- Page 1 USER’S GUIDE FOR THE BD800AM: AMPS MOBIL BI-DIRECTIONAL AMPLIFER/REPEATER MODEL: BD800AM Rev 1.1 11/26/2002...
- Page 2 The information provided by Wilson Electronics, Inc. is believed to be complete and accurate. However, no responsibility is assumed by Wilson Electronics, Inc. for any business or personal losses arising from its use, or for any infringements of patents or other rights of third parties which may result from its use.
-
Page 3: Package Contents
1. PACKAGE CONTENTS 1.1 Amplifier/Repeater 1.2 12V Car Adapter 1.3 Low Profile Antenna (Inside Antenna) 1.4 (Outside Antenna Sold Separately) 800 MHz Magnet Mount Shown OUTSIDE ANTENNA NOT INCLUDED Rev 1.1 PAGE... - Page 4 2. AMPLIFIER 2.1 About The Amplifier greatly improves signal strength when using your portable AMPS phone inside the car. The signal is received by the outside antenna from the cell site. It is then AMPLIFIED/REPEATED and then transmitted to your AMPS phone through the inside antenna. When the phone transmits it is received by the inside antenna.
- Page 5 3. AMPLIFIER/REPEATER INSTALLATION (REFER TO ILLUSTRATION) 3.1 Installing the Outside Antenna (800 MHz Magnet Mount) [Sold Separately] 3.1.1 Select a location on the roof: Try to keep Antenna centered on the car roof. 3.1.2 The Outside Antenna should be located in an area with at least a 12” (30cm) radius clear of obstructions, and other radiating elements.
- Page 6 3.2 Installing The Amplifier/Repeater 3.2.1 Mount the AMPLIFIER/REPEATER under the dash or car seat. 3.2.2 Connect the Outside Antenna to the AMPLIFIER/REPEATER side labeled “OUTSIDE ANTENNA”. NOTE: The amplifier should be mounted to the selected location using mounting screws. 3.3 Installing The Inside Antenna 3.3.1 Connect the Inside Antenna to the side labeled “INSIDE ANTENNA”...
- Page 7 Rev 1.1 PAGE...
