Single-ended mode pinout

Pin Signal Name
1 CH0
2 CH8
3 AGND
4 CH1
5 CH9
6 AGND
7 CH2
8 CH10
9 AGND
10 CH3
11 CH11
12 AGND
13 NC
14 AGND
15 NC
16 AGND
17 NC
18 GND
19 DIO0
20 DIO1
21 DIO2
22 DIO3
23 DIO4
24 DIO5
25 DIO6
26 DIO7
27 GND
28 GND
Table 18. 16-channel single-ended mode pinout
Description
Channel 0
Channel 8
Analog ground
Channel 1
Channel 9
Analog ground
Channel 2
Channel 10
Analog ground
Channel 3
Channel 11
Analog ground
No connection
Analog ground
No connection
Analog ground
No connection
Digital ground
DIO channel 0
DIO channel 1
DIO channel 2
DIO channel 3
DIO channel 4
DIO channel 5
DIO channel 6
DIO channel 7
Digital ground
Chassis ground
Pin Signal Name
29 CH15
30 CH7
31 AGND
32 CH14
33 CH6
34 AGND
35 CH13
36 CH5
37 AGND
38 CH12
39 CH4
40 AGND
41 AGND
42 AGND
43 +VO
44 AGND
45 NC
46 GND
47 AICKI
48 AICKO
49 NC
50 NC
51 TRIG
52 GND
53 CTR1
54 CTR0
55 TMR
56 GND
24
Specifications
Description
Channel 15
Channel 7
Analog ground
Channel 14
Channel 6
Analog ground
Channel 13
Channel 5
Analog ground
Channel 12
Channel 4
Analog ground
Analog ground
Analog ground
+5V voltage output
Analog ground
No connection
Digital ground
AI clock input
AI clock output
No connection
No connection
Trigger input
Digital ground
Counter 1
Counter 0
Timer output
Digital ground
