- Page 1 Instruction Guide Pegboard Kargo Master Rancho Cordova, CA 95742 800-343-7486 CustomerService@KargoMaster.com 20200618R1 DATE: _____________...
- Page 2 Step 2B – Installing using Lock Nuts........................5 Attaching Accessories ............................5 Before You Begin Read all instructions prior to installing any Kargo Master product. 42000 Parts List For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST)
- Page 3 Installation Instructions – Pegboard 42001 Parts List Hardware For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2...
- Page 4 Installation Instructions – Pegboard Step 1 – Installation Determine proper installation location. Installing the pegboard requires holes be drilled through installation surface, so make sure the following clearances and warnings are met. Be sure there is proper clearance behind installation surface for bolts and nuts to be installed. ...
- Page 5 Installation Instructions – Pegboard Step 2A – Installing using Plus Nuts Using 25/64” drill bit and appropriate sized drill-bit stop collar, drill a hole at each marked location. If 25/64” drill bit is not available, a 3/8” drill bit can be used, although it may be necessary to tap in the plus nuts.
- Page 6 Installation Instructions – Pegboard Step 2B – Installing using Lock Nuts Using a 17/64” drill bit and appropriate sized drill-bit stop collar, drill a hole through the installation surface at each location marked. Using six 1/4” x 5/8” hex head screws, six 1/4” washers, and six 1/4”...
