New England Arbors The Barcelona Planter Box Assembly Instructions

A S S E M B LY I N S T R U C T I O N S
The Barcelona Planter Box
Please read through before starting assembly.
Check Box for T hese Contents
IIn the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
(UK Tel: (44) 2038 687160 (Mon. to Fri. 1:00 PM to 10:00 PM GMT).
1. Pre-Assembled Side Wall Panels (2) -
2. Post Caps (4) -
10611
3. Floor Panels (2) -
10612
4. Pre-Assembled Front/Back Wall Panels with Posts (2) -
5. 1 1/2" (38 mm) Self-Auguring Stainless Steel Screws (16) -

Tools You Will Need

• Cordless Drill
• Hammer

General Information

• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 4'x 8' (1.2 m x 2.4 m) for unobstructed
assembling.
• You should not need to use excessive force when assembling components.
S T E P O N E
Connect the Front & Back Wall
to the Side Wall Panels
Layout front wall panel on the work surface.
Insert the side walls into the routed holes on the front wall
panel posts.
10610
10613
1
2
20"
(51cm)
27"
(69 cm)
1
20005
2
3
4
1
www.newenglandarbors.com
www.newenglandarbors.co.uk
1
17"
(43 cm)
21"
(53cm)
5
Not to Scale
2
V1.2/072617
21.75" (55 cm)
1
