Page 1: Installation Guide
Installation Guide 40370 Kargo Master Rancho Cordova, CA 95742 800-343-7486 CustomerService@KargoMaster.com DATE: ______________... - Page 2 Installation Instructions – 40370 *PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING, INSTALLING, AND USING THIS PRODUCT* Warning Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality items prior to drilling and installing all products.
- Page 3 Installation Instructions – 40370 For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2...
- Page 4 Installation Instructions – 40370 Step 1 - Assembly • Bolt all three pieces together as shown below. Repeat 2x. • Use #10 x .50” Pan head screw (1) to bolt into #10 Nuts. • Top Tray (A), sits on top of each flange on sides (B&C)
- Page 5 Installation Instructions – 40370 Step 2 - Installation • Place previously assembled bin holder onto desired location. • One can mount this part to multiple different places. These instructions show them being mounted to KargoMaster 46” Shelf unit. • Bolt through existing holes in shelf side panel using a 1/4” x .50” pan head screw.
