Novus LogBox Wi-Fi Instruction Manual page 27

94 CH2_ALARM_MAX_STATUS
95 CH2_ALARM_STATUS
97 CH3_STATUS
98 CH3_VALUE
99 CH3_VALUE_MIN
100 CH3_VALUE_MAX
101 CH3_ALARM_MIN_STATUS
102 CH3_ALARM_MAX_STATUS
103 CH3_ALARM_STATUS
106 BATTERY_VOLTAGE_VALUE
107 BATTERY_VOLTAGE_VALUE_MIN
108 BATTERY_VOLTAGE_VALUE_MAX
109 BATTERY_PERCENTAGE_OF_LIFE
113 EXTERNAL_VOLTAGE_VALUE
114 EXTERNAL_VOLTAGE_VALUE_MIN
115 EXTERNAL_VOLTAGE_VALUE_MAX
121 MQTT_LAST_UPDATE_YEAR
122 MQTT_LAST_UPDATE_MONTH
123 MQTT_LAST_UPDATE_DAY
124 MQTT_LAST_UPDATE_HOUR
NOVUS AUTOMATION
Analog channel maximum alarm status 2.
Analog channel 2 current alarm status.
Analog channel status 3.
Analog channel current value 3.
Minimum value recorded on analogue channel
3.
Maximum value recorded on analogue
channel 3.
Analog channel minimum alarm status 3.
Analog channel maximum alarm status 3.
Current analog channel alarm status 3.
Current value of battery voltage.
Minimum battery voltage value.
Maximum battery voltage value.
Battery life.
External voltage value.
Minimum registered voltage of external source
voltage.
Maximum recorded value of external source
voltage.
Year of last submission to the MQTT Broker.
Month of last submission to the MQTT Broker.
Day of last submission to the MQTT Broker.
Hour of last submission to the MQTT Broker.
Decimal places:
1. For temperature sensors
and the cold joint;
2. For battery voltage and
external power supply.
For linear sensors, the decimal
point is configured.
0. No alarm;
1. Minimum alarm;
2. Maximum alarm.
1. Ok;
2. Underflow;
3. Overflow;
4. Cold joint error;
5. Open sensor.
Decimal places:
1. For temperature sensors
and the cold joint;
2. For battery voltage and
external power supply.
For linear sensors, the decimal
point is configured.
Decimal places:
1. For temperature sensors
and the cold joint;
2. For battery voltage and
external power supply.
For linear sensors, the decimal
point is configured.
Decimal places:
1. For temperature sensors
and the cold joint;
2. For battery voltage and
external power supply.
For linear sensors, the decimal
point is configured.
Stores information if the channel
ever reached the minimum
alarm.
0. Never alarmed;
1. Already alarmed.
Stores information if the channel
ever reached the maximum
alarm.
0. Never alarmed;
1. Already alarmed.
0. No alarm;
1. Minimum alarm;
2. Maximum alarm.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
Unit in volts with two decimal
places.
27/53
