Using the Control Panel

On/Off Line and Lamp
Turn your machine On-line or Off-line.
The lamp lights while the machine is
on-line, indicating the machine is ready
for printing a PC file.
Use to give print priority to PC file
while the machine prints
a received fax.
One-Touch Dial and
Special Function Buttons
Use to call most frequently used
numbers with one button. Also, use
these buttons with Menu button to set
up special functions or print lists.
2.2
Print Priority
The display shows the current status of
your machine and guides you through
various tasks using a menu system for
01 02 03 04
System Data System ID Date & Time System Setup
06 07 08 09
Delay TX Memory TX Priority TX
11 12 13 14
Add/Cancel Group Dial Maintenance Journal
16 17 18 19
TX Confirm Schedule Job Phone Book System List
Use to display the next or last menu item.
Also, use to adjust audible volume.
Use to choose special functions.
Use to move cursor left or right
through the display.
Use to stop an operation at any time.
Use to copy a document.
Use to start a job. Also use to activate the
selection shown in the display.
LCD Display
each of operation.
On/Off Line
Print Priority
Multi Function Laser Facs
Menu
05
Memory Clear
10
Polling
15
Help List
20
Copy
¹ and
Menu
à and ¨
Stop
Copy
Start/Enter
Volume
Stop
