4.1.6 Connector Pin Assignment

Table 8: Connector Pin Assignment, VLT® Safety Option MCB 150
Y30
1 2 3 4 5
MCB 150
Safe Option
SW. ver. xx. xx
TT L Enc.interface
1 2 3 4
Y30/
Illustration 22: Nameplate MCB 150
Danfoss A/S © 2018.09
6 7 8 9 10 11
Option B
130B3280
1 2 3 4
LED:
5 6 7 8 9 10 11 12
Pin
1
12
2
3
4
5
6
7
8
9
10
11
12
Name Description
DI1 A Digital input 1 A channel
GND Digital GND
DI1 B Digital input 1 B channel
ENC A Encoder channel A
DI2 A Digital input 2 A channel
ENC nA Encoder channel A inverted
ENC B Encoder channel B
DI2 B Digital Input 2 B channel
ENC nB Encoder channel B inverted
24 V Power output
GND Supply GND
S37 STO enable
