USB-1608G-OEM User's Guide

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)

Header connector

Parameter
Connector type

Pin orientation

Table 14. Environmental specifications
Specification
0 °C to 55 °C max
–40 °C to 85 °C max
0% to 90% non-condensing max
Table 15. Mechanical specifications
Specification
121.92 × 86.36 × 15.24 (4.80 × 3.40 × 0.60 in.)
Table 16. Header connector specifications
Specification
Two 1 × 28 pin 0.1 in. pitch headers
22
Specifications
