startup settInGs

program change switch setting

To be able to change the TempTracker mod+ Hybrid settings the Program/Run Switch must be
set to Program. The switch is located under the Enclosure Wiring Cover for security.

startup sequence

Button: MENU/<System Startup>
• When powered, the TempTracker mod+ Hybrid performs a self diagnostics-test.
• On the first power up, the System Startup screen will appear after the initialization is
complete. If it doesn't, the TempTracker mod+ Hybrid has already been configured.
• The System Startup menu sets the main parameters that relate to the heating application.
These settings must be set by the installer.

Boiler type

Modulation, Staging, Hybrid
Button: MENU/<System Startup>/..../Boiler Type
• The same Raypak control can operate modulating boilers, staging boilers, or a combination
of both types.
• The Modulation option will operate a variety of modulating boilers.
• The Staging option will operate a variety of On/Off or multi-stage boilers.
• The Hybrid option will sequence two groups of boilers, condensing and non-condensing.
Each group could be of a different boiler type (Modulation or Staging). See "HYBRID
Startup Settings" on page 21. Each Multi-Stage boiler will use a single output relay. The
staging will take place using the voltage output signal.
• If BACnet is to be used, each of the Boiler Type modes will have a different set of BACnet
variables. See "Hybrid - Outdoor Reset - BACnet Variable list" on page 44..

sensor type

Reset °F, Reset °C, Set Point °F, Set Point °C, 4-20mA EMS
(Set Point Options Not Available with Hybrid Boiler Type)
Button: MENU/<System Startup>/..../Sensor Type
• If Reset °F is selected, all temperatures and settings will be displayed in degrees Fahrenheit
and the control will use Reset Ratios to adjust the system set point.
• If Reset °C is selected, all temperatures and settings will be displayed in degrees Celsius and
the control will use Reset Ratios to adjust the system set point.
• If Set Point °F is selected, all temperatures and settings will be displayed in degrees
Fahrenheit and the control will have an adjustable system set point.
• If Set Point °F is selected, all temperatures and settings will be displayed in degrees Celsius
and the control will have an adjustable system set point.
• The 4-20mA EMS option is only available to the Hybrid Boiler Type option. To use
4-20mA EMS with Staging and Modulating Boiler Types, select one of the Set Point options
and the EMS Input Mode menu will follow to offer the 4-20mA EMS option.
• The use of the 4-20mA EMS option requires the purchase of the 4-20mA EMS Interface
(#012019). It gives the TempTracker mod+ Hybrid the capability of accepting a remote
4-20mA signal from a BMS or EMS system as the target set point.
• If BACnet is to be used, each of the Sensor Type modes will have a different set of BACnet
variables. See "Hybrid - Outdoor Reset - BACnet Variable list" on page 44..
eMs Input Mode
Disable, Enable
(Available after Set Point with Staging or Modulation Boiler Types)
Button: MENU/<System Startup>/..../Boiler Type/Sensor Type / EMS Input Mode
• It allows the TempTracker mod+ Hybrid to utilize the 4-20mA EMS Interface (#012019) to
accept a remote 4-20mA signal from a BMS or EMS system as the target set point.
115VAC 60Hz , 30VA MAX
USE COPPER WIRE,
CLASS 1 WIRE ONLY.
ENCLOSED
ENERGY
CAUTION
: RISK OF ELECTRIC SHOCK
MANAGEMENT
More than one disconnect switch may be required
EQUIPMENT
99RA to de-energize the equipment before servicing.
Default: Modulation
Default: Reset °F
Default: Disable
C
D
PROGRAM RUN
-------- SETTINGS ----
Season Winter
System Target 140
<System Settings>
<Maintenance>
<Histories>
<System Startup>
BACK ▲ ▼ SELECT
--- BOILER TYPE ---
Modulation
Staging
Hybrid
BACK ▲ ▼ SAVE
-- SENSOR TYPE --
o
Reset F
o
Reset C
o
Set Point F
o
Set Point C
BACK ▲ ▼ SAVE
--- SENSOR TYPE ---
o
Reset F
o
Reset C
4-20mA EMS
BACK ▲ ▼ SAVE
- EMS INPUT MODE -
Disable
Enable
BACK ▲ ▼ SAVE
o
F
