FOR A DISTRIBUTOR NEAR YOU.
GAGE BILT Inc.
GAGE BILT
44766 Centre Court
(586) 226-1500
Clinton Twp. MI 48038
(586) 226-1505 Fax
MADE IN U.S.A.
e-mail: solutions@gagebilt.com / www.gagebilt.com

Advertisement

Table of Contents
loading

Related Manuals for Gage Bilt GB745SH

Summary of Contents for Gage Bilt GB745SH

  • Page 1 S/N: 1033 AND ABOVE GB745SH PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS. INSTALLATION TOOL GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE E-MAIL US FOR A DISTRIBUTOR NEAR YOU. GAGE BILT Inc. GAGE BILT 44766 Centre Court (586) 226-1500 Clinton Twp. MI 48038 (586) 226-1505 Fax MADE IN U.S.A.

  • Page 2: Table Of Contents

    - .620" (15.75 mm) Rated pull load - 6,300 lbs. (28.02 kN) Noise level - Less than 81.5 dB (A) Vibration - Tested– No Hazards Found S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 3: Warnings

    73.2 dB (A). In this daily basis for damage or wear. Any repair should condition the max level was 81.5 dB (A). Therefore, be done by qualified personnel trained on Gage Bilt it is required where prolonged use, hearing procedures.

  • Page 4: Principle Of Operation

    PISTON PRESSURE PISTON PRESSURE PRESSURE PRESSURE PRESSURE PISTON PISTON VALVE SPOOL PRESSURE PRESSURE REAR POSITION FORWARD POSITION EXHAUST Image may not reflect actual tool S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 5: How To Use The Gb745Sh

    (704312) the stem will eject to the rear of the tool. ASSEMBLY CYLINDER HEAD DEFLECTOR RIVET WORK ACTUATOR SHIPPING ASSY PLUG Image may not reflect actual tool QUICK DISCONNECT FITTING S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 6: Description, Maintenance And Hydraulic Thread Preparation

    The GB745SH split riveter operates on a wide range of air pressure, with 90 to 100 psi (6.2-6.9 bar) providing the maximum efficiency. At 90 psi. (6.2 bar) air pressure, the GB745SH does not exceed 81.5 dB (A) and consumes 3.9 cfm at 20 cycles per minute.

  • Page 7: Filling And Bleeding

    (A). Holding actuator in, check dimension (B). Subtract dimension (A) from dimension (B). If stroke is not within 1/64” (.0156) repeat steps 18-23. "A" .147 (3.7mm) "B" .767 (19.5mm) RIGHT SIDE LEFT SIDE BLEEDER HOLE BLEEDER HOLE STAMPED #1 STAMPED #2 S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 8: Troubleshooting

    Replace worn or broken parts. Clean the surface the jaws ride on. Stems lodged side by side in the follower. Disassemble, remove stems, and reassemble. Incorrect follower. S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 9: Overhaul, Disassembly And Parts Lists

    WARNING: Tool must be maintained in a safe working condition at all times and examined on a regular daily basis for damage or wear. Any repair should be done by qualified personnel trained on Gage Bilt procedures. WARNING: When operating, repairing or overhauling tool, wear approved eye protection. Do not look in Front of tool or rear of tool when installing fastener.
  • Page 10 S1181 - BARBED FITTING 402482 BUTT0N HEAD CAP SCREW 402482 - BUTT0N HEAD CAP SCREW S572 - STAT-O-SEAL S572 - STAT-O-SEAL 745303 - MANIFOLD - HANDLE S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 11 S908 - BACK-UP RING 400785 - O'RING 745344 744143 - MUFFLER PISTON ROD ASSEMBLY 744124 - BASE COVER (INCLUDES S908 AND A-201) 744149 - PIN S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 12: Dexron® Iii Oil Safety Data

    Use material for its intended purpose or recycle if possible. Oil collection services are available for used oil recycling or disposal. Place contaminated materials in containers and dispose of in a manner consistent with applicable regulations S/N: 1033 AND ABOVE 7/12 REV. 8/14 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 13: Nose Assembly Selection Chart

    OF A VDEL UK LIM ITED. CHERRYM A X® A ND M B C® A RE REGISTERED TRA DEM A RKS OF CHERRY A EROSP A CE FA STENERS. GAGE BILT CERTIFIES THE GB745 WILL INSTALL THE ABOVE FASTENERS *ALL OFFSET 204 SERIES NOSES REQUIRE 353204 ADAPTER, & ALL OFFSET 205 SERIES NOSES REQUIRE 353205 ADAPTER.

  • Page 14: Eu Conformity And Warranty

    GAGE BILT DECLARATION OF CONFORMITY MANUFACTURER: Gage Bilt Inc. 44766 Centre Ct. Clinton Twp. Michigan (586-226-1500) WE DECLARE THAT THE EQUIPMENT SPECIFIED HEREIN CONFORMS TO THE FOLLOWING DIRECTIVES AND STANDARDS Machinery Directive 2006/42/EC EN12100-1 & EN12100-2 EN792-1:2000+A1 EU REPRESENTATIVE Edgar Hausmann GmbH Förster-Busch-Str. 10 D-34346 Hann. Münden Germany EQUIPMENT DESCRIPTION: GB745SH FASTENER INSTALLATION TOOL This procuct specified above conforms to the above dIrectives and standards.
