R8 (Max.)
NOTE: The solid line is the line to use when cutting into the dash/helm.
The dotted line shows the outline of the IC-M412's front panel once the radio is fitted into the hole.
Do not follow the dotted line when making the hole in your dash/helm.
164
149
12
TEMPLATE
Unit: mm
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
57
