DESCRIPTION
The Avtron Model HS4 Incremental Encoder is a light mill duty speed
and position transducer (also known as tachometer or rotary pulse
generator), allowing operation down to zero RPM. The HS4 employs
Hall Effect magnetic sensing technology, and when coupled to a motor
or machine the encoder outputs a specific number of electrical Pulses
Per Revolution (PPR) that is directly proportional to shaft position (pulse
count) or speed (pulse rate).
The HS4 employs a hollow shaft and clamping collar to lock the
encoder to the motor shaft. An insert permits models to fit a broad
range of shaft sizes from 3/8" to 5/8" [6mm - 15mm]. An anti-rotation
tether prevents rotation of the encoder while allowing for shaft end
float and axial movement. The HS4 encoder offers 2Ø outputs (A, B)
90° apart for direction sensing (A Quad B), with complements (A/, B/),
and with marker pulse and complement (Z ,Z/).

INSTALLATION CONSIDERATIONS

See page 3 and drawing on last page for shaft engagement rules.
Shaft may include keyway, but should not be flatted. The HS4 offers
optional Avtron flexible anti-rotation tethers which will permit the
encoder to tolerate ±0.1" of shaft end float/axial movement. Select the
proper tether for the application from the table below.
CAUTION
Be careful not to damage clamping fingers of hollow
shaft during handling. Do not tighten clamping collar
before installation onto motor shaft.
MODEL PPR LINE DRIVER
HS4 1 - 5-30V In & Out
BA - 30 AJ - 960
4 - 5-30V In / 5V Out
AA - 32 AW - 1000
AK - 80 AY - 1024
BC - 100 AZ - 1200
AH - 120 AV - 1440
AC - 128 AU - 1800
AM - 200 A3 - 2000
AL - 240 A4 - 2048
AN - 256 AT - 3072
AE - 360 A6 - 3600
AG - 400 AD - 4096
AB - 480 A8 - 4800
AQ - 500 A9 - 5000
AR - 512 CA - 12700
AS - 600 CB - 10000
AP - 720
CONNECTOR
HOUSING
CODES
3 - 36mm
A, B, C, D, E, F, G, H, 4 - 42mm
J, K, M, N, R (SST Housing & IP69 "K" Seal option only)
5 - 58MM
2, 3, 5, 7, T, U, W All (3, 4, 5)
A - 10 pin MS w/o Plug, Avtron/BEI Pinout E - 6 pin MS w/o Plug, BEI/Avtron HS35 pinout
B - 10 pin MS w/o Plug, Dynapar HS35 pinout F - 6 pin MS w/o Plug, Dynapar HS35 Pinout
(Rev Phasing) (Rev Phasing)
C - 10 pin MS with Plug, Avtron/BEI Pinout G - 6 pin MS with Plug, BEI/Avtron HS35
D - 10 pin MS with Plug, Dynapar HS35 pinout
pinout (Rev Phasing) H - 6 pin MS with Plug, Dynapar HS35 Pinout
(Rev Phasing)
SHAFT SIZE CONNECTOR*
D - 1/4"
See Connector Codes
A - 3/8" table for compatible
B - 1/2" Connector & Housing
C - 5/8"*
L - 6mm
M - 8mm
N - 10mm
2 - 11mm
P - 12mm
Q - 14mm
R - 15mm*
*Native Bore / No Insert
CONNECTOR EXIT
R - Radial (side) ONLY
not available
A - Axial (end) ONLY
A or R
CONNECTOR
J - 7 pin MS w/o Plug, Avtron/BEI HS35 Pinout
K - 7 pin MS w/o Plug, Dynapar HS35 Pinout
(Rev Phasing)
M - 7 pin MS with Plug, Avtron/BEI HS35
Pinout
N - 7 pin MS with Plug, Dynapar HS35 Pinout
(Rev Phasing)
WARNING
Installation should be performed only by qualified
personnel. Safety precautions must be taken to ensure
machinery cannot rotate and all sources of power are
removed during installation.
WARNING
Be certain to identify thread locker and anti-seize
compound correctly. Using anti-seize in place of thread
locker can cause mechanical failure leading to
equipment failure, damage, and harm to operators.
Equipment Needed for Installation
Provided
HS4 Encoder Mating MS Cable
with Tether (if Connector
selected) Protective Basket Kit
Tether w/mounting
screws
CONNECTOR EXIT TETHER HOUSING SIZE
A - Axial (end) 3 - 36mm
See Chart Below
R - Radial (side) 4 - 42mm (SST)
5 - 58mm
CONNECTOR
CHANNEL
CODES
A, B, C, D, R, T, U, 2, A
3, 7, W
E, F, G, H, J, K, M, N B, E
5 E
R - 10 Pin Mini Twistlock with Plug
T - M12-8 pin w/o Plug, Global Pinout
7 - M12-8 pin w/o Plug, Global Pinout (Rev Phasing)
U - M12-8 pin w/o Plug, USA Pinout
HS4 1
Encoder Instructions
MODEL
HS4
Incremental Magnetic
1/4", 3/8", 1/2", 5/8" & 6-15mm
Hollow Shaft Encoder
Optional Not Provided
Thread Locker (Loctite 242 recommended)
Anti-Seize
Dial Indicator Gauge
SEALS CHANNEL
A - IP65 Seals, Alum A - All Channels (A, A, B, B, Z, Z)
Housing B - A, A, B, B, No Marker
G - IP67 Seals, Alum E - A, B, Z, No Compliments
Housing
J - IP67 Seals, SST
Housing
K - IP69K Seals, SST
Housing (with "4" housing
size only)
X - IP54 no Seals, NOT
RECOMMENDED
A - Dual-Tab Tether: 1.65" [42mm] BC, 0.14" [3.5mm] slot
B - Dual-Tab Tether: 2.48" [63mm] BC, 0.13" [3.2mm] slot
TETHER OPTIONS
C - Dual-Tab Tether: 1.65"-2.48" [42-63mm] BC, 0.14" [3.6mm] slot
D - Fan Cover Tether: 1.57-2.95" [40-75mm] BC, 0.45" [11.4mm] slot
X - No Tether
2 - M23-12 Pin w/o Plug, Leine & Linde and Hubner pinout
3 - M23-12 Pin w/o Plug, Inverted Hubner Signals
5 - M12-5 Pin w/o Plug
W - 3.2ft [1m] Cable (also use with special mod 9XX)
MOD CODE
000 - NONE
901 - 1' [0.3m] cable
902 - 2' [0.6m] cable
903 - 3' [0.9m] cable
905 - 5' [1.5m] cable
910 - 10' [3m] cable
915 - 15' [4.5m] cable
920 - 20' [6m] cable
925 - 25' [7.5m] cable
930 - 30' [9m] cable
